Intelix AVO-V1-WP Installation Manual

Specifications

Specifications subject to change without notice.
Maximum Distance* 2,200 feet
Maximum Video Input 1.1 Vp-p
Bandwidth (video) DC to 8 MHz
Impedance (video) 75 ohms
Insertion Loss Less than 2 dB per pair over the frequency range from
DC to 8 MHz
Return Loss Greater than 15 dB over the frequency range from DC to
8 MHz
Common Mode Rejection Greater than 40 dB @ 8 MHz
Unshielded Twisted Pair Maximum capacitance: 20 pf/foot
Cabling Specifications Impedance: 100 ohms @ 1 MHz
(24 gauge or lower solid Attenuation: 6.6 dB/1000 ft. @ 1 MHz
copper) Cat 3, Cat 5, Cat 5e, Cat 6, Cat 7 compatible
Connectors One (1) female RCA to one (1) RJ45
Pinout 7 & 8, pair 4
Temperature Operating: 32 to 131 F (0 to 55 C)
Storage: -4 to 185 F (-20 to 85 C)
Humidity: up to 95%
Enclosure Front: standard decora-style wallplate
Rear: metal
Dimensions 4.0" x 1.4" x 1.7"
Ordering Information AVO-V1-WP: single AVO-V1-WP balun in bulk
packaging
Warranty 2 years
* Distances and picture quality may be affected by cable grade, cable quality, source and
destination equipment, RF and electrical interference, and cable patches. Intelix specifications are
based on straight-through cabling with standard-grade Cat 5.
Contact Information
Intelix
2222 Pleasant View Road
Middleton, WI 53562
Toll-free: 866-4-MATMIX
Phone: 608-831-0880
Fax: 608-831-1833
www.intelix.com
AvoCat
Intelix AVO-V1-WP Video Balun
Ins Ins Inst t t t t allation Manual allation Manual allation Manual
Ins Ins allation Manual allation Manual
The Intelix AVO-V1-WP wallplate balun transmits one composite video signal over stan-
dard structured cabling, such as Cat 5. Used in pairs or with a rack-mountable Intelix AVO-
V1 balun, AVO-V1-WP baluns replace bulky coaxial video cable and transmit a video
signal up to 2,200 feet.
The Intelix AvoCat Series of baluns is the ideal solution for sending video over structured
cabling. When signal quality matters, choose Intelix.

Installation

Caution: Do not attempt to disassemple or alter the balun housing. There are
no user-serviceable parts inside the AVO-V1-WP. Modifying the unit
will void your warranty.
To install an AVO-V1-WP balun, perform the following steps:
1. Turn off power and disconnect the video equipment by following the manufacturer's
instructions.
2. Run your unshielded twisted pair cabling, such as Cat 5.
3. The AVO-V1-WP balun works in pairs or with other compatible Intelix baluns,
such as the AVO-V1 rack-mountable balun. Connect the AVO-V1-WP balun to the
source device with a composite video cable.
Caution: Do not connect the AVO-V1-WP to a telecommunication outlet
wired to unrelated equipment. Making such a connection may damage
the equipment and/or balun. Please ensure all wiring is "straight-
through."
4. Connect a second AVO-V1-WP or compatible balun to the destination device.
5. Connect a structured cable, such as Cat 5, to each RJ45 connector of the baluns.
Verify the pinout on the connector conforms to the EIA/TIA 568A or 568B
pattern standards.
Caution: Do not mount the balun over equipment ventilation openings. Covering the
openings may cause the equipment to overheat.
6. Power-on the video equipment and check the picture quality. The video should be
clear and sharp within the maximum specified distances.
