HRV / ERV INSTALLATION AND
OPERATING INSTRUCTIONS
Maxum ECM Series
RHRV-S200P (ECM)
Polypropylene Core
RERV-S200ES (ECM)
Enthalpy Core
790 Rowntree Dairy Road,
Woodbridge, ON Canada L4L 5V3
t: 905.851.6701
f: 905-851.8376
e: info@reversomatic.com
Toll Free: 1.800.810.3473 (Canada)
1.800.499.5073 (U.S.A.)
www.reversomatic.com
®
2100
CERTIFIED
model:
Deluxe ECM Series
RHRV-D100P ES (ECM)
Polypropylene Core
RERV-D100 ES (ECM)
Superior ECM Series
RHRV-S100P (ECM)
Polypropylene Core
RERV-S100 (ECM)
®
C
US
model:
Enthalpy Core
model:
Enthalpy Core
Advertisement
Table of Contents
Related Manuals for Reversomatic Deluxe ECM Series
Summary of Contents for Reversomatic Deluxe ECM Series
- Page 1 HRV / ERV INSTALLATION AND OPERATING INSTRUCTIONS Deluxe ECM Series ® 2100 model: CERTIFIED RHRV-D100P ES (ECM) Polypropylene Core RERV-D100 ES (ECM) Enthalpy Core Superior ECM Series Maxum ECM Series model: model: RHRV-S100P (ECM) RHRV-S200P (ECM) Polypropylene Core Polypropylene Core...
-
Page 2: Table Of Contents
4. When leaving house for a long period of time (more than Troubleshooting two weeks), a responsible person should check if unit operates adequately. Climate Zone 5. Published efficiencies are based on balanced air-flows on supply and exhaust. www.reversomatic.com • info@reversomatic.com... -
Page 3: Parts List (Delux/Superior Ecm)
Parts List Deluxe / Superior ECM unit Optional Parts: Note:- No hole on Superior Partition Wall. Pair (For Deluxe auto balance unit only) Filter 12” x 7” (For Deluxe auto balance unit only) 013085 Motor - Exhaust/ Supply (ECM) (ECM) 9356ECM (For Deluxe units only) (For Deluxe units only) -
Page 4: Parts List (Maxum Ecm)
Maxum ECM Parts List Maxum Series model: RHRV-S200P (ECM) Polypropylene Core RERV-S200ES (ECM) Enthalpy Core Optional Parts: RHRV-P100A RHRV-P100P RERV-P100 Reference Description Part no. QTY. QTY. QTY. HRV / ERV - Lid, Pan Assembly 9391 Polypropylene Collar 6” Dia. PBD6C 9393 Polypropylene Core Enthalpy Core... -
Page 5: Wiring Diagram
Wiring Diagram Control Board HRV/ERV CHASSIS Control Board Low Voltage From Safety Switch Side Connections (Mounted on HRV/ERV Housing) (RED) (RED) Connection to the Connection to wall control units and Furnace, Fan-coil or timer switches (WHITE) Heat Pump Three wires: Relay Output: SPDT +5V (Power) Signal Max. -
Page 6: Wall Control Units And Timer Switches
Wiring Diagram (Cont’d) Wall Control Units and Timer Switches (Low Voltage, 5 VDC) Option 1: Wall Control (WC 100) Wall Timer/ 20/40/60 Min. Timer (TC 100 - 5V) Control Timer Timer Intermittent Timer Unit Switch Switch Switch Switch Intermittent Switch (IC 100 - 5V) +5V GND SGNL YEL RED YEL RED... -
Page 7: Furnace / Fan-Coil / Heat Pump Interlock
Wiring Diagram (cont’d) Furnace / Fan-Coil / Heat Pump Interlock: W A R N I N G Never connect a 120 volt AC circuit to the terminals of the furnace /fan-coil/heat pump interlock (Standard Wiring). Only use the low voltage class 2 circuit. Standard Interlock Wiring THERMOSTAT TERMINALS FOUR WIRE... -
Page 8: Hrv/Erv Operational Modes Functionality
HRV/ERV Operational Modes Functionality Off Mode: HRV/ERV fans are off. Defrost damper is closed to prevent cold air from entering the unit. Normal Mode: In Normal mode HRV/ERV fans run and the unit exchanges indoor air with outdoor air. The airflow exchange can be adjusted in four preset airflow values. -
Page 9: Timer Switch And Intermittent Switch (Optional)
Timer Switch & Intermittent Switch (Optional) Timer Switch Timer Switch (Programmable) Intermittent Switch Timer Switch Model # TC-100-120 Model # TC-100-120P Model # IC-100-5V Model # TC100-5V (120 VAC) (120 VAC) (5 VDC) (5 VDC) 1. TC100-5V The Timer Switch Unit consists of 3 LEDs and 1 push button. The Timer Switch Unit can put the unit in to High Speed Mode for the set time on the Timer Switch (20 min, 40 min, 60 min). -
