ASSEMBLER/INSTALLER:
L
EAVE THESE INSTRUCTIONS WITH THE CONSUMER
CONSUMER/USER:
R
EAD ALL THESE INSTRUCTIONS AND KEEP THEM IN A
SAFE PLACE FOR FUTURE REFERENCE
WARNING:
T
HE EDGES OF SHEET METAL PARTS CAN CAUSE INJURY
IF NOT HANDLED WITH CARE
USE EXTREME CAUTION!
IMPORTANT!
T
O ENSURE PROPER GAS FLOW
CONTROL VALVES MUST BE
OPENING THE GAS CYLINDER VALVE
G000-031 (02/08/02)
.
.
.
,
BURNER
"OFF"
BEFORE
.
Coleman Company, Inc.
3600 N. Hydraulic
Wichita, KS 67219
Internet site:
www.coleman.com
1-800-356-3612
TDD: 316-832-8707

Advertisement

loading
Need help?

Need help?

Do you have a question about the BackHome LG406-SDN and is the answer not in the manual?

Questions and answers

Summary of Contents for Coleman BackHome LG406-SDN

  • Page 1 IF NOT HANDLED WITH CARE USE EXTREME CAUTION! IMPORTANT! O ENSURE PROPER GAS FLOW BURNER “OFF” CONTROL VALVES MUST BE BEFORE OPENING THE GAS CYLINDER VALVE G000-031 (02/08/02) Coleman Company, Inc. 3600 N. Hydraulic Wichita, KS 67219 Internet site: www.coleman.com 1-800-356-3612 TDD: 316-832-8707...
  • Page 2 UALITY OLEMAN ARBECUE RILL FOR EASE OF ASSEMBLY, leave the grill on the inside bottom foam packing tray until the wheels have been attached. (See representative example at right). Remove the outside foam from the right and left sides of the frame base at this time.
  • Page 3 Assemble the DOOR HANDLES (21) to the DOORS (20). See detail 1-A. NOTE: Attach MAGNET CATCH (81) to STAINLESS STEEL DOORS only. Step Attach the DOOR MAGNETS (19a) to the Door Stop Bracket. See detail 1-B. 1-A IF you have PAINTED DOORS, attach a DOOR HANDLE (21) to each DOOR (20) with two screws (BT) in each DOOR.
  • Page 4: Bottom View

    Attach the DOOR STOP (19b) on the grill base. See detail 2-A. Place the right DOOR (20) on the grill frame. See detail 2-A. Step Install the HINGE PIN (20a) in the Door. See detail 2-B. Repeat 2-A and 2-B for the left DOOR assembly.
  • Page 5: Door Assembly

