Liquid Propane Gas (LPG) Grill
Models BCC3B14ALP & BCC5B14ALP
Natural Gas (NG ) Grill
Models BCC3B14ANG & BCC5B14ANG
FREE HELP
Grill Information Center:
FROM THE GRILL EXPERTS
Grand Hall is the expert on this product
and trained to help you with:
Ÿ
Assembly Questions
Ÿ
Grill Operation
Ÿ
Replacement of Damaged or Missing parts
visit www.grandhall.com or call:
1-800-474-5587
Monday - Friday 8:00am-4:30pm PST
IMPORTANT:
Ÿ
NOTE TO ASSEMBLER / INSTALLER:
Leave this manual with the consumer.
Ÿ
NOTE TO CONSUMER:
Keep this manual for future reference.
Ÿ
RECORD YOUR SERIAL #
__________________
(see silver CSA label on back of cart)
BCC3B14ALP/NG
Operator's Manual
WARNING
!
Ÿ
Failure to comply with these instructions could
result in a fire or explosion that could cause
serious bodily injury, death or property damage.
Ÿ
Whether this grill was assembled by you or
someone else, you must read this entire manual
before using your grill to ensure the grill is
properly assembled, installed and maintained.
Ÿ
Use your grill at least 3 feet away from any
wall or surface. Use your grill at least 3 feet
away from combustible objects that can melt or
catch fire such as vinyl or wood siding, fences
and overhangs or sources of ignition including
pilot lights on water heaters and live electrical
appliances.
Ÿ
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
Ÿ
Never use your gas grill in a garage, porch,
shed, breezeway or any other enclosed area.
Ÿ
Never obstruct the flow of ventilation air
around your gas grill housing.
Ÿ
Never disconnect the gas regulator or any gas
fitting while your grill is lit. A lit grill can ignite
leaking gas and cause a fire or explosion which
could result in property damage, personal injury
or death.
Manual #
BCC5B14ALP/NG
P80151139E
-
Date:2014/12/19
!
Advertisement
Table of Contents
Related Manuals for Capt'n Cook BCC3B14ALP
Summary of Contents for Capt'n Cook BCC3B14ALP
-
Page 1: Primary Safety Warnings
Operator's Manual Liquid Propane Gas (LPG) Grill Models BCC3B14ALP & BCC5B14ALP Natural Gas (NG ) Grill Models BCC3B14ANG & BCC5B14ANG BCC3B14ALP/NG BCC5B14ALP/NG FREE HELP WARNING Grill Information Center: FROM THE GRILL EXPERTS Ÿ Failure to comply with these instructions could... -
Page 2: Table Of Contents
Table of Contents WARNING Primary Safety Warnings......1-3 Pre-Assembly Instructions........3 Do not store or use gasoline or other Part Diagrams and Lists......4-10 flammable liquids or vapors in the Assembly Instructions.........11-15 vicinity of this or any other appli- Use & Care Instructions: ances. -
Page 3: Pre-Assembly Instructions
Pre-Assembly Instructions For Your Safety CAUTION PRE-ASSEMBLY Read and perform the following pre-assembly instruc- tions: Failure to comply with these instructions may result Tools Required for Assembly in a hazardous situation which, if not avoided, may • protective work gloves result in injury. -
Page 4: Part Diagrams And Lists
Hardware Parts List for Models BCC3B14ALP/NG & BCC5B14ALP/NG PART # PART DESCRIPTION PURPOSE OF PART For use in assem bly of Captain Cook P06013025B Hardware Pack S112M0615A Phillips Head Screw M6 x 15 Install Casters S411M06161 Plain Washer S431M06091 Spring Washer... - Page 5 Parts Diagram for Models BCC3B14ALP/NG...
