- Page 1 OWNER’S MANUAL MICROWAVE OVEN PLEASE READ THIS OWNER’S MANUAL THOROUGHLY BEFORE OPERATING. MS3040S MS3040SW www.lg.com MFL06331222...
-
Page 2: Precautions
Precautions Precautions to avoid possible exposure to excessive microwave energy. When heating liquids, e.g. soups, sauces and beverages in your microwave You cannot operate your oven with the door open due to the safety interlocks built into the door mechanism. These safety interlocks automatically switch off oven, delayed eruptive boiling can occur without evidence of bubbling. -
Page 3: Table Of Contents
Contents How the Microwave Oven Works Precautions Contents Microwaves are a form of energy similar to radio and television waves and Unpacking & Installing 4 ~ 5 ordinary daylight. Normally, microwaves spread outwards as they travel Setting the Clock through the atmosphere and disappear without effect. Microwave ovens, Child Lock however, have a magnetron which is designed to make use of the energy in microwaves. -
Page 4: Unpacking & Installing 4
Unpacking & By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. Please pay particular attention to the guidance on where to install your oven. When unpacking your Installing oven make sure you remove all accessories and packing. - Page 5 Plug your oven into a standard household socket. Open your oven door by push the BUTTON .. Make sure your oven is the only appliance Place the TURNTABLE ROLLER REST connected to the socket. If your oven does not operate inside the oven and place the GLASS TRAY on top.
-
Page 6: Setting The Clock
Setting the You can set either 12 hour clock or 24 hour clock . Clock In the following example I will show you how to set the time for 14:35 when using the 24 clock. Make sure that you have removed all packaging from your oven. Make sure that you have correctly installed your oven as described earlier in this book. -
Page 7: Child Lock
Child Lock Press STOP/CLEAR . Press STOP/CLEAR . Your oven has a safety feature that Press and hold STOP/CLEAR until “L” appears in the display and BEEP prevents accidental running of the oven. sounds. Once the child lock is set, you will be The CHILD LOCK is now set. -
Page 8: Micro Power Cooking
Micro Power In the following example I will show you how to cook some food on 80% power for 5 minutes and 30 seconds. Cooking Make sure that you have correctly installed your oven as described earlier in this book. Press STOP/CLEAR. -
Page 9: Micro Power Level
Micro Power Your microwave oven is equipped with 5 power levels to give you maximum flexibility and control over cooking. Level The table below shows the examples of food and their recommended cooking power levels for use with this microwave oven. POWER POWER LEVEL POWER LEVEL... -
Page 10: Two Stage Cooking
Two stage In the following example I will show you how to cook some food in two stages. The first stages will cook your food for 11 minutes on HIGH; the second will cook for 35 minutes on 340 power. Cooking Press STOP/CLEAR. -
Page 11: Quick Start
Quick In the following example I will show you how to set 2 minutes of cooking on high power. Start Press STOP/CLEAR . The QUICK START feature allows you to Press START four times to select 2 minutes on HIGH power. set 30 seconds intervals of HIGH power Your oven will start before you have finished the fourth press. -
Page 12: Auto Cook 12 ~ 1
Auto In the following examplw i will show ou how to cook 0.6kg of fresh vegetable. Cook Press STOP/CLEAR. twice to select Fresh vegetable. Press AUTO COOK AUTO COOK allows you to cook most of "Ac-2" appears on the display. your favorite food easily by selecting the food type and entering the weight of the food. - Page 13 CATEGORY WEIGHT LIMIT UTENSIL FOOD TEMP. INSTRUCTIONS Choose medium sized potatoes 170 -200g. Room 0.2 kg ~ 1.0 kg 1. Jacket On Glass tray Wash and dry potatoes. Pierce the potatoes several times with fork. Place the potatoes on Potato the glass turntable.
-
Page 14: Auto Defrost 14 ~ 1
Auto In the following example I will show you how to defrost 1.4Kg of frozen poultry. Defrost Press STOP/CLEAR. Weigh the food that you are about to defrost. Be certain to remove any metallic ties or wraps; then place the food in your oven and close the oven door. - Page 15 AUTO WEIGHT DEFROST GUIDE * Food to be defrosted should be in a suitable microwave proof container and place uncovered on the glass turntable. * If necessary, shield small areas of meat or poultry with flat pieces of aluminum foil. This will prevent thin areas becoming warm during defrosting. Ensure the foil does not touch the oven walls.
