- Page 1 User’s Guide W1946SM W2246SM ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for future reference. ee the label attached on the product and give the information to your dealer when you ask for service.
-
Page 2: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. - Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
- Page 4 Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
- Page 5 Important Precautions NOTE THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTRERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE This epuipment has been tested and found to comply with the limits for a class B digital device,pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates,uses and can radiate radio frequency...
- Page 6 Accessories !!! Thank for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Power Cord User's Guide/Cards 15-pin D-Sub Signal Cable (To set it up, this signal cable may be attached to this product before shipping out.) NOTE...
-
Page 7: Connecting The Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand Place the monitor with its front facing downward on a soft cloth. Assemble the Stand Body into the Assemble the Stand Base(Front, product in the correct direction as shown in... -
Page 8: Disassembling The Stand
Connecting the Display Disassembling the stand Place the monitor face Down on the Put a cushion or soft cloth on aflat cushion or soft cloth. surface. Change your lock on the product as it follows and turn it in the arrow direction. If you can't release the stand base even the locking knob is at a release position, Please push the indicated knob down and retry it. - Page 9 Connecting the Display Pull out the Stand to remove. Pushing the PUSH button, Take the stand body from hinge body. Good Position Bad Position Warning: You can hurt your finger.
-
Page 10: Positioning Your Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display -After installation, adjust the angle as shown below. Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -5˚~15˚... -
Page 11: Connecting With The Pc
Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable. -
Page 12: Using The Cable Holder
Connecting the Display Using the cable holder (This feature is not available in all models.) AUDIO IN D-SUB Cable holder... -
Page 13: Control Panel Functions
Control Panel Functions Front Panel Controls M O NI T O R SET U P AUTO MENU VOLUME MODE AUTO EXIT MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. -
Page 14: Auto Button
This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode). The best display mode is W1946SM : 1360 x 768 W2246SM : 1920 x1080 VOLUME Button To adjust the volume of headphone/Earphone. -
Page 15: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. -
Page 16: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub-menu Description To adjust the brightness, contrast BRIGHTNESS PICTURE and sharpness of the screen CONTRAST SHARPNESS COLOR COLOR TEMP To customize the color of the screen (PRESET / USER) - Page 17 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. M ON IT OR SE T U P AUTO MENU...
- Page 18 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE To adjust the brightness of the screen. BRIGHTNESS M EN U PICTU RE To adjust the contrast of the screen. CONTRAST BRIGHTNESS SHARPNESS To adjust the clearness of the screen. CONTRAST SHARPNESS EXIT...
- Page 19 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description HORIZONTAL To move image left and right. ME N U DI SP LAY To move image up and down. VERTICAL HORIZONTAL VERTICAL CLOCK PHASE To minimize any vertical bars or CLOCK 1024X768 60Hz stripes visible on the screen...
- Page 20 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description OTHERS LANGUAGE To choose the language in which the MENU OT HERS control names are displayed. Use this function to set the power LANGUAGE ENGLISH POWER POWER INDICATOR indicator on the front side of the monitor INDICATOR WHITE BALANCE to ON or OFF.
- Page 21 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. M ONIT OR SE TUP AUTO MENU...
- Page 22 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description NORMAL Select this when you want to use the product in the most general using environment. MOVIE Select this when you are watching a video or movie. INTERNET Select this when you are working on the document (Word etc.) DEMO This is used for advertising in the store.
- Page 23 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description WIDE Switch to full screen mode according to input image signal. ORIGINAL Change the input image signal ratio to original. * This function works only if input resolution is lower than monitor ratio (16:9).
-
Page 24: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator •... -
Page 25: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is • Press the AUTO button to automatically adjust incorrect. your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. - Page 26 Troubleshooting Display image is incorrect The screen color is • Check if the signal cable is properly connected mono or abnormal. and use a screwdriver to fasten if necessary. • Make sure the video card is properly inserted in the slot. •...
-
Page 27: Specifications
Specifications W1946SM Display 18.5 inches (47.0 cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 47.0 cm 0.300 x 0.300 mm (Pixel pitch) Horizontal Freq. 30 - 61 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate Sync. - Page 28 Specifications W2246SM Display 21.5 inches (54.6 cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 54.6 cm 0.248 x 0.248 mm (Pixel pitch) Horizontal Freq. 30 - 83 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate Sync.
-
Page 29: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) W1946SM Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 720 x 400 31.469 640 x 480 37.500 640 x 480 37.879 800 x 600 46.875 800 x 600 49.725 832 x 624 48.363 1024 x 768 60.123... -
Page 30: Installing The Wall Mount Plate
Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor with its front facing downward on a soft cloth. Separate the stand by pushing the PUSH button. Good Position Bad Position Warning: You can hurt your finger. - Page 31 Digitally yours...