    3-B. Loosen, the twelve front leg screws no more than 1/4 to 1/2 turn. Note: DO NOT REMOVE the screws. At the top of the grill frame, gently push left or right for proper alignment of the doors. Once the alignment is complete, re-tighten all screws from top to bottom.
  • Page 6 4-A. Insert the AXLE PINS (3) into the wheels. Insert the wheels and axle pins into each side of the base and secure with two clevis pins (WN). See diagram. Remove the remaining foam tray from under the barbecue grill now. A - M ISCELLANEOUS ARTS 4-B.
  • Page 7 Assemble the one GREASE PAN (48) and one GREASE CUP (49) under the bottom casting. See details 5-A and 5-B. Step 5-A. Secure two shoulder screws (DN) into the GREASE PAN (48) with two hex nuts (GC), taking care not to damage the porcelain by overtightening.
  • Page 8 Assemble CONTROL KNOBS (32), MEAT PROBE RECEPTACLE (57a) and MEAT PROBE (57). See detaill 6-A. Step 6-A. Place CONTROL KNOBS (32) on valve stems. Insert MEAT PROBE RECEPTACLE (57a) into the right side of the control panel. Place the MEAT PROBE (57) into the meat probe receptable. (Pg.
  • Page 9 Assemble HEAT TENTS (61) and DIVIDERS (62). See details 7-A and 7-B. Step 7-B. Slide the DIVIDERS (62) into the Bottom casting. 7-A. Set the HEAT TENTS (61) onto the bracket mount points. (Pg. 9)
  • Page 10 (Pg. 10) IMPORTANT: NOW R R EFER T T O T T HE R R OTISSERIE A A SSEMBLY Step MANUAL A A ND C C OMPLETE S S TEPS 1 1 a THROUGH 2 2 b BEFORE C C OMPLETING T T HE G G RILL A A SSEMBLY.
  • Page 11 Assemble FRONT HANDLE Assembly to the GRILL LID (55) in detail 9-A. Assemble two GUARDS (42b), COOKING GRIDS (63), GRIDDLE (64) and Step WARMING RACK (65). See detail 9-B and 9-C. 9-A. The FRONT HANDLE (58), HANDLE SPACER (60), HANDLE INSULATOR (59), four screws (DT) and four hex nuts (AO) are PRE-ASSEMBLED at the factory.
  • Page 12 CAUTION: DO NOT Remove screws completely. Place the bottom slot of the brackets on the screws first and then the top slot. Note: The TOOL BAR (12) faces the front of the grill. Gently slide the Bracket down and tighten screws.
  • Page 13 ELECTRONIC MODULE (28). Then attach the two orange ELECTRODE WIRES (29) located on the left side of your grill, to the pins on the module marked 1MB and 2MB. Insert the 9-VOLT BATTERY (30) in the module, it MUST snap in place.
  • Page 14 Attaching TYPE 1 fitting to the inline gas gauge. See detail 12-C. Outlet Valve Left side of grill 12-A Set CYLINDER (79) in the cylinder caddy with the outlet valve facing the left side of the grill. Tighten the cylinder hold down bolt against the bottom cylinder collar. 12-A Outlet...
  • Page 15 DO NOT WARRANT in any way the propane cylinder (see label on cylinder for cylinder manufacturer’s warranty) or the paint finish of the product. Coleman, at its option, will repair or replace this product or any component of the product found to be defective during the warranty period.
  • Page 16 (Pg. 16) Notes...
  • Page 17 SEGURO COMO REFERENCIA DVERTENCIA OS BORDES DE LA HOJA DE METAL PUEDEN CAUSAR LESIONES SI NO SON MANEJADOS CON CUIDADO ¡TENGA EXTREMA PRECAUCION! Coleman Company, Inc. ¡IMPORTANTE! 3600 N. Hydraulic ARA ASEGURAR UN CORRECTIO FLUIDO DE GAS Wichita, KS 67219 Página en Internet:...
  • Page 18 Herramientas Necesarias Destornillador Nº 20 6-Lobe (Incluye) Destornillador Phillips Nº 2 Destornillador ranurado Una llave inglesa Pila de 9 volts (Incluye) Herramientas Opcionales Llaves de tubo de 1 cm y 8 mm Llave para tuercas de 1 cm Destornillador eléctrico o inalámbrico Broca Torx Nº...
  • Page 19 Ensamblar las AGARRADERAS DE LA PUERTA (21) a las PUERTAS (20). Ver el detalle 1-A. NOTA: Fije los AGARRA IMANES (81) a las PUERTAS DE ACERO INOXIDABLE solamente. Paso Fije los IMANES PARA PUERTAS (19a) al Gancho Detiene Puertas. Vea la ilustración 1-B. NOTA: Agarra Imanes (81) es suplido SOLO para las unidades con Puertas de Acero Inoxidable.
  • Page 20 Sujete el PIE DE LA PUERTA (19b) en la base de la parrilla. Ver el detalle 2-A. Colocar la PUERTA derecha (20) en el armazón de la parrilla. Ver el detalle 2-A. Paso Instalar la CLAVIJA DE BISAGRA (20a) en la puerta. Ver el detalle 2-B. Repetir 2-A y 2-B para el ensamblaje de la PUERTA izquierda.
  • Page 21: Panel De Control

