Capt'n Cook B2612ALP Operator's Manual

Liquid propane and natural gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Liquid Propane Gas (LPG) Grill
Models B2612ALP
Natural Gas (NG ) Grill
Models B2612ANG
FREE HELP
Grill Information Center:
FROM THE GRILL EXPERTS
Grand Hall is the expert on this product
and trained to help you with:
Ÿ
Assembly Questions
Ÿ
Grill Operation
Ÿ
Replacement of Damaged or Missing parts
visit www.grandhall.com or call:
1-877-934-7455
Monday - Friday 8:00am-4:30pm CST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL #
__________________
(see silver CSA label on main body of grill)
Operator's Manual
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Ÿ
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences
and overhangs or sources of ignition including
pilot lights on water heaters and live electrical
appliances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
Ÿ
Never use your gas grill in a garage, porch,
shed, breezeway or any other enclosed area.
Ÿ
Never obstruct the flow of ventilation air
around your gas grill housing.
Ÿ
Never disconnect the gas regulator or any gas
fitting while your grill is lit. A lit grill can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Manual # P80151131A - Date:2012/02/03
!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B2612ALP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Capt'n Cook B2612ALP

Summary of Contents for Capt'n Cook B2612ALP

  • Page 1: Primary Safety Warnings

    Operator's Manual Liquid Propane Gas (LPG) Grill Models B2612ALP Natural Gas (NG ) Grill Models B2612ANG FREE HELP WARNING Grill Information Center: FROM THE GRILL EXPERTS Ÿ Failure to comply with these instructions could Grand Hall is the expert on this product...

  • Page 2: Table Of Contents

    Table of Contents WARNING Primary Safety Warnings......1-3 Pre-Assembly Instructions........3 Do not store or use gasoline or other Part Diagrams and Lists......4-8 flammable liquids or vapors in the Assembly Instructions.........9-15 vicinity of this or any other appli- Use & Care Instructions: ances.

  • Page 3: Pre-Assembly Instructions

    Pre-Assembly Instructions For Your Safety CAUTION PRE-ASSEMBLY Read and perform the following pre-assembly instruc- tions: Failure to comply with these instructions may result Tools Required for Assembly in a hazardous situation which, if not avoided, may • protective work gloves result in injury.

  • Page 4: Part Diagrams And Lists

    Hardware Parts List for Model B2612ALP PART # PART DESCRIPTION PURPOSE OF PART P06030036A Hardware Pack For use in assembly of B2612ALP S182G0306A Pan Head Screw 3/16"x3/8" Install Caster Seats S112G0406A Phillips Head Screw 1/4"x3/8" S142G0306A Countersink Flat Head Screw 3/16"x3/8"...
  • Page 5 Hardware Parts List for Model B2612ANG PART # PART DESCRIPTION PURPOSE OF PART P06030037A Hardware Pack For use in assembly of B2612ANG S182G0306A Pan Head Screw 3/16"x3/8" Install Caster Seats S112G0406A Phillips Head Screw 1/4"x3/8" S142G0306A Countersink Flat Head Screw 3/16"x3/8" Install Door Lower Hinges S112G0306A Phillips Head Screw 3/16"x3/8"...
  • Page 6 Parts Diagram for Models B2612ALP/NG...
  • Page 7 Parts List for Models B2612ALP/NG DESCRIPTION PART# Lid Assembly P001462764 Temperature Gauge P00601071A Lid Hinge P055010204 Lid Handle Bracket, Left P03303124A Lid Handle Bracket, Right P03303125A Lid Handle Heat Insulating Spacer P06802007J Lid Handle P00218001R Protective Pad P055180021I Cooking Rack/Secondary...
  • Page 8 Parts List for Models B2612ALP/NG DESCRIPTION PART# Regulator with Hose (LPG) P03601040A Door Assembly, Right P04303051D Lighting Stick P05313025B Grease Tray P02706404A Grease Tray Handle P0272008H4 Bowl Bracket, Left P01301014D Cart Bracket, Front P03305074J Door Hinge Bracket, Upper Left P03302014J...

  • Page 9: Assembly Instructions

    Assembly Instructions CAUTION : While it is possible for one person to assemble this grill, obtain assistance from another person when handling some of the larger, heavier pieces. Install Caster Seats and Door Lower Hinges Align the holes on the Caster Seats (LF/LR) with the holes on the Left Cart Side Panel. Secure the Caster Seats by tightly securing 4 Phillips Head Screws 1/4’’x3/8’’...
  • Page 10 Install Casters Position the Cart as shown. Install 4 Casters onto the Caster Seats using 16 Phillips Head Screws 1/4’’x3/8’’. Tighten the screws securely as shown. Phillips Head Screw 1/4"x3/8" Qty. 16 Rear Part # S112G0406A Front Install Weight onto Cart Bottom Shelf Position Cart as shown.
  • Page 11 Install Cart Front Bracket, Cart Rear Panel and Tank Holder Assembly (for B2612ALP) Install the Tank Holder Brackets onto the Cart Bottom Shelf using 4 Phillips Head Screws 3/16’’x3/8’’. Secure the Tank Holder Brackets and Screws using 4 Flange Nuts 3/16’’ as shown. Be sure that the flat surfaces of the Tank Holder Brackets are positioned so that they face inwards as shown.
  • Page 12 Qty. 4 Part # S112G0314A Install Grill Head and Hose Holders onto the Cart(for B2612ALP Model) With the help of your assistants, lift the Grill Head onto the top of the Cart so that the bottom of the Grill Head sits on top of the Bowl Brackets.
  • Page 13 Install NG Regulator, Hose Holder, and 12 Foot Hose (for B2612ANG Model) Install the NG Regulator onto the Left Cart Side Panel using 2 Phillips Head Screws 3/16"x1/4". Install the Hose Holder onto the Rear Panel. Secure using 2 Phillips Head Screws 3/16"x3/8" and 2 Flange Nuts 3/16".
  • Page 14 Install Side Shelf Brackets and Side Shelves Attach the Side Shelf Brackets(LF/LR) to the Left Bowl Side Panel. Align the 4 holes on the Side Shelf Brackets (LF/LR) with the 4 threaded holes on the Left Bowl Side Panel. Insert 4 Phillips Head Screws 1/4"x 1/2"...
  • Page 15 Install the Temperature Gauge onto the Install Cooking Components Grill Lid Remove the W ing Nut and Lock W asher Place the Flame Tamer Rack inside the Grill Bowl. from the Temperature Gauge. Insert the Position it onto the lower ledge of the Bowl above Temperature Gauge probe into the hole in the burners.

