Intelix AVO-A4-WP Installation Manual

Specifications
Specifications subject to change without notice.
Maximum Distance* 2,500 feet
Bandwidth 20 Hz to 20 kHz
600 ohms, balanced
Impedance
Isolation 500 V
Nominal Level 1.0 volts
Insertion Loss 1 dB
Common Mode Rejection Greater than 40 dB
Unshielded Twisted Pair Maximum capacitance: 20 pf/foot
Cabling Specifications Impedance: 100 ohms @ 1 MHz
(24 gauge or lower solid Attenuation: 6.6 dB/1000 ft. @ 1 MHz
copper) Cat 3, Cat 5, Cat 5e, Cat 6, Cat 7 compatible
Connectors Four (4) female RCA to one (1) RJ45
RJ45 Pinout Channel 1 (L): 4 & 5, pair 1
Channel 1 (R): 1 & 2, pair 2
Channel 2 (L): 3 & 6, pair 3
Channel 2 (R): 7 & 8, pair 4
Temperature Operating: 32 to 131 F (0 to 55 C)
Storage: -4 to 185 F (-20 to 85 C)
Humidity: up to 95%
Enclosure Front: standard decora-style wallplate
Rear: metal
4.0" x 1.4" x 1.7"
Dimensions
We i g h t 0.2 lbs (3.2 oz.)
Ordering Information AVO-A4-WP: single AVO-A4-WP balun in bulk packaging
Warranty 2 years
* Distances and picture quality may be affected by cable grade, cable quality, source and
destination equipment, RF and electrical interference, and cable patches. Intelix specifications are
based on straight-through cabling with standard-grade Cat 5.
Contact Information
Intelix
2222 Pleasant View Road
Middleton, WI 53562
Toll-free: 866-4-MATMIX
Phone: 608-831-0880
Fax: 608-831-1833
www.intelix.com
AvoCat
Intelix AVO-A4-WP Stereo Audio Balun
Ins Ins Ins Ins Inst t t t t allation Manual allation Manual allation Manual allation Manual allation Manual
The Intelix AVO-A4-WP wallplate balun transmits four mono or two stereo analog
audio signals via standard structured cabling, such as Cat 5. Used in pairs or with
the Intelix AVO-A4 rack-mountable balun, the AVO-A4-WP transmit analog audio
in either direction up to 2,500 feet and is ideal for corporate A/V, churches, schools,
auditoriums, and almost any other situation involving audio distribution.
The Intelix AvoCat Series of baluns is the ideal solution for sending audio and
video over structured cabling. When signal quality matters, choose Intelix.
Installation
Caution: Do not attempt to disassemble or alter the balun housing. There are
no user-serviceable parts inside the AVO-A4-WP. Modifying the unit
will void your warranty.
To install an AVO-A2-WP balun, perform the following steps:
1. Turn off power and disconnect the audio equipment by following the
manufacturer's instructions.
2. Make certain that outlets and cross connects to which you will connect the AVO-
A4-WP are configured properly and labeled appropriately to identify the circuit.
Caution: Do not connect the AVO-A4-WP to a telecommunication outlet
wired to unrelated equipment. Making such a connection may damage
the equipment and/or balun. Please ensure all wiring is "straight-
through."
3. Verify the desired twisted pairs are not being used for other LAN or telephony
equipment.
4. Connect the RCA outputs from the source equipment to the AVO-A4-WP.
Connect the RCA inputs from the receive device to a second AVO-A4-WP or
another compatible Intelix balun, such as the AVO-A4.
Caution: Do not mount the balun over equipment ventilation openings.
Covering the openings may cause the equipment to overheat.
5. Connect the two baluns with a structured cable with RJ45 connectors, such as
Cat 5. Verify the cable's pinout conforms to EIA/TIA 568A or 568B pattern
standards.
6. Power on the source and destination equipment and test for correct operation.
