HorizontalPlacement
TheValethasfourrubberfeetonitsbottompanel .Place
theValetonalevelsurfacenearanelectricaloutlet .
HorizontalPlacement
Wall-MountingPlacement
TheValethastwowall-mountslotsonitsbottompanel .
Thedistancebetweentheslotsis152mm .
TwoscrewsareneededtomounttheValet .
Suggested Mounting Hardware
4-5mm 1-1 .5mm
NOTE: Cisco is not responsible for damages
incurredbyunsecuredwall-mountinghardware .
Printthispageat100%size .
Cutalongthedottedline,andplaceonthewalltodrillprecisespacing .
2 .5-3 .0mm
Wall-MountingTemplate
152 mm
Chapter1:ProductOverview
Followtheseinstructions:
1 . DeterminewhereyouwanttomounttheValet .Make
sure that the wall you use is smooth, flat, dry, and
sturdy .Alsomakesurethelocationiswithinreachof
anelectricaloutlet .
2 . Drilltwoholesintothewall .Makesuretheholesare
152mmapart .
3 . Insert a screw into each hole and leave 3 mm of its
headexposed .
4 . PositiontheValetsothewall-mountslotslineupwith
thetwoscrews .
5 . Place the wall-mount slots over the screws and slide
the Valet down until the screws fit snugly into the
wall-mountslots .
