Summary of Contents for LG GR-W600GS
- Page 1 OWNER’S MANUAL REFRIGERATOR- FREEZER Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. www.lg.com P/No. : MFL67085712...
-
Page 2: Table Of Contents
IMPORTANT SAFETY INFORMATION ....3 CONTENTS INSTALLATION ........... 11 INNER PARTS ............. 12 OPERATIONS ............13 Starting Before Setting The Temperature Door Alarm Self Test Controls For Refrigerator Compartment Fast Freezing Child Lock Controls For Freezer Compartment Ice Making Fresh Room Drawer Vegetable Drawer Water Dispenser SUGGESTIONS ON FOOD STORAGE .... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION w w WARNING w Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. w Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. w Do not damage the refrigerant circuit. - Page 4 IMPORTANT SAFETY INFORMATION BASIC SAFETY PRECAUTIONS This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others or cause damage to the product.
- Page 5 IMPORTANT SAFETY INFORMATION 1. When connecting the power Do not extend or modify the length of the Unplug the power plug when cleaning, power plug. handling or replacing the interior lamp of the refrigerator. It causes electric shock or fire by the electric damage of the •...
- Page 6 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not place the heavy object or the Do not cling to the door or the shelves of the dangerous object door or the cool chamber. (container with liquid) on It may make the refrigerator the refrigerator.
- Page 7 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not use drier to dry the inside, nor light a Install in places away from the fire such as candle to remove odor. the place where flammable gas is It may cause explosion or leaked.
- Page 8 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not allow any person except the qualified When any strange smell or smoke is engineer to disassemble, repair or alter the detected from the refrigerator, disconnect refrigerator. the power plug immediately and Service It may cause injury, center...
- Page 9 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not remove the cover Place all the components in the right places on the back. before connecting the power. Don not use an Adapter. Never leave lit candles or incense on the fridge, at risk of causing fire or product damage.
- Page 10 IMPORTANT SAFETY INFORMATION Do not put any living animal in the Do not use the carbonated water. The gas refrigerator. pressure may cause leakage. Water Tank Do not use products such as grinding Clean the water tank according to the sponge, brush, iron, or even special instruction before using the Ice Maker.
-
Page 11: Installation
THIS REFRIGERATOR IS MANUFACTURED WITH GREAT CARE, AND UTILIZES THE LATEST IN TECHNOLOGY. WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH IT'S PERFORMANCE AND RELIABILITY. BEFORE YOU START YOUR REFRIGERATOR, PLEASE READ THIS BOOKLET CAREFULLY. IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND MAINTENANCE, AND ALSO SUPPLIES SOME USEFUL HINTS. -
Page 12: Inner Parts
INNER PARTS FREEZER COMPARTMENT Lamp Shelf Freezer Freezer Temperature Door Rack Control Dial Twisting Ice Serve Type Ice Making Freezer Shelf Door Rack REFRIGERATOR COMPARTMENT Water Tank Fresh Room Drawer Lamp Egg Tray Shelf Refrigerator Door Rack Vegetable Drawer Leveling Screw •... -
Page 13: Operations
OPERATIONS STARTING When your refrigerator is first installed, allow it 2-3 hours to stabilize at normal operating temperatures prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. BEFORE SETTING THE TEMPERATURE The temperature of the refrigerator is kept constant regardless of changes in room temperature. -
Page 14: Fast Freezing
OPERATIONS FAST FREEZING The FAST FREEZING feature operates when the refrigerator is first turned on. The compressor and circulating fan operate at maximum cooling capacity to quickly lower the refrigerator temperature. It shuts off automatically. If warm food is placed into the refrigerator, FAST FREEZING can be started with the button on the control panel. -
Page 15: Ice Making
OPERATIONS ICE MAKING Twisting Ice Serve Type To make ice cubes, fill the ice tray with water Ice Trays and insert in its position. Ice Cube Box To remove ice cubes, hold the lever of the tray and pull turn gently. Then, ice cubes drop in to the ice cube box. -
Page 16: Water Dispenser
OPERATIONS WATER DISPENSER Put water after the water tank being in position. Necessarily separate the water tank to clean it or not to use it. When the water tank is not in position after filling it with water, water can leak out by the valve pushed. -
Page 17: Suggestions On Food Storage
SUGGESTIONS ON FOOD STORAGE STORING FOOD Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, pineapples, and melons. -
Page 18: Cleaning
CLEANING It is important that you refrigerator be kept clean to w WARNING prevent undesirable odors. Spilled food should be wipe up immediately, since it may acidify and stain Always remove power cord from the wall outlet plastic surfaces if allowed to settle. prior to cleaning in the vicinity of electrical parts(lamps, switches, controls, etc.). - Page 19 CLEANING WATER DISPENSER Grille - Wipe with a wet cloth, and dry with a dry cloth. Water Tank - 1. Putting the Water Is not necessary to remove the water tank in order to supply it. NOTE Before closing door, close the cap and clamp tightly. Do not use liquids containing sugar or carbonated drinks like soda.
-
Page 20: General Information
GENERAL INFORMATION VACATION TIME ANTI-CONDENSATION PIPE During average length vacations, you will probably The outside wall of the refrigerator cabinet may find it best to leave the refrigerator in operation. sometimes get warm, especially just after Place freezable items in freezer for longer life. installation. -
Page 21: W W Warning
w w WARNING DO NOT USE AN EXTENSION CORD ABOUT GROUNDING (EARTHING) If possible, connect the refrigerator to its own In the event of an electric short circuit, grounding individual electrical outlet to prevent it and other (earthing) reduces the risk of electric shock by appliances or household lights from causing an providing an escape wire for the electric current. -
Page 22: Before Calling For Service
BEFORE CALLING FOR SERVICE SERVICE CALLS CAN OFTEN BE AVOIDED! IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE POSSIBLE CAUSES FIRST : PROBLEM POSSIBLE CAUSES REFRIGERATOR DOES Has a house fuse blown or circuit breaker tripped? NOT OPERATE Has the power cord plug been removed or loosened from the electrical wall outlet? Temperature control not set on proper position.