- Page 6 Parts List for Model BCC3B14ALP/NG DESCRIPTION PART# Lid Assembly P0014642K4 Temperature Gauge P00601601C Temperature Gauge Seat P00614047E Handle P00205117M Handle Spacer P06801039F Warming Rack P01505033H Cooking Grid W186 P01615061H Grill Bowl P0077115F4 Burner/Main P02003060F Burner Bracket P022034584 Gas Valve/Manifold Assem bly (LPG)
- Page 7 Parts List for Model BCC3B14ALP/NG DESCRIPTION PART# NG Connecting Hose P03705107F NG Regulator P03641006C Hose, 12FT. (NG) 3/8"ID(sold separately) P03721001A Hardware Pack P06013025B Operator's Manual P80151146A...
- Page 8 Parts Diagram for Models BCC5B14ALP/NG 31 30...
- Page 9 Parts List for Models BCC5B14ALP/NG DESCRIPTION PART# Lid Assem bly P0014754K4 Temperature Gauge P00601601C Temperature Gauge Seat P00614047E Handle P00205118M Handle Spacer P06801039F Warming Rack P01507034H Cooking Grid W341 P01615060H Cooking Grid W186 P01615061H Grill Bowl P0077115F4 Burner/Main P02003060F Burner Bracket P022051684 Y0060826 Gas Valve/Manifold Assembly (LPG)
- Page 10 Parts List for Models BCC5B14ALP/NG DESCRIPTION PART# Cart Door, Left Y0410019 Cart Door, Right Y0410020 Handle Spacer P06801039F Door Handle P00205117M Caster Seat P05327072U 3" Caster with Brake P05112032A 3" Caster without Brake P05112033A Cart Reinforced Bracket P03303197K Lighting Stick P05507145M Protective Pad P05518113K...
-
Page 11: Assembly Instructions
Assembly Instructions for BCC3B14ALP/NG & BCC5B14ALP/NG CAUTION : Even though it is possible for one person to install this grill, it is better to obtain assistance from another person when handling the large, heavy pieces. Install Casters Open lid of shipping carton and remove packing materials. Lay a piece of cardboard on the ground. With the help of your assistant, lift and lay the grill on the cardboard carefully as shown. - Page 12 Install Side Burner Gas Valve Assembly and Control Knob Seat Insert Side Burner Gas Valve stem through the hole on the front of the Side burner Frame. Then place the Control Knob Seat over the gas valve stem, aligning the holes on the Knob Seat, Side Burner Frame and Gas Valve Assembly, tighten securely using two (2) M4x12 Phillips Head Screws.
- Page 13 Install Side Burner Accessories Place the Side Burner Head on Side Burner Seat. Make sure the hole on Side Burner Head with the hole on Side Burner Base are aligned. Place the Side Burner Cap over the Side Burner Head. Place the Side Burner Pot Support in mounting holes on the surface of Side Burner Seat.
- Page 14 Install Grease Receptacle Install the Grease Receptacle from the rear of the grill by placing it in the brackets under the grease draining tray as shown. Grease Receptacle Install Ignitor Battery Remove Ignitor Cap from Control Panel. Place supplied AA battery into the Ignitor Slot with positive pole facing you. Install the Cap and Spring over the AA battery and tighten securely.
- Page 15 "clicking" sound. Your assistant should see a blue spark between the Burner and Spark Electrode Tip. If a spark is present the Elec- (for models BCC3B14ALP/NG) trode Tips are properly positioned. If no spark, check the following situation: AA Battery may be installed backwards.
-
Page 16: Use & Care Instructions
Always supervise WIND DIRECTION children and pets if they are in the vicinity of the unit. Use of alcohol, prescription or non-prescription drugs can impair your ability to properly assemble and safely (for BCC3B14ALP/NG & BCC5B14ALP/NG Models) operate your grill. - Page 17 Secure a 20lb LP Gas Tank to Gas Grill Many retailers that sell grills offer you the option of (for Models BCC3B14ALP/NG & BCC5B14ALP/NG) replacing your empty LP Gas tank through an exchange service. Use only those reputable exchange compa-...
