- Page 1 MICROWAVE OVEN INSTRUCTION MANUAL FDMO-2099DIG IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS …………。 。 。 。 。 ……………………… The following basic precautions should always be followed when using electrical appliance: 1. Read all instructions before using. 2. Make sure the voltage in your living area corresponding to the one shown on the rating label of the appliance. And the wall socket is properly grounded. - Page 3 order to avoid possible hazards caused by delayed eruptive boiling of liquids. c. Potatoes, sausage and chestnut should be peeled or pierced before cooking. Eggs in their shell, whole hard -boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.
- Page 4 mode, children should only use the oven under adult supervision due to the temperatures generated. 14. Any accessories not recommended by the manufacturer may cause injuries to persons. 15. Do not use outdoors. 16. Save these instructions. 17. WARNING: If the door or door seals are damaged or the oven is malfunctioned, the oven must not be operated until it has been repaired by a competent person;...
- Page 5 • Farm houses; • By clients in hotels, motels and other residential environments; • Bed and breakfast type environments. 25. The microwave oven is intended for heating food and beverages. Drying of food or clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.
- Page 6 taken to avoid touching heating elements inside the oven. 33. The surfaces are liable to get hot during use. Household use only INSTALLATION… …………………………………………………..……….… 1. Take out all the packing. If there is a safe film over the oven, tear it off before Use. Check carefully for damage. If any, immediately notify dealer or send to the manufacturer’s service center.
-
Page 7: Microwave Oven Care
8. As there is manufacturing residue or oil remained on the oven cavity or heat element, it usually would smell the odor, even a slight smoke, It is normal case and would not occur after several times use, keep the door or window open to ensure good ventilation. -
Page 8: Tips For Cleaning
b. Place a cup of red tea in oven, then heat with high micro power. c. Put some orange peel into oven, and then heat them with high Micro Power for 1 minute. 6. WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use;... -
Page 9: Product Instruction
.PRODUCT INSTRUCTION …………………………......⑦ ⑤ ② ① ③ ④ ⑥ 1) Door lock Microwave oven door must be properly closed in order for it to operate 2) Viewing window Allow user to see the cooking status 3) Rotating axis The glass turntable sits on the axis; the motor underneath it drives the turntable to rotate 4) Rotating ring The glass turntable sits on its wheels;... -
Page 10: Operation Of Control Panel
7) Waveguide cover It is inside the microwave oven, next to the wall of control panel. Never remove the waveguide cover .OPERATION OF CONTROL PANEL …。 。 。 。 。 。 。 。 。 。 ...。 …... 1. BEFORE COOKING The LED flashes 3 times when plugged in power supply. - Page 11 2. TIME/WEIGHT KNOB You can increase or decrease cooking time, weight during operation by turning the knob. 3. PAUSE/CANCEL At the initial or input stage: press once to cancel input programs and resume initial stage. During cooking: press once to stop oven operation, press twice to cancel cooking programs.
-
Page 12: Microwave Cooking
Example: to set 12:30 Steps Display After power-up, the colon flashes 1:00 Press and hold Defrost/ Clock button for 3 1:00 seconds Turn Time/Weight knob to set exact hours. 12:00 Press Defrost/ Clock button once again. 12:00 Turn Time/Weight knob to set exact 12:30 minutes. - Page 13 c. At the maximum microwave power, the oven will automatically lower the power after a certain time of cooking to lengthen the service life. d. If you turn the food during operation, press the Instant/Start button once and the preset cooking procedure will continue. e.
- Page 14 Example: To cook with express for 1 minute Steps Display After power-up, the colon flashes 1:00 Press Express button consecutively to select 1:00 desired menu Instant/ Start cooking by pressing Start button 9. DEFROST This function use for defrost food. Press the Defrost/Clock button and the LED display will cycle to show d.1-d.2-d.3.
-
Page 15: Auto Cooking
Example: To defrost 0.4kg poultry Steps Display After power-up, the colon flashes 1:00 Press Defrost/ Clock button once to set the food kind. Turn Time/ Weight knob to set the defrost weight Instant/ Start cooking by pressing Start During defrosting, beep sounds will be heard two times to prompt you turn over the food. - Page 16 Display Kind Method Suitable for popping a bag of corn, Popcorn which is available in the market, weighted 0.1kg. Reheat Reheat food weighted 0.2-1.0kg. Heating 1-3 cup of liquid. The liquid Beverage temperature is about 5-10℃. Use a big mouth cup and do not seal Pizza Warm 1-2 pieces of chilled pizza.
-
Page 17: Automatic Starting (Delayed Function)
to the factor noted on above menu, you can adjust the cooking time for best result. Example: Steam 0. 5 kg fish Steps Display After power-up, the colon flashes 1:00 Press Auto Cooking button to set the cooking menu Turn Time/ Weight knob to set the set weight Instant/ Start cooking by pressing... - Page 18 Example: Now it is 12:30 clock, if you hope that the microwave oven will automatically start cooking with 100P microwave power for 9 minutes and 30 seconds at 14:20 Steps Display After power-up, the colon flashes 1:00 Press and hold Defrost/Clock button for 3 1:00 seconds Set hours by turning Time/ Weight knob...
-
Page 19: Multi-Sequence Cooking
12. MULTI-SEQUENCE COOKING To obtain best cooking result, some recipes call for different cook mode and time. You may program your personalized menu as follow: Example: You want cook food with 100P microwave for 3 minutes then 20P for 9 minutes. This is 2 sequence setting. Steps Display 100P microwave for 3min... -
Page 20: Utensils Guideline
.UTENSILS GUIDELINE …………………。。…………………………….. It is strongly recommended to use the containers which are suitable and safe for microwave cooking. Generally speaking, the containers which are made of heat-resistant ceramic, glass or plastic are suitable for microwave cooking. Never use the metal containers for microwave cooking and combination cooking as spark is likely to occur. -
Page 21: Cooking Tips
.COOKING TIPS …………………………………………。……………..…….. The following factors may affect the cooking result: Food arrangement Place thicker areas towards outside of dish, the thinner part towards the centre and spread it evenly. Do not overlap if possible. Cooking time length Start cooking with a short time setting, evaluate it after it times out and extend it according to the actual need. -
Page 22: Maintenance
Microwave safe plastic cookware Some microwave safe plastic cookware might not be suitable for cooking foods with high fat and sugar content. Also, the preheating time specified in the dish instruction manual must not be exceeded .MAINTENANCE …………。。………………………………………………….. SERVICING Please check the following before calling for services. 1. - Page 23 2. During servicing below listed parts are liable to be removed and give access to potentials above250V to earth. ● Magnetron ● High voltage transformer ● High voltage capacitor ● High voltage diode ● High voltage fuse 3. The following conditions may cause undue microwave exposure during servicing.
