MS50 STD USER MANUAL
1 PRODUCT PROFILE
This device is a new Android-based vehicle trouble diagnostic device developed for Internet
applications. It inherits from OBDSTAR advanced diagnosing technology and it is characterized
by covering wide range of vehicles, featuring powerful function, and providing precise result.
Through motorcycle diagnostic OBD connector and variant mobile intelligent terminals, it
achieves motorcycle trouble diagnosis for full car model and full system vehicle.
Meanwhile, taking advantage of mobile Internet, this device integrates all product resources and
service of OBDSTAR.
2 FEATURES
1. Diagnostic function:
● Diagnose the electronic control system of prevailing vehicle models covering Asian, European,
American and Chinese. Diagnosis functions include: Read DTCS, Clear DTCS, Read data stream,
Special functions etc.
● Specially designed for Android platform with clear and user-friendly interface;
2. Support Center: equipped with powerful database. Large number of videos help users to
operate device easily.
3. Personal center:
User information and the device's configuration information.
4. Upgrade: built-in WIFI mode can realize application downloading and diagnostic function by
one key upgrade.
5. System setting: set VCI formation, language, unit, Workshop information, About and Network
test etc.
6. Remote assistance: achieve remote assistance by this function.
3 KNOWLEDGE OF THIS DEVICE
3.1 The whole set
This device is composed of the tablet computer, main test cable and kinds of cables.
3.2 The tablet computer
front view
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS50 STD and is the answer not in the manual?

Questions and answers

Related Manuals for Obdstar MS50 STD

Summary of Contents for Obdstar MS50 STD

  • Page 1 1 PRODUCT PROFILE This device is a new Android-based vehicle trouble diagnostic device developed for Internet applications. It inherits from OBDSTAR advanced diagnosing technology and it is characterized by covering wide range of vehicles, featuring powerful function, and providing precise result.

  • Page 2: Technical Parameters

    reverse view 4 TECHNICAL PARAMETERS ● Operation system: Android 5.1.1 ● CPU: RK3128 Quad-Core，ARM Cortex A7@1.2Ghz ● Battery: 2600mA, rechargeable polymer lithium battery ● Extension memory card: 32G Micro SD (TF) card supported ● Memory capacity: 16GB...
  • Page 3 ● LCD: 5.0 inches ● LCD resolution: 800*480 ● Touch screen: Capacitive touch screen ● Wi-Fi: supported ● Working temperature: -20℃~55℃（14℉~131℉） ● Storage temperature: -20℃~70℃（-4℉~158℉） ● Weight: about 700g ● Dimension: 198mm*115*mm*31mm 5 ACCESSORIES（Standard Configuration） 5.1 Main test cable 5.2 Other Connectors Other connectors are used to connect the diagnosis socket of non OBD II vehicles.
  • Page 4 5.3 P001 Programmer Unit P001 Programmer is used for key transponder renewing and EEPROM reading and writing functions, the wiring of key renewing (specific function operation is helpful in software) is as shown below; Note: Not all configurations include P001 Programmer accessories. 5.4 Others accessories DC Power Adapter (Output DC 12V/2A) To power up the tablet via connecting with outside power Supply.

  • Page 5: Using Battery

    outlet. 5. Unplug USB cable on the charger from this device. 7 USING BATTERY ● If the battery keeps unused for a long time or battery is completely discharged, it is normal if it cannot be turned on while being charged. Please charge it for a period and then turn it on. ●Using data service will cause more power consumption and shorten the stand by time.

  • Page 6: Customize Your Desktop

    B. Back button : go back to previous interface or exit program. C. Home button : return to the desktop D. Touch screen menu button : select desired item E. DP button : enter diagnose and program interface F. VCI button : enter system settings 10 CUSTOMIZE YOUR DESKTOP 10.1 Add items on the desktop...

