Digital Multimedia Projector
Model name
PalmPro 7763P/65PE
OPERATING GUIDE
Thank you very much for purchasing this Acer DLP™ Technology Projector.
Please read this operating guide to ensure correct use of the device. After reading this
manual, keep it for future reference.
Outline
This DLP™ Technology
various computer signals and NTSC/PAL/SECAM
video signals.
Features
(1)
High brightness
(2)
High resolution
(3)
Compact size, light weight for portability
(4)
RGB output terminal
(5)
RS232 Communication
(6)
Mouse emulation
(7)
Complies with VESA DDC1/2B specifications
Projector can display
English I
Advertisement
Table of Contents
Related Manuals for Acer PalmPro 7763P
Summary of Contents for Acer PalmPro 7763P
-
Page 1: Operating Guide
Digital Multimedia Projector Model name PalmPro 7763P/65PE OPERATING GUIDE Thank you very much for purchasing this Acer DLP™ Technology Projector. Please read this operating guide to ensure correct use of the device. After reading this manual, keep it for future reference. -
Page 2: Monitor Information
Copyright Copyright © 2000 by this company. All rights reserved. No part of this publication reproduced, transmitted, translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of this company. - Page 3 5. Do not place this product on an unstable cart, stand, or table. fall, causing serious damage to the product. 6. The Standard Remote Control contains a low-power laser that acts as a pointing device during presentations. directly into a person’s eyes. 7.
-
Page 4: Table Of Contents
Table of Contents Introduction ... 1 Projector Features ... Description ... 2 A FRONT (figure) ... 2 B REAR (figure) ... 2 C BOTTOM (figure) ... 3 Installation ... 3 Positioning ... 3 Adjustable Feet ... 4 Moving the Projector ... 4 Accessories ... -
Page 5: Introduction
Introduction Projector Features Image Resolution Fully compatible with true SVGA(63P)/XGA(65PE), and supports SXGA using advanced intelligent intelligent compression compression SVGA/XGA images without line omission. Brightness Provides superior brightness of 700 ANSI lumens using TI’s Digital Micromirror Device (DMD) and our own optical design, with a geometric effect that increases light usage efficiency. -
Page 6: Description
Ceiling Mount and Rear Screen Projection The projector is equipped with a full mirror scan conversion function (vertical/horizontal mirror), which allows the image to be reversed for ceiling mounting as well as for rear projection applications. AV box An AV box is optional, and users can attach one or two to the projector. -
Page 7: C Bottom (Figure)
Figure 2 Rear view of 7763P/65PE C BOTTOM (figure) Figure 3 Bottom view of 7763P/65PE Installation Positioning • This projector is basically designed to project on a flat projection surface. • This projector can be focused from 1.5m–14m. • Refer to the figure below to adjust the screen size. English 3... -
Page 8: Adjustable Feet
Figure 4 Positioning of 7763P/65PE B. Adjustable Feet Picture tilt and projection angle can be adjusted by twisting Adjustable Feet. Projection angle can be adjusted 2° to 8.5° degrees by rotating Adjustable Feet. Figure 5 Adjustable feet Moving the Projector Use the carrying handle when moving the projector. -
Page 9: Accessories
Figure 6 Moving the projector Accessories Please check and make sure your box contains everything listed below. If any pieces are missing, contact your dealer. Please save the original box and packing materials in case you ever need to ship the unit. English 5... - Page 10 Figure 7 Accessories of 7763P/65PE English 6...
-
Page 11: Connection
Connection Connecting the Projector to Computer/Notebook Figure 8 Connection to PC Figure 9 Connection to notebook English 7... -
Page 12: B Connecting The Projector To Macintosh/Power Book
B Connecting the Projector to Macintosh/Power Book Figure 10 Connection to Macintosh Figure 11 Connection to Power Book English 8... -
Page 13: Operation
Operation Turn On/Off Procedure Power on Press the Standby/On key to turn on the lamp. The LED will blink green during warm up and then light solid green. "INPUT SIGNAL DETECTED, ACTIVATING AUTO IMAGE" will be displayed on the screen after the projector has identified the input signal; “SEARCHING“... - Page 14 MAIN UNIT To call the OSD menu. Menu To enter sub pages. To select items. To navigate through sub pages or to increase the scale bar number. To navigate through sub pages or to decrease the scale bar number. To exit from the current page or OSD menu, and Exit save setting changes.
-
Page 15: Remote Control
Remote Control Figure 13 Remote control The remote control allows you to operate the function keys on the projector connected to a computer. Main Unit To turn the projection lamp on and off. Standby/On Pressing Freeze picture. Pressing this button partially magnifies a displayed Magnify picture. -
Page 16: Usage And Replacement Of Lamp
Be sure to follow instructions in placing batteries into the remote control units. • Push and slide the lid in the direction of the arrow. • Install two ’AAA’ batteries as indicated inside the battery compartment. • Replace the lid and snap into place. Caution •... -
Page 17: A Lamp/Temperature Status Led Indicator
The picture will become dark or the color will fade after the lamp has been used for a long time. In such cases, continued use of the lamp could cause a malfunction. Replace the lamp with a new one. A Lamp/temperature Status LED Indicator 1. -
Page 18: B Replacing The Lamp
Figure 17 Lamp replacement warning signal II replacement warning signal II 2. Lamp is not well attached blinks attached properly. 3. Temperature is too high projector’s safely, the LED will blink slowly for one minute and then the lamp will turn off automatically. 4. - Page 19 iii. Loosen the screw and pull the handle to remove the lamp. • If the screw is not loosened completely, you could hurt your fingers. • Do not insert your hand into the box after the lamp has been removed. (There are optical parts inside that, if touched, could result in color unevenness, etc.) Replace the lamp with a new one and fix it using the same screw.