-
Page 16: Quick Defrost 16 ~ 1
Quick In the following example will show you how to defrost 0.5kg of frozen minced meat. Defrost Press STOP/CLEAR. Weight the food that you are about to defrost. Be certain to remove any metallic ties or wraps; then place the food in your oven and close the oven door. - Page 17 QUICK DEFROST GUIDE Use this function to defrost quickly for minced meet. Remove the meat completely from it’s wrapping. Place the mince onto a microwave-safe plate. When BEEP, at this point remove the mince from the microwave oven, turn the mince over and return to the microwave oven. Press start to continue. At the end of the program remove the mince from the microwave oven, cover with foil and allow to stand 5-15 minutes or until completely thawed.
-
Page 18: Auto Reheat 18
Auto Reheat In the following example I will show you how to cook 0.6kg of Frozen Meal. Press STOP/CLEAR . Auto Reheat cooking make food Press AUTO REHEAT twice to select Frozen Meal. reheating convient and easy to use. The oven has been pre-programmed to “rh-2”... - Page 19 FUNCTION CATEGORY WEIGHT LIMIT UTENSILS FOOD TEMP. INSTRUCTIONS Pierce using a skewer on the surface. Refrigerated 0.3 kg ~ 0.6 kg Own tray AUTO 1. Chilled Place food on the glass turntable. After cooking, allow to standfor 2-3 minutes REHEAT Meal before serving.
-
Page 20: More Or Less Cooking
More or Less In the following example I will show you how to change the preset of AUTO COOK programmes for a longer or Cooking shorter cooking time. Press STOP/CLEAR . If you find that your food is over or Set the required AUTO COOK programme. -
Page 21: Important Safety Instructions 21
Please keep for future reference. Read and follow all instructions before using your oven Important Safety toprevent the risk of fire, electric shock, personal injury, or damage when using the oven. This guide does not cover all possible conditions that may occur. Always contact yourservice Instructions agent or manufacturer about problems that you do not understand. - Page 22 Important Safety Please keep for future reference. Read and follow all instructions before using your oven toprevent the risk of fire, electric shock, personal injury, or damage when using the oven. This guide does not cover all possible conditions that may occur. Always contact yourservice Instructions agent or manufacturer about problems that you do not understand.
- Page 23 Please keep for future reference. Read and follow all instructions before using your oven Important Safety toprevent the risk of fire, electric shock, personal injury, or damage when using the oven. This guide does not cover all possible conditions that may occur. Always contact yourservice Instructions agent or manufacturer about problems that you do not understand.
- Page 24 Important Safety Please keep for future reference. Read and follow all instructions before using your oven toprevent the risk of fire, electric shock, personal injury, or damage when using the oven. Instructions This guide does not cover all possible conditions that may occur. Always contact yourservice agent or manufacturer about problems that you do not understand.
- Page 25 Important Safety Please keep for future reference. Read and follow all instructions before using your oven toprevent the risk of fire, electric shock, personal injury, or damage when using the oven. This guide does not cover all possible conditions that may occur. Always contact yourservice Instructions agent or manufacturer about problems that you do not understand.
-
Page 26: Microwave-Safe Utensils
Microwave-safe Utensils Never use metal or metal trimmed utensils in your Paper microwave oven Paper plates and containers are convenient and safe to use in your microwave oven, Microwaves cannot penetrate metal. They will bounce off any metal object in the provided that the cooking time is short and foods to be cooked are low in fat and oven and cause arcing, an alarming phenomenon that resembles lightning. -
Page 27: Food Characteristics & Microwave Cooking 27 ~ 2
Food characteristics & Microwave cooking Moisture content of food Keeping an eye on things The recipes in the book have been formulated with great care, but your success in Since the heat generated from microwaves tends to evaporate moisture, relatively dry food such as roasts and some vegetables should either be sprinkled with water prior to cooking preparing them depends on how much attention you pay to the food as it cooks. - Page 28 Food characteristics & Microwave cooking To Clean Your Oven Stirring Stirring is one of the most important of all microwaving techniques. In conventional cooking, food is stirred for the purpose of blending. Microwaved food, however, is stirred in order to spread and redistribute heat.
-
Page 29: Questions & Answers
Questions & Answers Q What’s wrong when the oven light will not glow? Q Is it possible to pop corn in a microwave oven? A There may be several reasons why the oven light will not glow. A Yes, if using one of the two methods described Light bulb has blown below Door is not closed... -
Page 30: Plug Wiring Information/Technical Specifications
Plug wiring information/ Technical Specifications Warning Technical Specification This appliance must be earthed The wires in this mains lead are colored in accordance with the MS3040S/MS3040SW following codes BLUE ~ Neutral Power Input 230V AC / 50Hz BROWN ~ Live GREEN &...
