MICROWAVE OVEN
SERVICE MANUAL
MODEL: MS-304W
MS-304WB
MS-304WG
MS-304WS
CAUTION
BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