    NDIRECTAS PROVECHOSAS PARA LA ASAMBLEA DE LA PUERTA Extraiga la espuma protectora exterior del LADO IZQUIERDO y del LADO DERECHO de la BASE. Comprobar la alineación de las puertas con respecto al panel de control. Comprobar las ilustraciones 3-A y 3-B. Paso PANEL DE CONTROL UERTA...
  • Page 22 MPIECE CON LA CAJA DE CARTON A Consejos para el Ensamblaje de la Puerta Ensamblar las RUEDAS (16). Comprobar la ilustración 4-A. Paso Ensamblar la cesta (22) en el extremo derecho de la base y de las patas. Comprobar la ilustración 4-B. Extremo derecho Etiqueta Parte...
  • Page 23 Ensamblar el RECIPIENTE PARA LA GRASA (48) y la TAZA PARA LA GRASA (49) bajo la pieza inferior moldeada. Ver las ilustraciones 5-A y 5-B. Paso 5-A. Asegurar dos tornillos de resalto (DN) dentro del RECIPIENTE PARA LA GRASA (48) utilizando dos tuercas hexagonales (GC), tomando todas las precauciones necesarias para no dañar la porcelana al apretar excesivamente.
  • Page 24 Ensamblar las PERILLAS DE CONTROL (32), RECIPIENTE PARA LA SONDA DE LA CARNE (57a) y la SONDA DE LA CARNE (57). Paso Ver las ilustraciónes 6-A. 6-A. Colocar las PERILLAS DE CONTROL (32) en los vástagos de la válvula. Insertar el RECIPIENTE PARA LA SONDA DE LA CARNE (57a) dentro del lado derecho del panel de control.
  • Page 25 Ensamblar las CUBIERTAS PROTECTORAS CONTRA EL CALOR (61) y los DIVISORES (62). Ver las ilustraciónes 7-A y 7-B. Paso 7-B. Deslizar el DIVISOR (62) dentro de la pieza inferior moldeada. 7-A. Colocar las CUBIERTAS PROTECTORAS CONTRA EL CALOR (61) en los puntos de ensambleje del soporte. (Pg.
  • Page 26 (Pg. 26) IMPORTANTE: AHORA C C ONSULTE E E L M M ANUAL D D E A A RMADO D D EL Paso ROSTIZADOR Y Y S S IGA L L OS P P ASOS 1 1 A H H ASTA 2 2 B ANTES D D E S S EGUIR C C ON E E L A A RMADO D D EL A A SADOR.
  • Page 27 Ensamblar el montaje del ASA FRONTAL en la TAPA DE LA PARRILLA (55) tal como aparece en la ilustración 9-A. Armar las dos GUARDAS (42b), PARRILLAS DE COCCIÓN (63), ASADOR Paso (64) y PARRILLA DE CALENTAMIENTO (65). Vea las figuras 9-B y 9-C. 9-A.El ASA FRONTAL (58), SEPARADOR DEL ASA (60), AISLANTE DEL ASA (59), cuatro tornillos (DT) y cuatro tuercas hexagonales (AO) se preinstalan en...
  • Page 28 MPIECE CON LA CAJA DE CARTON Ensamblar la MESA LATERAL DERECHA premontada tal como aparece en la ilustración 10-A. Paso Ensamblar la MESA LATERAL IZQUIERDA premontada tal como aparece en la ilustración 10-B. Nota: Usar ambas manos y levantar con los soportes de la mesa lateral. No levantar NUNCA con partes plásticas.
  • Page 29 Ensamblar los CABLES DEL ELECTRODO (29), CABLES DE CONMUTACIÓN (26) y la pila de 9 voltios (30) en el MÓDULO ELECTRÓNICO (28) tal como aparece en las ilustraciones 11-A. Paso Ensamblar el MÓDULO ELECTRÓNICO (28) bajo la Mesa Lateral Izquierda tal como aparece en la ilustración 11-B.
  • Page 30 Ensamblar el TANQUE (79) al carrito del tanque. Ver el detalle 12-A. Fijar el CALIBRADOR DE GAS INTERNO (80) a la válvula de entrada de combustible. Ver el detalle 12-B. Paso Fijar el accesorio TIPO 1 a la calibrador de gas interno. Ver el detalle 12-C. Válvula de salida Parte...
  • Page 31 GARANTIZAMOS de ninguna manera el tanque de propano (ver la etiqueta que se encuentra sobre el tanque para determinar la garantía del fabricante del tanque) o el acabado de pintura del producto. Coleman dispone de la opción de reparar o de substituir este producto o cualquier componente del producto, el cuál se determine como defectuoso durante el período de garantía.
  • Page 32 (Pg. 32) Notas...
