ENGLISH
Easy Setup Guide
Please read this manual carefully before operating your set and retain it for future reference.
ESPAÑOL
Guía Rápida de Configuración
Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras consultas.
a
b
www.lg.com
AA
c
d
X 5
(M5 x L12)
X 4
(M4 x L12)
P/No: MFL69670632 (1701-REV00)
OLED TV
OLED55B7P
OLED55B7T
OLED65B7P
OLED65B7T
Advertisement
Table of Contents
Troubleshooting
Related Manuals for LG OLED55B7T
Summary of Contents for LG OLED55B7T
- Page 1 ENGLISH Easy Setup Guide OLED55B7P Please read this manual carefully before operating your set and retain it for future reference. OLED55B7T ESPAÑOL Guía Rápida de Configuración OLED65B7P Lea atentamente este manual antes de poner en marcha el equipo y consérvelo para futuras consultas.
- Page 2 ENGLISH Read Safety & Reference. ESPAÑOL Leer Seguridad y Consultas.
- Page 7 : kg OLED55B7P (OLED55B7P-S) 1,229 1 229 48.6 48,6 18.6 18,6 17.2 17,2 3.7 A / 370 W 3,7 A / 370 W OLED55B7T (OLED55B7T-D) OLED65B7P (OLED65B7P-S) 1,451 1 451 48.6 48,6 24.5 24,5 23.1 23,1 5.0 A / 500 W...
- Page 9 Safety and Reference Please read this manual carefully before operating your set and retain it for future reference. OLED55B7P OLED65B7P OLED55B7T OLED65B7T OLED65E7P OLED65E7T www.lg.com P/NO : MFL69728322 (1708-REV02) *MFL69728322* Copyright ⓒ 2017 LG Electronics Inc. All Rights Reserved.
- Page 10 Warning! Important Safety • Only use attachments/accessories specified by the manufacturer. instructions • Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution Read these instructions. Keep these instructions. when moving the cart/apparatus combination to Heed all warnings.
- Page 11 • Do not attempt to modify this product in any • Use only an authorized AC adapter and power way without written authorization from LG cord approved by LG Electronics. Otherwise, this Electronics. Unauthorized modification could may result in fire, electric shock, malfunction, or void the user’s authority to operate this product.
- Page 12 • Keep the product away from direct sunlight. • For an optimal connection, HDMI cables and • Never touch this apparatus or antenna during a USB devices should have bezels less than 10 mm lightning storm. thick and 18 mm width. •...
-
Page 13: Optional Extras
Optional Extras • When transporting the TV, do not expose the TV to jolts or excessive vibration. • When transporting the TV, keep the TV upright; never turn the TV on its side or tilt towards the Optional extras can be changed or modified for left or right. -
Page 14: Mounting On A Table
We recommend lubricants, etc.) to the screw parts when that you use an LG brand wall mount. The LG wall assembling the product. (Doing so may mount is easy to adjust or to connect the cables. -
Page 15: Connections (Notifications)
CAT 7 cable. OLED65B7P Connecting to an Antenna or Cable OLED55B7P OLED65B7T Model OLED55B7T OLED65E7P Connect an antenna, cable, or cable box to watch OLED65E7T TV while referring to the following. The illustrations VESA (A x B) -
Page 16: Other Connections
Other Connections Connect your TV to external devices. For the best picture and audio quality, connect the external device and the TV with the HDMI cable. • > > > General > HDMI ULTRA HD Deep Color: - On : Support 4K @ 50/60 Hz (4:4:4, 4:2:2, 4:2:0) - Off : Support 4K @ 50/60 Hz 8bit (4:2:0) •... - Page 17 Returns to the previous screen. * Clears all on-screen displays and returns to Supported licenses may differ by model. For more TV viewing. information about licenses, visit www.lg.com. Displays the program event according to time scheduler. Streaming Service buttons Connects to the Video Streaming Service.
-
Page 18: Open Source Software Notice Information
Doing so may produce some are available for download. temporary distortion effects on the screen. LG Electronics will also provide open source code - This panel is an advanced product that contains to you on CD-ROM for a charge covering the cost millions of pixels. - Page 19 Regulatory Television System For OLED55/65B7P, NTSC, PAL-M/N, OLED65E7P series SBTVD WARNING! For OLED55/65B7T, NTSC, PAL-M/N, Never place a television set in an unstable OLED65E7T series DVB-T, DVB-T2 location. A television set may fall, causing serious personal injury or death. Many injuries, particularly Program Coverage to children, can be avoided by taking simple precautions such as:...
- Page 20 The model and serial numbers of the TV are located on the back and on one side of the TV. Record them below should you ever need service. MODEL SERIAL...
-
Page 21: External Control Device Setup
OWNER’S MANUAL EXTERNAL CONTROL DEVICE SETUP Please read this manual carefully before operating the set and retain it for future reference. www.lg.com... -
Page 22: Key Codes
KEY CODES KEY CODES • This feature is not available for all models. Code Code Function Note Function Note (Hexa) (Hexa) CH +, PR + R/C Button List R/C Button CH -, PR - R/C Button Exit R/C Button Volume + R/C Button PIP(AD) R/C Button... - Page 23 (TV) (PC) • LGTV supports PL2303 chip-based (Vendor ID : 0x0557, Product ID : 0x2008) USB to serial converter RS-232C IN which is not made nor provided by LG. (CONTROL & SERVICE) (PC) (TV) • It can be purchased from computer stores that carry accessories for IT support professionals.