- Page 20 Lamp Replacement Procedure Step 1 Step 2 Step 3 Lamp replacement Figure 19 : Step 1, Step 2, Step 3 English 16...
-
Page 21: Osd
Resetting Lamp Timer If replacing the lamp after 1500 hours of operation, please carry out the following operation within 10 minutes of powering on. Main OSD Menu Press the “Menu” key and the main OSD menu structure will appear as shown at right (Fig. -
Page 22: A Display Page
Input PC input without AV box status Subpage Display Image Control A Display Page When a PC is the input source, there will be only four items on this page: Keystone, Brightness, Contrast, and Color Balance (Fig. 21). On the other hand, when the input source are video, S-video, TV or CATV, there will... -
Page 23: B Image Page
Sharpnes (Soft) Image Page Select the Image sub-page and the first item, “Auto Resize” will be highlighted. There are five items on this page: Auto Resize, H. Phase, H. Size, H. Position, and V. Position (Fig. 23). If AV box is attached and the input is from Video other instead of another different System ,Color and Tint will come out as figure 24. -
Page 24: C Control Page
H.Posit (move (move the image right) The Auto Image should be turned off to activate the H. Position item. Position adjustments are saved when the projector is power off. (move (move the image up) Positio Position adjustments are saved when the projector is power off. -
Page 25: D Source Page
Mirror To select Normal projection, H-Invert projection, V- Invert projection, or H/V Invert projection. To select the background color when the image/sound is Blank blanked. To set the time to turn the power off after the start up Auto Off screen is displayed and no signal is detected or sync is out of range. -
Page 26: Other Correspondent Remote Functions And Messages
Other Correspondent Remote Functions and Messages Source Freeze Mute Volume Magnify Laser Disk Pad English 22 FUNCTION The selected source will be displayed at the bottom right of the screen for 3 seconds after selecting the source. (PC, VIDEO, S-VIDEO). image will “Freeze”... - Page 27 (Macintosh/ Powerbook) mouse. When an image has been magnified, press the “Disk Pad” button to move around the display area (the mouse function is not available when magnify function is on). This button is a toggle switch to turn on/off the drag function of the remote Drag mouse.
-
Page 28: Maintenance And Troubleshooting
Maintenance Troubleshooting Lamp Replacement Refer to Page 11 Cleaning the Lens Follow these steps to clean the projection lens: 1. Apply non-abrasive cleaning cloth (abrasive cleaners, solvents or other harsh chemicals might scratch the lens). 2. Avoid using an excessive amount of cleaner. 3. - Page 29 Stand within 4 meters (13 feet) of the unit. Make sure nothing is blocking the receiver on the control pad. Check audio cable connection from audio input source. Adjust audio source. NO SOUND Press “Volume” (+) button. Press “Mute” button. English 25...
-
Page 30: Specifications
Specifications Optical 1-chip 0.7” DMD Lens Manual zoom ,manual focus (F=2.8 to 3.1 Lamp mercury lamp 150W Image size 25” to 300” Projection Distance Light Output 800 ANSI Contrast Ratio 450:1 Electrical Inputs RGB(H:31.47 to 68.70 kHz Video (NTSC/PAL/SECAM/NTSC 4.43) Color Reproduction Power Requirement 100 to 240 VAC, 50 to 60 Hz Mechanical... -
Page 31: D Preset Display Resolution Table
D Preset Display Resolution Table Resolution H Sync (kHz) 640x350 640x400 720x400 720x400 640x480 640x480 640x480 640x480 800x600 800x600 800x600 800x600 800x600 832x624 1024x768 1024x768 1024x768 1024x768 1280x1024 V Sync (kHz) 31.5 70.1 37.9 85.1 31.5 70.0 37.9 85.1 31.5 60.0 37.9 72.8... -
Page 32: Appendix
Guideline to Acer 7763P/65PE AV box 1. Features and Connection AV Connection Port This box is compatible with RCA input, S-Video input, audio output . Figure 27 Connection of AV box Speaker RCA Jack S Video Port Phone Jack *AV box is sold separately and is not included in the standard configuration of accessories in the unit. -
Page 33: Connecting The Box
Connecting the Box Please follow the instruction here to place the AV box: Figure 28 Bottom View of To attach the AV box to the unit： A/V function. 4. Select inputs by pressing “Source” key, and select channel by the Figure30 Connecting the Box Figure 29 Side View of AV box...
