CONTROLS AND INDICATORS

5
4
3
2
1
6
7
9
8
1) Low level input from
amplifier
(Enclosed Y-adaptor)
2) Standby mode switch-
Auto or ON
WARNING !
To reduce the risk of electric shock, do not open or remove cover or back. Do not expose this appliance to rain or moisture. In case
of malfunction consult qualified service personel.
The lightning flash with arrowhead, within an equilateral
triangle, is intended to alert the user of the presence of
uninsulated "dangerous voltage" within the product´s
enclosure; that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
LEVEL
MIN MAX
LOW PASS
FREQUENCY
50HZ 100HZ
180 0 0
PHASE
ON AUTO
L
LINE IN
R
IN
SPEAKER
R L
LEVEL
OUT
DOUBLE INSULATION - when servicing
use only identical replacement parts.
POWER ON OFF
3) Phase switch 0 - 180
4) Low pass crossover control
5) Volume control
6) Speaker Level input
(from amplifier)
CAUTION
SUB SUPREME
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING:SHOCK HAZARD-DO NOT OPEN.
AC 230V 50Hz 200W AVIS:RISQUE DE CHOC ELECTRIQUE-NE
PAS OUVRIR.
Serial no:
CAUTION:
TO REDUCE THE RISK OF FIRE,
REPLACE WITH ONLY THE SAME
TYPE AND RATING OF FUSE.
ATTENTION:
FUSE TYPE:
UTILISER UN FUSIBLE DE
T1AL 250V FOR 230V RECHANGE DE MEME TYPE.
O
O
The exclamation point, within an equilateral triangle, is intended to alert
the user of the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
6
10
11
7) Speaker Level output
(to satellite speakers)
8) Mains switch
9) ON/OFF indicator
10) Mains cord (230V)
11) Fuse
