Technical Specifications - 4xem IPVS1E User Manual

D. Technical specifications
- System
CPU: Trimedia PNX1300
RAM: 8MB SDRAM
ROM: 2MB FLASH ROM
Networking
-
Protocol
TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS, DHCP, DRM,
DDNS and UPnP
Physical
10BaseT Ethernet or 100BaseT Fast Ethernet
- Video
Algorithm supported
MPEG4(short header mode)
Video Inputs
1 BNC composite video input
NTSC/PAL auto-sensing
Features
Adjustable image size, quality and bit rate
Timestamp and text overlay
3 motion detection windows
Resolution
NTSC
Up to 30 frames at 176x120
Up to 30 frames at 352x240
PAL
Up to 25 frames at 176x144
Up to 25 frames at 352x288
- Camera Specification
1/4 inch color CCD sensor
1Lux / F2.0
AGC, AWB, AES
NTSC
512(H) x 492(V)
Electronic shutter: 1/60 – 1/15,000 sec
PAL
512(H) x 582(V)
Electronic shutter: 1/50 – 1/15,000 sec
- Audio
Algorithm supported
24Kbps, 8Kbps(optional)
Audio Inputs
1 RCA mono audio input
- General I/O
1 sensor input(max. 12VDC 50mA)
1 relay output(max. 24VDC 1A, 125VAC
0.5A)
- LED indicator
Dual color status indicator
- Dimension
138mm(L) * 88.9mm(W) * 57.2mm(H)
- Weight
NET. 222g
- Power
Consumption: near 5.4W
Universal switching power supply included
Input: 100-240VAC, 50/60Hz, 0.4A
Output: 12VDC, 1.5A
- Operating Environment
Temperature: 0-50°C/32-122°F
Humidity: 95%RH
- Viewing system requirement
Operating system
Microsoft Windows
Browser
Internet Explorer 5.x or above
- 64 -
