Installation - Power Dynamics 952.550 Instruction Manual

INSTALLATION

1. Drill a hole in the ceiling, big enough to fit the speaker
2. Connect the Active speaker with the 12VDC plug (See picture)
3. Connect Active and Passive speaker with speaker cable (+ / -) (See picture)
4. Insert the speaker in the hole.
5. Screw down each of the two screws (the locking tabs will swivel into the rear surface)
6. Place the metal grill
CONNECTING WITH BT
Connecting your BT-device to the speaker, follow below steps:
1. Turn on BT on your device
2. Search for "BT-SPEAKER"
3. Connect with "BT-SPEAKER"
Your device is now connected, no password needed.
DISCONNECTING OR RECONNECTING
If you want to change from BT-device, follow below steps:
1. Disconnect the current BT-device ("OFF")
2. Connect new BT-device by following above steps
If you move out of range or turn off the BT function on your BT-device, the BT of the speaker will disconnect. To
reconnect turn on the BT on the desired device, it will reconnect.
4
