- Page 1 Portable Evaporative Air Cooler User Manual Read and save these instructions before use Model: TC30PE/ TC30PCE/ TC30PEU/ TC50PE/ TC50PCE/ TC50PEU...
-
Page 2: Parts Description
PARTS DESCRIPTION Control Panel Rear Grill & Mesh Filter Louvers Honeycomb Cooling Media Water Level Indicator Water Fill Door Casters Power Cord & Plug Handle & Remote Control Drain Plug Storage Remote Control Water Inlet Valve* WARNING -- READ AND SAVE THE AIR COOLER SAFETY & MAINTENANCE GUIDE AND USER MANUAL BEFORE USING THIS PRODUCT. -
Page 3: Use And Operation
USE & OPERATION CONTROL PANEL Icons on Display Screen Power Speed Swing = Low Cool = Medium = High... -
Page 4: Function Buttons
USE & OPERATION (CONTINUED) FUNCTION BUTTONS POWER Press the button to turn the unit on. The cooler will start automatically at medium speed. After a few seconds the speed will switch to low. To turn the unit off, press the button again. COOL You must add water before operating the unit in Cool mode. -
Page 5: Remote Control
USE & OPERATION (CONTINUED) REMOTE CONTROL POWER : ON / OFF SPEED Low / Medium / High COOL Evaporative Cooling ON / OFF SWING Controls the motion of the louvers NOTE: • The remote control requires a CR2025 (1 x 3V) coin type or equivalent battery for replacement. Open the battery compartment at the back of the remote control and insert the battery inside. -
Page 6: Cooler Location
USE & OPERATION (CONTINUED) COOLER LOCATION Make sure to position the air cooler correctly before you set up and start using the product. Please refer to the COOLER LOCATION section of the separate Safety & Maintenance Guide. FILLING WITH WATER It is ideal to use the Continuous Water Supply* Connection to run the unit for long periods of time without refilling the tank. - Page 7 USE & OPERATION (CONTINUED) FILLING WITH WATER (CONTINUED) The Water Level Indicator is located at the back of the unit. Refill the water tank when water level is low. Do not fill water above the "Max." water level mark to avoid water droplets collecting on the louvers.
- Page 8 USE & OPERATION (CONTINUED) LOW WATER ALARM* The unit is equipped with a low water sensor. In Cooling Mode, when water in the tank is below the minimum level, you will hear a beeping sound and the indicator light will flash continuously. The unit will automatically pause evaporative cooling.
- Page 9 USE & OPERATION (CONTINUED) CLEANING THE MESH FILTER AND HONEYCOMB COOLING MEDIA WARNING: Before cleaning the unit, switch the unit OFF and disconnect the power adapter from the unit and electrical socket. • The appliance is supplied with a Mesh Filter and Honeycomb Cooling Media. •...
- Page 10 JMATEK Limited Made in China © 2020 JMATEK Limited. All rights reserved. Rykadan Capital Tower, The Honeywell Trademark is used under license Kwun Tong, Hong Kong from Honeywell International Inc. Honeywell International Inc. makes no representations or warranties with respect to this product.