- Page 18 Regulator with Hose (LPG) LP Gas Tank (for model BCC3B14ALP) CAUTION: When the appliance is not in use the gas must be turned off at the tank. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap on the cylinder valve outlet that is provided with the cylinder valve.
-
Page 19: Natural Gas Connection
Natural Gas Connection Fig.1 Natural Gas Model only: Connecting Natural Gas To Your Grill Connect the Swivel nut of the 12' Natural Gas Hose to the Vertical fitting of NG Regulator as shown in Fig.1. Connect the other hose end Vertical fitting (male plug) to the gas supply line from your Swivel nut... -
Page 20: Lighting Instructions
Parts List. Also make sure all Main Burner gas supply connections are securely tightened. Familiarize yourself with all Safety and Use and Care (for Models BCC3B14ALP/NG ) instructions in this manual. Do not smoke while lighting your grill or when checking the gas supply connections. -
Page 21: Troubleshooting
USE AND CARE INSTRUCTIONS Troubleshooting To purge air from your gas line and/or reset If the grill fail to light : the regulator excess gas flow device: Turn gas off at source and turn Control Knobs to OFF. Wait at least 5 minutes for gas to clear, then retry. Turn Control Knobs to the OFF position. -
Page 22: Cleaning And Maintenance
GRILL CLEANING AND MAINTENANCE Proper care and maintenance will keep your grill in top operating Cleaning Exterior Stainless Steel Surfaces: condition and prolong its life. Follow these cleaning procedures on Routine care and maintenance is required to preserve a timely basis and your grill will stay clean and operate with the appearance and corrosion resistance of stainless minimum effort. - Page 23 2. 2. CLEANING THE BURNER TUBES AND BURNER PORTS Regardless of which Burner cleaning procedure you To reduce the chance of FLASHBACK FIRE you must clean use, we recommend that you also complete the follow- the Burner Tubes as follows at least once a month in summer ing cleaning regimens to help prolong Burner life.
- Page 24 Cooking Instructions Burn-Off Indirect Cooking using Main Burners Before cooking on your gas grill for the first time, you should "burn off" the grill to eliminate any odor or foreign The indirect cooking method can also be used with the matter.
- Page 25 Guide to Grilling using the Main Burners and Direct Cooking Method Approximate Cooking Times Grilling Steak and Ribs Cut of Meat Rare: 4-8 minutes Turn the grill Burners on HI, close the Lid and preheat your T-bone steak Medium: 10-14 minutes grill 10 to 15 minutes.
- Page 26 Guide to using the Sizzle Burner Important notes about using the Sizzle Burner • Once lit, leave the Sizzle Burner on sizzle and sizzle both sides of meat using the guidelines below. NOTE: The Sizzle Burner knob has three positions: •...
- Page 27 Guide to Roasting and Baking Using the Main Burners Food preparation An Important Note About Heat Settings Trim meat of excess fat. Truss meat and poultry with cooking The suggested heat settings shown are approximate. There string to retain shape if desired. Bacon strips can be used to are many factors such as outside temperature, wind condi- cover the outside surface of lean meat and poultry to help tions and grill location that affect your grill performance.
- Page 28 Guide to Rotisserie Cooking Guide to Smoking Slow Cooking with a Rotisserie Preparing to Smoke Rotisserie cooking produces foods that are moist, flavor- Smoking gives food a distinctive, delicious flavor. You will find ful and attractive. The rotisserie system is most com- a variety of wood chips available for use in smoking grilled monly used for cooking meat or poultry and is designed foods.
- Page 29 Question: Question: Sometimes I hear a humming sound coming from my Can I convert my grill from one fuel type to another in regulator. What causes this? And - My grill has a low other words from LPG to NG? flame and sometimes will not light.
- Page 30 Question: The Regulator and Hose supplied with my gas grill After every use (after your grill has cooled down), wipe stain- does not fit the older LP Gas tank I’ve used for years. less surfaces with a soft, soapy cloth or sponge then Why not? rinse with water.
