Summary of Contents for Biostar P4TGT

  • Page 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    CPU Installation ... 4 DDR DIMM Modules: DDR1-2 ... 5 Jumpers, Headers, Connectors & Slots ... 6 ESPAÑOL ... 12 Características del P4TGT ... 12 Contenido del Paquete... 13 Disposición del P4TGT ... 14 Instalación de la CPU ... 15 Módulos DDR DIMM: DDR1-2 ...
  • Page 3: English

    English P4TGT Features Use Intel 845GE/ ICH4 Chipset, ITE IT8712. Contains on board I/O facilities, which include one serial port, one VGA port, a parallel port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB ports and a game port.
  • Page 4: Package Contents

    Support SPDIF-Out. Supports Hardware Audio 6CH Audio (Optional). Line-in phone-jack share with rear out . Mic-in phone-jack share with Bass and Center. Package contents HDD Cable X 1 FDD Cable X 1 Fully Setup Driver CD X 1 USB Cable X 2 (Optional)
  • Page 5: Layout Of P4Tgt

    Layout of P4TGT JKBMS1 JKBV1 & Mouse JATXPWR2 JUSB1 JUSBV1 JCOM1 JPRNT1 JVGA1 JGAME1 INTEL 845GE JSPDIF_OUT JATXPWR1 JCDIN1 AGP1 JAUDIO1 PCI1 Codec (optional) JUSBV2_3 PCI2 PCI3 AUDIO Chip (optional) PCI4 BAT1 PCI5 BIOS CNR1 JCFAN1 JUSB2 INTEL ICH4 JCMOS1...
  • Page 6: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU.
  • Page 7: Ddr Dimm Modules: Ddr1-2

    DDR DIMM Modules: DDR1-2 Supports DDR200/266/333 unregistered 184-pin non-ECC DDR SDRAM DIMMs. Does not support double-size x16 DDR DIMMs. DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin) DIMM Socket DDR Module Location DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB * The list shown above for DRAM configuration is only for reference.
  • Page 8: Jumpers, Headers, Connectors & Slots

    3D graphics. Peripheral Component Interconnect Slots: PCI1-5 This motherboard is equipped with 5 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards, which has, supplanted the older ISA bus standard in...
  • Page 9 Power Connectors: JATXPWR1/ JATXPWR2 JATXPWR2 (ATX 12V Power Conn.) (ATX Main Power Conn.) (ATX Main Power Conn.) Wake On LAN Header: JWOL1 Ground 5V_SB Wake up WOL1 Front USB Header: JUSB2/ JUSB3 Pin1,2 ==> +5V Pin3,4 ==> Data(-) Pin5,6 ==> Data(+) Pin7,8 ==>...
  • Page 10 5V/ 5VSB Selection for USB: JUSBV1/2_3 Pin 1-2 on ==> 5V Pin 2-3 on ==> 5V_SB JUSBV1/2_3 5V/ 5VSB Selection for KB: JKBV1 Pin 1-2 on ==> 5V Pin 2-3 on ==> 5V_SB JKBV1 Chassis Open Detection input: JCL1 Ground Intruder JCL1 Audio Subsystem: JAUDIO1/ JCDIN1...
  • Page 11 Pin1 ==> Mic In Pin3 ==> Mic Power Pin5 ==> RT Line Out Pin7 ==> Reserved Pin9 ==> LFT Line Out Pin10 ==> LFT Line Out Pin11==> RT Line In Pin13 ==> LFT Line In Digital Audio Connector: JSPDIF_OUT Pin1 ==> 5V Pin2 ==>...
  • Page 12 Front Panel Connector: JPANEL1 PWR_LED (+) (-) HLED ==> Speaker Conn. HLED ==> Hard Driver LED ==> Reset Button ==> Infrared Conn. ==> Sleep Button PWR_LED ==> Power LED ON/ OFF ==> Power-on Button Back Panel Connectors JKBMS1 JPRNT1 PS/2 Mouse PS/2 COM1...
  • Page 13 4 Ch an nel Speakers Speaker Out Line In/ Mic In Speaker Out Rear Speaker 6 Ch an n el Speakers Line In/ Mic In/ Center & Bass Rear Speaker...
  • Page 14: Español