Page 10: Programming Instructions For Wall Control Unit (Wc100)
Programming Instructions for Wall Control Unit (WC100) Normally there will be only one Wall Control Unit connected to Control Board. Multi Wall Control Unit (up to three) is also supported (see page 2). All Wall Control Units will have the same priorities over each other. It means that if multiple Wall Control Units command Control Board differently, the latest command will be executed by the Control Board. -
Page 11: Setting Internal Programming Parameters
Programming Instructions for Wall Control Unit (cont’d) Setting Internal Programming Parameters NOTE: There are totally 9 Defrost Maps. Map1-3 are for Aluminum Core (RHRV-D100A). Mode OFF. Current Humidity Map 4-6 are for Polypropylene Core (RHRV-D100P). Map 7-9 are for ERV Core (RERV-D100). Factory programmed default DEFR values are Map-1 for RHRV-D100A, Press both + and - buttons for... -
Page 12: Displaying Errors
Programming Instructions for Wall Control Unit (cont’d) The changed exhaust fan speed After pressing the MODE button, PROGRAM is stored in non-volatile memory the unit switches to Airflow which will be used from now on Balancing disable/enable setting. for the current airflow settings The current value is enabled. -
Page 13: Hrv And Erv Typical Installations
HRV and ERV Typical Installations (Deluxe Series) Typical Installations for House Fully Ducted System This is a stand alone HRV/ERV system which is not connected to a force air system. Stale air is drawn from key areas of the home (bathroom, kitchen) while fresh air is supplied to main living areas. -
Page 14: Horizontal
HRV and ERV Typical Installations (cont’d) HORIZONTAL • 32” clearance is recommended for cleaning of the core/servicing the unit. (use appropriate access door size) • Dampers are installed for horizontal installation. For vertical installation both dampers have to be turned so they can open properly and close when there is any backdraft. •... -
Page 15: Access Door Installation
For more info visit http://www.reversomatic.com/HRV&ERV/Accessories Drain Connection During defrost cycle the HRV unit may produce some condensation and the water should flow into a nearby drain. -
Page 16: Air Flow Balancing
Air Flow Balancing For units without built-in true Automatic Electronic Air-balancing and for cross verification only Balancing Procedure It is required to have balanced air flows in an HRV/ERV. The volume of air brought in from the outside must equal the volume of air exhausted by the unit while running at normal speed. If the air flows are not properly balanced, then: •... -
Page 17: Regular Maintenance
Air Flow Balancing (cont’d) DUCT DIAM CROSS SECTION AREA P" Note:(Option #2) Ø5 Ø6 *For balancing, extension box cover plate is 5" 0.136 sq. ft. 0.010 0.004 provided with 3 holes on supply side and 3 6" 0.196 sq. ft. 0.012 0.006 holes on exhaust side. -
Page 18: Annual Maintenance
Maintenance (cont’d) Annual Maintenance Repeat steps 1 to 5 from the previous section and continue with the following steps: 1. Clean the HRV and ERV core: - Remove filters, Loosen the core locking bracket , Remove the core, carefully grip ends of core and pull evenly outward ATTENTION - HRV Core >... -
Page 19: Troubleshooting
Troubleshooting (cont’d) PROBLEMS POSSIBLE CAUSES SOLUTION - check wall control connections - loss of communication with the Control - Error Code “E1" 4. “Wall Mount Board. HRV/ERV switched to OFF mode Unit” showing automatically. error Codes: - clean temperature sensor, if it still - defrosting Temperature Sensor Failure. -
Page 20: Climate Zone
Select HRV/ERV For Your Climate Zone Pacific Conditions Severe Conditions Moderate Conditions Dry Climate High Humidity U.S. Department of Energy climate zones map Select HRV/ERV for your Climate Zone HRVs are recommended for colder climates. ERVs are designed for warm-humid climates with long cooling seasons.
