Audio Pro Evo Series Sub Evo 10 Instructions

English
CONTROLS AND INDICATORS
5
4
3
2
1
6
7
9
8
1) Low level input from
amplifier
(Enclosed Y-adaptor)
2) Standby mode switch-
Auto or ON
WARNING !
To reduce the risk of electric shock, do not open or remove cover or back. Do not expose this appliance to rain or moisture. In case
of malfunction consult qualified service personel.
The lightning flash with arrowhead, within an equilateral
triangle, is intended to alert the user of the presence of
uninsulated "dangerous voltage" within the product´s
enclosure; that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
O
3) Phase switch 0 - 180
4) Low pass crossover control
5) Volume control
6) Speaker Level input
(from amplifier)
The exclamation point, within an equilateral triangle, is intended to alert
the user of the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
6
O
7) Speaker Level output
(to satellite speakers)
8) Mains switch
9) ON/OFF indicator
10) Mains cord (230V)
11) Fuse
