OWNER'S MANUAL
TRINITY PRO 5-TIER NSF 72" x 24" x 72"
WIRE SHELVING RACK
Model # TBTZ-0948 / TBTPBA-0948
/ TBFPBA-0948
Important / Important / Importante
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
Direct ives int elligent es
POUR DES DIRECTIVES D'ASSEMBLAGE 3D RAPIDES ET FACILES
Inst rucciones Int eligent es
PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D
DOWNLOAD THE FREE APP | TÉLÉCHARGER L'APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA
Advertisement
Related Manuals for TRINITY Pro TBTZ-0948
Summary of Contents for TRINITY Pro TBTZ-0948
- Page 1 OWNER’S MANUAL TRINITY PRO 5-TIER NSF 72" x 24" x 72" WIRE SHELVING RACK Model # TBTZ-0948 / TBTPBA-0948 / TBFPBA-0948 Important / Important / Importante FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS Direct ives int elligent es POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES Inst rucciones Int eligent es PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D...
-
Page 2: Table Of Contents
PARTS LIST Your TRINITY PRO 5-Tier NSF 72"x24"x72“ Wire Shelving Rack should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. -
Page 3: Bottom Pole
ASSEMBLY INSTRUCTIONS STEP 1 For easiest assembly, do not attach TOP POLES (B) and BOTTOM POLES (A) until instructed. Once connected, these will be posts for the rack. A (4) D (8) Note that POLES (A+B) have slight horizontal line indentations at 1” intervals. - Page 4 ASSEMBLY INSTRUCTIONS STEP 3 On BOTTOM POLE (A), place 1 pair of SLIP SLEEVES (D) at desired height. Make sure D (8) C (1) arrow faces up and word “TOP” is right side up. Do this for each BOTTOM POLE (A), and make sure height is identical for each BOTTOM POLE (A).
- Page 5 ASSEMBLY INSTRUCTIONS STEP 5 Repeat Step 3 to install other SHELVES (C) as desired. C (3) D (24) Note: • Shelves are adjustable in 1” increments and can be placed as needed to best fit storage needs. • Use a rubber mallet, if needed, to secure SHELVES (C).
-
Page 6: Feet Leveler
SERVICE PARTS LIST – Chrome Color TBTZ-0948 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-01-011-2543 Slip Sleeve XBK-98-010-2535 Feet Leveler ZSV-04-006-3600 Top Pole XBK-23-004-2514 End Cap ZSV-01-013-2523 Pole Connector ZSV-03-074-7224 Shelf ZSV-04-043-3600 Bottom Pole... -
Page 7: Top Pole
SERVICE PARTS LIST – Black TBTPBA-0948 / TBFPBA-0948 Anthracite Color TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-01-012-2543 Slip Sleeve XBK-98-010-2535 Feet Leveler PBA-04-006-3600 Top Pole XBK-23-004-2514 End Cap ZSV-01-013-2523 Pole Connector PBA-03-074-7224 Shelf PBA-04-043-3600 Bottom Pole... - Page 8 CARE AND MAINTENANCE • Wipe with a dry cloth as needed to remove dust and dirt. • Avoid harsh, abrasive cleaners, and other corrosive chemicals. • The chrome color version (TBTZ-0948) is not recommended for outdoor use. © 2020 TRINITY - 800.985.5506...
- Page 9 PRODUCT REGISTRATION Thank you for purchasing a TRINITY PRO 5-Tier NSF 72"x24"x72“ Wire Shelving Rack. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com.
- Page 10 © 2020 TRINITY - 800.985.5506...
- Page 11 Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY PRO 5-Tier NSF 72"x24"x72“ Wire Shelving Rack (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s...
- Page 12 CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com...
