1. With power disconnected from the receiver, open cover
by loosening the two cover fastening screws and remove
the Eeprom by pulling up as shown.
3. Install the battery and insert Eeprom with the spade
connector to the outside into the programming pin
connector.
820 Lakeside Drive
www.drivecon.com
V:\Production\Radios\PWR\Transmitter programming instructions
PWR RADIO TRANSMITTER
PROGRAMMING INSTRUCTIONS
Gurnee, IL 60031-9165
E-mail: drive.sales@drivecon.com
2. To prevent damage to the transmitter upon
reassembly, turn the key-lock to the 0 or OFF position.
Next remove the cover fastening screws from the bottom.
4. Depress and hold the ON/OFF micro-switch.
Ph: (847) 855-9150
Fax: (847) 855-9650
(800) 374-8266
Advertisement
Table of Contents
Related Manuals for Drivecon PWR
Summary of Contents for Drivecon PWR
- Page 1 PWR RADIO TRANSMITTER PROGRAMMING INSTRUCTIONS 2. To prevent damage to the transmitter upon 1. With power disconnected from the receiver, open cover by loosening the two cover fastening screws and remove reassembly, turn the key-lock to the 0 or OFF position.
- Page 2 6. Return the Eeprom to the receiver, close the cover and reassemble the transmitter. Make sure the keylock is still in the 0 or OFF position as damage to the ON/OFF micro-switch will result if cover is put back on with it in the On position! 5.
