Item # 1001 406 076
1001 411 575
Model # FRS80952F-ST-1
FRS80952F-ST-N
USE AND CARE GUIDE
LUXLEY 5PC ROPE MODERN CHAT SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this set. We strive to continually
create quality products designed to enhance your home. Visit us onlineto see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY FRS80952F-ST-1
Summary of Contents for HAMPTON BAY FRS80952F-ST-1
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this set. We strive to continually create quality products designed to enhance your home. Visit us onlineto see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents........2 Pre-Assembly. -
Page 3: Warranty
Warranty 2 YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY WHAT IS COVERED We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for the fabric. WHAT IS NOT COVERED Its remains the customer’s responsibility for freight and packaging charges to and from our service center. -
Page 4: Hardware Included
Pre-Assembly (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity M6x15 Combination Bolt 34+2 Hex Wrench Hand knob 16+1 CHAIR PACKAGE CONTENTS Part Description Quantity Chair Bucket Right Leg Left Leg Chair Base Seat Cushion Back Cushion... - Page 5 Pre-Assembly (continued) TABLE PACKAGE CONTENTS Part Description Quantity Table Top Upper Table Leg Lower Table Leg Connection Plate HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
-
Page 6: Chair Assembly
Chair Assembly Attaching The Chair base To The Chair Bucket Place the chair bucket (A) upside down on a soft surface. Attach the chair base (D) to the chair bucket (A) using hand knobs (CC). Attaching The Chair Leg To The Chair Base Attach the right leg (B) and the left leg (C) to the chair base (D) using M6x15 combination bolts (AA). - Page 7 (continued) HOMEDEPOT.CA Please contact 1-855-HD-HAMPTON for further assistance.
- Page 8 Table Assembly Connecting The Upper Table Leg To The Table Top Place the table top (G) upside down on a soft surface. Attach the upper table legs (H) to the table top (G) using M6x15 combination bolts (AA). NOTE: Loosely tighten all the bolts using the hex wrench (BB). Connecting The lower table leg To The Table Top Connect the lower table leg (I) to the table top (G) using M6x15 combination bolts (AA).
- Page 9 Table Assembly (continued) Connecting The Connection Plate To The Table Legs Connect the connection plate (J) to the lower table leg (I) and the upper table leg (H) using M6x15 combination bolts (AA). NOTE: Loosely tighten all the bolts using the hex wrench (BB). Tightening The Bolts Once all of the bolts are in place, fully tighten all the bolts using the hex wrench (BB).
-
Page 10: Care And Cleaning
Care Care and Cleaning For best results, clean the frame and cushions with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that may accumulate. Do not clean with abrrasive materials, bleach or solvents. Store the set in a dry sheltered place when not in use. - Page 11 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HOMEDEPOT.CA Retain this manual for future use. For certification use only...