    Español Características del P4TGT Usa Chipset Intel 845GE/ ICH4, ITE IT8712. Contiene facilidades I/O integrados en la placa madre en el que incluye un puerto en serie, un puerto VGA, un puerto paralelo, un puerto para ratón PS/2, un puerto para teclado PS/2, puertos de audio, puertos USB y un puerto de juego .
  • Page 15: Contenido Del Paquete

    Alto S/N ratio para requerimientos PC 99. 6CH de Salida de Audio, aplicable para chipsets de principales placas madres. Soporta SPDIF_Out. Soporta 6CH de harware audio (opcional). Entrada de Línea phone-jack compartido con el rear out. Micrófono phone-jack compartido con Bass y Center. Contenido del Paquete Cable HDD X 1 Cable FDD X 1...
  • Page 16: Disposición Del P4Tgt

    Disposición del P4TGT JKBMS1 Teclado JKBV1 & Raton JATXPWR2 JUSB1 JUSBV1 JCOM1 JPRNT1 JVGA1 JGAME1 INTEL 845GE JSPDIF_OUT JATXPWR1 JCDIN1 AGP1 JAUDIO1 PCI1 Codec (opcional) JUSBV2_3 PCI2 PCI3 AUDIO Chip (opcional) PCI4 BAT1 PCI5 BIOS CNR1 JCFAN1 JUSB2 INTEL ICH4...
  • Page 17: Instalación De La Cpu

    Instalación de la CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU.
  • Page 18: Módulos Ddr Dimm: Ddr1-2

    Módulos DDR DIMM: DDR1-2 Soporta DDR200/266/333 unregistered 184-contactos sin ECC DDR SDRAM DIMMs. No soporta DDR DIMMs x16 de doble cara. DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulos DIMM (184 contactos) Localización Módulo DDR del Zócalo DIMM DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB...
  • Page 19: Puentes, Cabezales, Conectores Y Ranuras

    Puentes, Cabezales, Conectores y Ranuras Conectores del Disco Duro: IDE1/ IDE2 La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalidad Ultra DMA / 33/ 66/ 100. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). El conector IDE puede conectar a un master y un drive esclavo, así...
  • Page 20 Conectores de Corriente: JATXPWR1/ JATXPWR2 JATXPWR2 (ATX 12V Conector de Corriente) (ATX Conector de Corriente Principal) Cabezal Wake On LAN: JWOL1 Tierra 5V_SB Wake up WOL1 Cabezal Frontal USB: JUSB2/ JUSB3 Contacto1,2 ==> +5V Contacto3,4 ==> Dato(-) Contacto5,6 ==> Dato(+) Contacto7,8 ==>...
  • Page 21 5V/ 5VSB Selección para USB: JUSBV1/2_3 Contacto 1-2 on ==> 5V Contacto 2-3 on ==> 5V_SB JUSBV1/2_3 5V/ 5VSB Selección para KB: JKBV1 Contacto 1-2 on ==> 5V Contacto 2-3 on ==> 5V_SB JKBV1 Chassis Open Detection Input: JCL1 Tierra Intruder JCL1 Subsistema de Audio: JAUDIO1/ JCDIN1...
  • Page 22 Pin1 ==> Entrada del Mic Pin3 ==> Corriente del Mic Pin5 ==> RT Salida de Linea Pin7 ==> Reservado Pin9 ==> LFT Salida de Linea Pin11 ==> RT Entrada de Linea Pin12 ==> RT Entrada de Linea Pin13 ==> LFT Entrada de Linea Pin14 ==> LFT Entrada de Linea Conector de Audio Digital: JSPDIF_OUT Pin1 ==>...
  • Page 23 Conector del Panel Frontal: JPANEL1 PWR_LED (+) (-) HLED ==> Conector de Altavoz HLED ==> LED del Disco Duro ==> Boton de Reinicio ==> Conector Infrarojo ==> Boton de Suspension PWR_LED ==> Corriente LED ON/ OFF ==> Boton de Encendido Conectores del Panel Trasero JKBMS1 JPRNT1...
  • Page 24 Altavoz de 4 Canales Salida del Altavoz Entrada de Entrada Salida del Linea/ del Mic Altavoz Rear Speaker Altavoz de 6 Canales Entrada Entrada del Mic/ de Linea/ Center & Bass Rear Speaker...
  • Page 25: Warpspeeder

