USER'S MANUAL
DC REGULATED POWER SUPPLY
DC POWER SUPPLY
BRIEF INTRODUCTION:
The HY3000 and HY5000 series variable DC power supplies are very stable, regulated DC power
supplies allowing continuous adjustment of both the output voltage and output current levels.
The HY3000 and HY5000 series have LED displays, the HY3000C and HY5000C have analogue
displays and the HY3000D and HY5000D series have LCD displays.
MODELS:
HY3002
MODEL HY3002C
HY3002D
REGULATED
OUTPUT VOLTAGE
REGULATED
OUTPUT CURRENT

1. TECHNICAL PARAMETERS

1.1 Input voltage :

1.2 Line regulation:

1.3 Load regulation:

HY3003 HY3005
HY3003C HY3005C
HY3003D HY3005D
0-30V 0-30V
0-2A 0-3A
104~127V AC (60Hz), or 207~253V AC (50Hz)
CV≤0.01%+1mV
CV≤0.01%+3mV(I≤3A)
CV≤0.01%+5mV(I>3A)
HY3006 HY5002
HY3006C HY5002C
HY3006D HY5002D
0-30V 0-30V
0-5A 0-6A
CC≤0.2%+1mA
CC≤0.2%+3mA(I≤3A)
CC≤0.2%+5mA(I>3A)
- -
1
HY5003 HY6003E
HY5003C HY6003C
HY5003D HY6003D
0-50V 0-50V
0-2A 0-3A
0-60V
0-3A
