VENT - FREE GAS
WALL HEATER
OWNER'S OPERATION AND
INSTALLATION MANUAL
INFRARED MODELS
B10TNIR - B, B10TPIR - B
B20TNIR - BB, B18TPIR - BB
B30TNIR - BB, B28TPIR - BB
PFS
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable va-
pors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Questions, problems, missing parts? Before returning to your retailer, call
our customer service department at 1-866-762-4050, 8:00 am - 4:30 pm CST,
®
US
Monday through Friday or email service@bluegrassliving.com
B20TNIR-BB
Model Shown
Advertisement
Table of Contents
Related Manuals for Bluegrass Living B10TNIR-B
Summary of Contents for Bluegrass Living B10TNIR-B
- Page 1 B20TNIR-BB Model Shown VENT - FREE GAS WALL HEATER OWNER’S OPERATION AND INSTALLATION MANUAL INFRARED MODELS B10TNIR - B, B10TPIR - B B20TNIR - BB, B18TPIR - BB B30TNIR - BB, B28TPIR - BB ® WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ............3 Operation ..........16 Qualified Installing Agency ......4 Electrical Connection ....... 18 Specifications ..........5 Electrical Wiring ........18 Product Features ........6 Inspecting Burners........19 Local Codes..........6 Care And Maintenance ......20 Preparing For Installation ...... -
Page 3: Safety
SAFETY This appliance is only for use WARNING: Do not attempt to with the type of gas indicated on access or change the setting of the rating plate. This appliance the fuel selection means. is not convertible for use with Access to and adjustment of other gases. -
Page 4: Qualified Installing Agency
SAFETY 3. This heater needs fresh air ventilation to WARNING: Make sure grill run properly. This heater has an Oxygen guard is in place before running Depletion Sensing (ODS) safety shutoff system. The ODS shuts down the heater heater. if not enough fresh air is available. See Air for Combustion and Ventilation, pages 7 WARNING: Due to high tem- through 8. -
Page 5: Specifications
SPECIFICATIONS MODEL B10TNIR-B B10TPIR-B Ignition Piezo Piezo Gas Type Natural Propane/LP BTU (available) 10,000 10,000 Pressure Regulator Setting 6" W.C. 10" W.C. Maximum 10.5" Maximum 14" Inlet Gas Pressure* (inches of water) Minimum 7" Minimum 11" Heater Weight 14 lbs... -
Page 6: Product Features
PRODUCT FEATURES SAFETY PILOT THERMOSTATIC CONTROL This heater has a pilot with an Oxygen Deple- These heaters have a control valve with a tion Sensing (ODS) safety shutoff system. The thermostat sensing bulb. This results in the ODS/pilot shuts off the heater if there is not greatest heater comfort and may result in enough fresh air. -
Page 7: Unpacking
UNPACKING 1. Remove heater from carton. 3. Check heater for any shipping damage. If heater is damaged, promptly inform dealer 2. Remove all protective packaging applied where you bought heater. to heater for shipping WATER VAPOR: A BY - PRODUCT OF UNVENTED ROOM HEATERS Water vapor is a by-product of gas combus- The following steps will help ensure that water... - Page 8 AIR FOR COMBUSTION AND VENTILATION VENTILATION AIR Ventilation Air From Inside Building Ventilation Air From Outdoors Provide extra fresh air by using ventilation This fresh air would come from an adjoining grills or ducts. You must provide two perma- unconfined space. When ventilating to an nent openings: one within 12"...
-
Page 9: Installation
INSTALLATION NOTICE: This heater is intended CAUTION: This heater cre- for use as supplemental heat. ates warm air currents. These Use this heater along with your currents move heat to wall sur- primary heating system. Do not faces next to heater. Installing install this heater as your pri- heater next to vinyl or cloth wall mary heat source. - Page 10 INSTALLATION LOCATING HEATER This heater is designed to be mounted on a wall. For convenience and efficiency, install heater: 1. Where there is easy access for operation, inspection, and service. 2. In the coldest part of room. When installing the appliance directly on car- Screw peting, tile or other combustible material other Front...
- Page 11 INSTALLATION Attaching to Wall Stud Method 2. Mark screw locations on wall (see Fig- For attaching mounting bracket to wall studs: ure 7). Note: Mark only last hole on each end of mounting bracket. Insert mounting 1. Drill holes at marked locations using 9/64" screws through these holes only.
- Page 12 INSTALLATION Placing Heater On Mounting Bracket 1. Locate two horizontal slots on back panel of heater (see Figure 10). 2. Place heater onto mounting bracket. Slide Front View horizontal slots onto stand-out tabs on mounting bracket. Front View Horizontal Slots Wall Heater Stand-...
- Page 13 INSTALLATION CONNECTING TO GAS SUPPLY WARNING: A qualified ser- CAUTION: For propane/LP vice technician must connect gas, Never connect heater directly to the gas supply. This heater heater to gas supply. Follow all requires an external regulator local codes. (not supplied). Install the external WARNING: This appliance regulator between the heater and requires a 3/8"...