- Page 24 EXTERNAL CONTROL DEVICE SETUP (TV) (PC) (TV) (PC) Phone jack Type RS-232C IN • You need to purchase the phone-jack to RS-232 cable required for the connection between the PC and (CONTROL & SERVICE) (PC) (TV) the TV, which is specified in the manual. RS-232C IN (CONTROL &...
-
Page 25: Communication Parameters
EXTERNAL CONTROL DEVICE SETUP Communication Parameters • Baud rate : 9600 bps (UART) • Stop bit : 1 bit • Data length : 8 bits • Communication code : ASCII code • Parity : None • Use a crossed (reverse) cable. Command reference list (Depending on model) DATA... -
Page 26: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV. (j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the [Set ID] to choose desired monitor ID number in option menu. Adjustment range in TV is 1 to 99. - Page 27 EXTERNAL CONTROL DEVICE SETUP * Commands may work differently depending on model and signal. 01. Power (Command: k a) Ack [d][ ][Set ID][ ][OK/NG][Data][x] ► To control Power *On or Off of the set. * In case of video mute on only, TV will display On Transmission[k][a][ ][Set ID][ ][Data][Cr] Screen Display(OSD).
- Page 28 EXTERNAL CONTROL DEVICE SETUP 08. Color/Colour (Command: k i) 13. Treble (Command: k r) ► To adjust the screen Color(Colour). ► To adjust treble. You can also adjust colour in the PICTURE menu. You can also adjust in the AUDIO menu. Transmission [k][i][ ][Set ID][ ][Data][Cr] Transmission [k][r][ ][Set ID][ ][Data][Cr] Data Min : 00 to Max : 64...
- Page 29 EXTERNAL CONTROL DEVICE SETUP 18. Equalizer (Command : j v) * Analog Antenna/Cable ► Adjust EQ of the set. [Data 00][Data 01] Channel Data Transmission [j][v][ ][Set ID][ ][Data][Cr] Data 00 : High byte channel data Data 01 : Low byte channel data - 00 00 ~ 00 C7 (Decimal : 0 ~ 199) Data 02 : Input Source (Analog) - 00 : Antenna TV (ATV)
- Page 30 EXTERNAL CONTROL DEVICE SETUP * Analog Antenna/Cable 2. Tune to the digital antenna (ATSC) channel 30-3. Set ID = All = 00 Data 00 : Physical Channel Number Data 00 = Don’t know Physical = 00 - Antenna (ATV) : 02~45 (Decimal: 2 ~ 69) Data 01 &...
- Page 31 11 11 EXTERNAL CONTROL DEVICE SETUP 2. Tune to the BS (ISDB-BS) channel 30. 24. Input select (Command: x b) Set ID = All = 00 (Main Picture Input) Data 00 = Don’t know Physical = 00 ► To select input source for main picture. Data 01 &...
- Page 32 EXTERNAL CONTROL DEVICE SETUP * [Data 02], [Data 03] functions depend on model 3) When [Data 00] is 06, 07 and signal. 00 : Off 01 : On * If [Data 00] is 00 (3D On), [Data 03] has no meaning.
-
Page 34: Network Settings
Wheel (OK). Accessibility 5 If the connection is completed, Connected to Internet is displayed. NETWORK Picture TV Name Sound [LG] webOS TV WEBOS3.5 Wired Connection (Ethernet) Channels 3 Select the Network Wired Connection Not Connected (Ethernet) or Wi-Fi Connection. Wi-Fi Connection... -
Page 35: Troubleshooting Network Problems
Fi Settings. NETWORK Picture TV Name When X appears next to Gateway: Sound [LG] webOS TV WEBOS3.5 1 Unplug the power cord of the AP (Router) or cable Wired Connection (Ethernet) Channels modem, wait 5 seconds. Reapply power. Not Connected 2 Initialize (Reset) the AP (Router) or cable modem. -
Page 36: Updating The Tv Firmware
SmartShare PC SW Installation & Setting Install the SmartShare PC SW program on your PC. 1 Go to www.lg.com . Then, select your region. 2 Select Support. 3 Select Software & Drivers. Then, select SmartShare. 4 Download the SmartShare PC SW and install it on your PC. You can run the program when installation is complete. - Page 37 (Screen Share) 1 On the TV Intel® WiDi is set to On. Your laptop runs the Intel® WiDi program. * LG TVs do not need to register. * For more information on Intel® WiDi, visit http://intel.com/go/widi . 2 It detects LG Smart TVs available, which supports WiDi.
- Page 38 Troubleshooting Wi-Fi Network Problems Checkpoints • Make sure that you have the latest version of the software. - If you are using a Wi-Fi router, check whether you have the latest firmware installed. - If there are any available updates, update the firmware according to the manufacturer's instructions. - Check the current software version and if there is an available update, install it.
- Page 39 • Interference Factors If there is any interference from surrounding equipment, the network connection may be weak or unstable. - Wireless telephones that operate in the 2.4 GHz or 5 GHz bandwidth - Wireless speakers that operate in the 2.4 GHz or 5 GHz bandwidth - Video transmitters that operate in the 2.4 GHz or 5 GHz bandwidth - Other wireless devices (Microwaves, cameras, baby monitors, neighboring wireless devices, etc.) that operate in the 2.4 GHz or 5 GHz bandwidth.
