Audio Pro Sub Cinema Manual

English

CONTROLS AND INDICATORS

1
2
3
1) Line input
(MONO) from amplifier
2) Speaker Level input
(from amplifier)
3) Speaker Level output
(to satellite speakers)
WARNING !
To reduce the risk of electric shock, do not open or remove cover or back. Do not expose this appliance to rain or moisture. In case of malfunction consult qualified service
personel.
The lightning flash with arrowhead, within an equilateral triangle, is intended to
alert the user of the presence of uninsulated "dangerous voltage" within the
product´s enclosure; that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
6
4) Low pass crossover control
variable 50 - 100Hz
5) Volume control
The exclamation point, within an equilateral triangle, is intended to alert the user of the presence
of important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
4
5
6
7
8
6) Fuse
7) Mains switch
8) Mains cord (230V)