- Page 14 INSTALLATION Apply pipe joint sealant lightly to male threads. as shown in Figure 15. Pointing the vent down This will prevent excess sealant from going protects it from freezing rain or sleet. into pipe. Excess sealant in pipe could result Install sediment trap in supply line as shown in clogged heater valves.
- Page 15 INSTALLATION CHECKING GAS CONNECTIONS WARNING: Test all gas piping WARNING: Never use an open and connections for leaks after flame to check for a leak. Apply a installing or servicing. Correct mixture of liquid soap and water all leaks at once. to all joints.
-
Page 16: Operation
INSTALLATION PRESSURE TESTING HEATER GAS CONNECTIONS 1. Open equipment shutoff valve (see Fig- 5. Correct all leaks at once. ure 16, page 15). 6. Light heater (see Lighting Instructions on 2. Open gas supply tank valve. page 16). Check all other internal joints for leaks. - Page 17 OPERATION 6. With control knob pressed in, push Control down and release ignitor button. This Knob will light pilot. The pilot is attached to the front of burner. The pilot can be seen through the grill. If needed, keep pressing ignitor button until pilot lights. Note: If pilot does not stay lit, refer to IGNITOR Troubleshooting, pages 21 though 23.
-
Page 18: Electrical Connection
ELECTRICAL CONNECTION FOR BLOWER KIT Do not use this heater if any part of it has been under water. Immediately call a qualified ser- Cover of vice technician to inspect the Grounded Grounding Pin heater and replace any part of Outlet Box the electrical system which has been under water. -
Page 19: Inspecting Burners
INSPECTING BURNERS IMPORTANT: Owner’s should check pilot flame pattern and burner flame pattern often. Incorrect flame patterns indicate the need for cleaning (see Care and Maintenance, page 20) or service. WARNING: Only a qualified service person should service and repair heater. This includes maintenance requiring replacement or alteration of components. -
Page 20: Care And Maintenance
CARE AND MAINTENANCE WARNING: Turn off heater and let cool before servicing. CAUTION: You must keep control areas, burner, and circulating air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a qualified service techni- cian. -
Page 21: Troubleshooting
TROUBLESHOOTING WARNING: If you smell gas: • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Fol- low the gas supplier’s instructions. - Page 22 TROUBLESHOOTING Problem Possible Cause Corrective Action ODS/pilot lights but flame 1. Control knob is not fully 1. Press in control knob fully. goes out when control pressed in. knob is released. 2. Control knob is not pressed 2. After ODS/pilot lights, keep in long enough.
- Page 23 TROUBLESHOOTING Problem Possible Cause Corrective Action Heater produces a whis- 1. Turning control knob to the 1. Turn control knob to the low tling noise when burner high position when burner is position and let warm up for is lit. cold.
-
Page 24: Technical Service
TECHNICAL SERVICE You may have further questions about installation, operation, or troubleshooting. If so, contact Bluegrass Living, Inc. at 1-866-762-4050. When calling, please have your model and serial numbers of your heater ready. SERVICE HINTS When Gas Pressure Is Too Low •... -
Page 25: Parts
PARTS MODELS B10TNIR - B, B10TPIR - B www.bluegrassliving.com 2000458-01A... - Page 26 MODELS B10TNIR - B, B10TPIR - B This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 30 of this manual. ITEM B10TNIR-B B10TPIR-B DESCRIPTION Back Body Panel 161132-01...
- Page 27 PARTS MODELS B20TNIR - BB, B18TPIR - BB, B30TNIR - BB, B28TPIR - BB 30,000 BTU/Hr Heater Shown www.bluegrassliving.com 2000458-01A...
- Page 28 PARTS MODELS B20TNIR - BB, B18TPIR - BB This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 30 of this manual. ITEM B20TNIR-BB B18TPIR-BB DESCRIPTION Back Body Panel 161132-01 161132-01 Mounting Bracket...
- Page 29 PARTS MODELS B30TNIR - BB, B28TPIR - BB This list contains replaceable parts for your heater. When ordering replacement parts, follow the instructions listed under Replacement Parts on page 30 of this manual. ITEM B30TNIR-BB B28TPIR-BB DESCRIPTION Back Body Panel 161562-01 161562-01 Mounting Bracket...
-
Page 30: Replacement Parts
REPLACEMENT PARTS Note: Use only original replacement parts. This will protect your warranty coverage for parts replaced under warranty. PARTS UNDER WARRANTY Contact authorized dealers of this product. • Model and serial number of your heater If they can’t supply original replacement •... - Page 31 NOTES ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ ________________________________________________________________ www.bluegrassliving.com 2000458-01A...
-
Page 32: Warranty
Bluegrass Living makes no other warranties regarding this product. Bluegrass Living’s liability is limited to the purchase price of the product and Bluegrass Living shall not be liable for any other damages whatsoever under any circumstances including direct, indirect, incidental, or consequential damages.