  • Page 16: Use & Care Instructions

    USE AND CARE INSTRUCTIONS Use of alcohol, prescription or non-prescription drugs CORRECT LP GAS TANK USE can impair your ability to properly assemble and LP Gas grill models are designed for use with a standard safely operate your grill. 20 lb. Liquid Propane Gas (LP Gas) tank (sold sepa- rately).
  • Page 17 USE AND CARE INSTRUCTIONS LP Gas Model only: NOTE about LP Gas Tank Exchange Programs Ÿ Secure a 20lb LP Gas Tank to Gas Grill Many retailers that sell grills offer you the option of replacing your empty LP Gas tank through an exchange Note: Make sure the LP gas tank valve is completely service.
  • Page 18 USE AND CARE INSTRUCTIONS LP Gas Model only: Check all connections for LP Gas Leaks Connect Regulator with Hose to your LP Gas Tank Never test for leaks with an open flame. Prior to first use, at the beginning of each season, or every time Turn all Burner Valves to the OFF position.

  • Page 19: Natural Gas Connection

    Natural Gas Connection Fig.1 Natural Gas Model only: Connecting Natural Gas To Your Grill Connect the Swivel nut of the 12' Natural Gas Hose to the horizontal fitting of NG Regulator Horizontal as shown in Fig.1. Connect the other hose end Fitting (male plug) to the gas supply line from your home.

  • Page 20: Lighting Instructions

    USE AND CARE INSTRUCTIONS Grill Lighting Instructions Before each use, check all hoses for cracks, nicks, cuts, burns or abrasions. If a hose is damaged in any way, do not use your grill before replacing the hose with an authorized part from the Parts List. Also make sure all gas supply connections are securely tightened.

  • Page 21: Troubleshooting

    USE AND CARE INSTRUCTIONS Troubleshooting To purge air from your gas line and/or reset the regulator excess gas flow device: If the grill fails to light : Turn gas off at source and turn Control Knobs to OFF. Wait Turn Control Knobs to the OFF position. at least 5 minutes for gas to clear, then retry.

  • Page 22: Cleaning And Maintenance

    Cleaning Exterior Stainless Steel Surfaces: CLEANING AND MAINTENANCE Routine care and maintenance is required to preserve Proper care and maintenance will keep your grill in top operating the appearance and corrosion resistance of stainless condition and prolong its life. Follow these cleaning procedures on steel.
  • Page 23 2. 2. CLEANING THE BURNER TUBES AND BURNER PORTS Regardless of which Burner cleaning procedure you To reduce the chance of FLASHBACK FIRE you must clean the Burner Tubes as follows at least once a month in summer use, we recommend that you also complete the follow- ing cleaning regimens to help prolong Burner life.
  • Page 24 Cooking Instructions Burn-Off Indirect Cooking using Main Burners Before cooking on your gas grill for the first time, you The indirect cooking method can also be used with the should "burn off" the grill to eliminate any odor or foreign supplied Cooking Grids.
  • Page 25 Guide to Grilling using the Main Burners and Direct Cooking Method Approximate Cooking Times Grilling Steak and Ribs Cut of Meat Rare: 4-8 minutes Turn the grill Burners on Hi, close the Lid and preheat your T-bone steak Medium: 10-14 minutes grill 10 to 15 minutes.
  • Page 26 Guide to Roasting and Baking Using the Main Burners Food preparation An Important Note About Heat Settings Trim meat of excess fat. Truss meat and poultry with cooking The suggested heat settings shown are approximate. There string to retain shape if desired. Bacon strips can be used to are many factors such as outside temperature, wind condi- cover the outside surface of lean meat and poultry to help tions and grill location that affect your grill performance.
  • Page 27 Guide to Smoking Preparing to Smoke Safe Minimum Internal Tem peratures Fish 145ºF/63ºC Smoking gives food a distinctive, delicious flavor. You will find a variety of wood chips available for use in smoking grilled Pork 160ºF/71ºC foods. Pre-soaking of wood chips may be required so read Egg Dishes 160ºF/71ºC and follow the manufacturer's instructions for preparing...
  • Page 28 Question: Question: Can I convert my grill from one fuel type to another in Sometimes I hear a humming sound coming from my other words from LPG to NG or vice versa? regulator. What causes this? And - My grill has a low flame and sometimes will not light.
  • Page 29 Question: The Regulator and Hose supplied with my gas grill After every use (after your grill has cooled down), wipe stain- does not fit the older LP Gas tank I’ve used for years. less surfaces with a soft, soapy cloth or sponge then Why not? rinse with water.
  • Page 30 Grand Hall Limited Warranty Grand Hall will warrant to the ORIGINAL PURCHASER of this gas grill that it will be free of defects in material and workmanship for set periods below from the date of purchase when used under normal outdoor use and correct assembly.