    WarpSpeeder Introduction [ WarpSpeeder™ ], a new powerful control utility, features three user-friendly functions including Overclock Manager, Overvoltage Manager, and Hardware Monitor. With the Overclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU performance with just one click. The Overvoltage Manager, on the other hand, helps to power up CPU core voltage and Memory voltage.
  • Page 26: System Requirement

    System Requirement OS Support: Windows 98 SE, Windows Me, Windows 2000, Windows XP DirectX: DirectX 8.1 or above. (The Windows XP operating system includes DirectX 8.1. If you use Windows XP, you do not need to install DirectX 8.1.) Installation Execute the setup execution file, and then the following dialog will pop up.
  • Page 27 When you see the following dialog in setup procedure, it means setup is completed. If the “Launch the WarpSpeeder Tray Utility” checkbox is checked, the Tray Icon utility and [ WarpSpeeder™ ] utility will be automatically and immediately launched after you click “Finish”...
  • Page 28: Usage

    Usage The following figures are just only for reference, the screen printed in this usr manual will change according to your motherboard on hand. [ WarpSpeeder™ ] includes 1 tray icon and 5 panels: 1. Tray Icon: Whenever the Tray Icon utility is launched, it will display a little tray icon on the right side of Windows Taskbar.
  • Page 29 2. Main Panel If you click the tray icon, [ WarpSpeeder™ ] utility will be invoked. Please refer do the following figure; the utility’s first window you will see is Main Panel. Main Panel contains features as follows: a. Display the CPU Speed, CPU external clock, Memory clock, AGP clock, and PCI clock information.
  • Page 30 3. Voltage Panel Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide out to up as the following figure. In this panel, you can decide to increase CPU core voltage and Memory voltage or not.
  • Page 31 4. Overclock Panel Click the Overclock button in Main Panel, the button will be highlighted and the Overclock Panel will slide out to left as the following figure. Overclock Panel contains the these features: a. “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user the ability to do real-time overclock adjustment.
  • Page 32 “Verify button”: User can click this button and [ WarpSpeeder™ ] will proceed a testing for current frequency. If the testing is ok, then the current frequency will be saved into system registry. If the testing fail, system will do a fail-safe rebooting. After reboot, the [ WarpSpeeder™ ] utility will restore to the hardware default setting or load the verified best and stable frequency according to the Recovery Dialog’s setting.
  • Page 33 5. Hardware Monitor Panel Click the Hardware Monitor button in Main Panel, the button will be highlighted and the Hardware Monitor panel will slide out to left as the following figure. In this panel, you can get the real-time status information of your system. The information will be refreshed every 1 second.
  • Page 35 Note: Because the overclock, overvoltage, and hardware monitor features controlled [ WarpSpeeder™ ] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels’ functions. This property can make [ WarpSpeeder™...
  • Page 36: Trouble Shooting

    Trouble Shooting PROBABLE CAUSE No power to the system at all Power light don’t illuminate, fan inside power supply does not turn on. Indicator light on keyboard does not turn on PROBABLE CAUSE System inoperative. Keyboard lights are on, power indicator lights are lit, hard drive is spinning.
  • Page 37: Solución De Problemas

    Solución de Problemas CAUSA PROBABLE No hay corriente en el sistema. La luz de corriente no ilumina, ventilador dentro de la fuente de alimentación apagada. Indicador de luz del teclado apagado. CAUSA PROBABLE Sistema inoperativo. Luz del teclado encendido, luz de indicador de corriente iluminado, disco rígido está...
  • Page 38 10/16/2002...
