Pulsar PSBS 10A12C Manual

Buffer, switched mode power supply unit
Hide thumbs Also See for PSBS 10A12C:

Advertisement

Quick Links

1
PSBS 10A12C
v.1.0
PSBS 13,8V/10A/17Ah
Buffer, switched mode power supply unit.
EN
Edition: 2 from 18.09.2012
Supersedes edition: 1 from 02 .03.2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PSBS 10A12C and is the answer not in the manual?

Questions and answers

Summary of Contents for Pulsar PSBS 10A12C

  • Page 1 PSBS 10A12C v.1.0 PSBS 13,8V/10A/17Ah Buffer, switched mode power supply unit. Edition: 2 from 18.09.2012 Supersedes edition: 1 from 02 .03.2012...
  • Page 2: Table Of Contents

    2. Buffer power supply unit PSBS 13,8V/24x0,3A/17Ah - PSBS 10A12C + 3xLB8 24x0,3A (AWZ577 or AWZ580) + 17Ah 3. Buffer power supply unit PSBS 13,8V/10x1A/17Ah - PSBS 10A12C + LB8 8x1A (AWZ579 or AWZ580) + LB2 2x1A (AWZ585 or AWZ586) + 17Ah...
  • Page 3: Block Diagram

    - PSBS 10A12C + 2xRN500 (13,8V/12V) + 17Ah 6. Buffer power supply unit PSBS 13,8V/2x12V/16x0,5A/17Ah - PSBS 10A12C + 2xRN500 (13,8V/12V) + 2xLB8 16x0,5A (AWZ578 or AWZ580) + 17Ah 7. Buffer power supply unit PSBS 13,8V/2x12V/10x1A/17Ah - PSBS 10A12C + 2xRN500 (13,8V/12V) + 2xLB8 10x1A (AWZ579 or AWZ580) + 17Ah 8.
  • Page 4 PSBS10A12C • Ibat =2,1A • Ibat =3,6A • Ibat =4,8A Caption: jumper on, jumper off +BAT - DC supply battery output [11] (+BAT= red, -BAT = black) FAC - AC absence technical output –OC type (open collector) [12] hi-Z level = status: AC power failure L level = status: AC supply FPS - technical output of the PSU operation status –...
  • Page 5 PSBS10A12C Table 2. Element no. Description [Fig. 3] Insolation transformer PSU board (tab. 1) TAMPER micro-switch (contacts) of tamper resistance (NC) fuse in the supply circuit (230 V AC) MAIN L-N 230 V AC power connector PE – PE connector Battery connectors: +BAT = red, - BAT = black Tab 2.
  • Page 6: Specifications

    PSBS10A12C 1.4. Specifications: - electrical specifications (tab.3) - mechanical specifications (tab.4) - operation safety (tab.5) - operating specifications (tab.6) Electrical specifications (tab. 3). Mains supply 230V AC (-15%/+10%) Current consumption 1,1A Power frequency 50Hz PSU power 138W Efficiency Output voltage 11,0V ÷...
  • Page 7: Installation

    PSBS10A12C Notes The enclosure does not adjoin the assembly surface so that cables can be led. Convectional cooling. Operation safety (tab.5). Protection class PN-EN 60950-1:2007 I (first) Protection grade PN-EN 60529: 2002 (U) IP20 Electrical strength of insulation: - between input (network) circuit and output circuits of the PSU (I/P-O/P) 3000 V/AC min.
  • Page 8: Operating Status Indication

    PSBS10A12C 4. Connect the receivers’ cables to the +AUX-, +AUX1-, +AUX2-, +AUX3- connectors of the terminal block on the PSU board. 5. If necessary, connect the devices’ wires to the technical outputs: - FAC; AC status indication (alarm panel, controller, indicator, LED, etc.) - FPS;...
  • Page 9: Operation And Use

    PSBS10A12C Fig. 4. Electrical diagram of the OC outputs. 4. Operation and use. 4.1 Overload or short circuit of the PSU output The output circuit of the PSU is equipped with the electronic current protection. If the output voltage value exceeds the acceptable threshold –...
  • Page 10 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, starting from the initial product date of purchase placed on the receipt. 2. If a purchase proof is missing, a three-year warranty period is counted from the device’s production date.