  • Page 7: Lock&Unlock

    ● Long-press: press and hold the current interface, icon or input field to open the available operation options. ● Slide: use your finger to slide the screen horizontally or vertically. ● Drag: hold and press the desired item, then drag it to any location. 12 LOCK&UNLOCK 12.1 Lock the screen ●...
  • Page 8 According to the regulations of some countries or areas, PC device must be turned off before boarding on the airplane. The way to disable functions of this device is to set it as airplane mode. In this mode, all wireless radio waves will be off, including mobile network, Bluetooth and WLAN.
  • Page 9 3.1 User registration Enter the Personal Center interface, display the login interface, click the “Register” button in the lower right corner to enter the user registration interface. As shown:...
  • Page 10 Fill in the information in each field. After that, the registration is successful, click “Login now!” If you have registered to be a member, click “User login” to enter user login page, as following picture shown:...
  • Page 11 3.2 User login After the registration is completed, fill in the account number and password and click login: Display personal basic information and modify information and password. 3.2.1 Modify information...
  • Page 12 3.2.2 Change password 3.2.3 View distributor information Click "View Distributor Information" to view the Distributor Contact Information. 3.2.4 Recover password Click on the forgotten password in the login interface to enter the password recover interface, fill in the relevant information to recover the password.
  • Page 13 3.3 Recharge and expense 3.3.1 Recharge CREDIT Click "Recharge CREDIT" to recharge through 2 contact methods. 3.3.2 Upgrade configuration Click "Upgrade configuration" to upgrade the software configuration, you need to consume CREDIT.
  • Page 14 Click“View Configuration Contrast Information” to view the configuration table. 3.3.3 Renewal fee Click "Renewal fee" to upgrade the software service years, you need to consume CREDIT.
  • Page 15 3.3.3 Order history Click "Order history" to view the Order history.

  • Page 16: Start Diagnosing

    4 Diagnostic Software Main Interface Introduction The main interface is divided into two pages, including the following functions: Moto Diag: Enter the motorcycle diagnostic programming function. Motorboat Diag: Enter the motorboat diagnostic programming function. Moto IMMO: Enter the Moto IMMO programming function for programming. Personal Center: new user registration, login;...
  • Page 17 Click on the plus sign to enter the interface for selecting vehicle series and tick the square in the upper right corner to choose to add to favorites:...
  • Page 18 If you want to delete favorite vehicles from Favorites, click the minus sign and remove the ticked. You can see all the downloaded software of the machine configuration. The OBD II software is in each area by default and in the first position: Hereinafter, take OBDII for example, to introduce how to start diagnosing.
  • Page 19 To select software version, as following photo shown: To enter diagnostic function menu, as following photo shown:...
  • Page 20 To select AUTO SCAN, as following photo shown: 5.1 Read vehicle information Tap “Read vehicle information”, as following photo shown:...
  • Page 21 5.2 Read Stored Codes Tap “Read Stored Codes”, as following photo shown:...
  • Page 22 5.3 Clear trouble codes 5.4 Read data stream...

  • Page 23: Support Center

    6 SUPPORT CENTER We have powerful maintenance database and detailed product introduction information. 6.1 VIDEO CENTER Connect the diagnosis function operation videos of the actual vehicles; 6.2 Product Description Introduce the instruction manual of this product, and exhibit the basic information of the equipment, diagnosis instructions, upgrades, other applications and additional explanations of...

  • Page 24: System Settings

    the company's products in the device. 6.3 FAQ Summarize some common problems encountered in the use of the product; 7 SYSTEM SETTINGS It includes VCI information, language, unit, Workshop information, user information and about etc. 7.1 VCI information...
  • Page 25 7.2 Language 7.3 Unit...
  • Page 26 7.4 Workshop information 7.5 About Display software version updates and product announcements. 7.6 Network test The network test function is convenient for network connection failure and other phenomena during the use process. The test logs are submitted and engineers can analyze the network status of the machine through the test logs.
  • Page 27 7.7 DC Calibrate Voltage calibration is performed when the voltage is abnormal: Enter the PinCode to access:...

  • Page 28: Remote Assistance

    Enter the correct voltage for calibration. When it is completed, display the correct voltage value in the upper right corner of the diagnostic programming interface. 8 REMOTE ASSISTANCE This application can realize remote hosting operation via the Third Party’s software: Quick Support.
  • Page 29 1 Detection System Upgrade The system APK automatically detects the version. If there is a version update, a red dot is in the upper right corner of the upgrade button. Click on the upgrade button to prompt “Whether to upgrade software?”:...
  • Page 30 If not, click “Esc”, you will directly return to the main interface. However you cannot enter the upgrade diagnosis application interface. Click on the APK upgrade and it prompts to install: Click on the installation and perform the program installation, automatically close the program and install.
  • Page 31 Re-enter the main interface and prompt statement. (Notes: Ensure Internet connection is normal when updating.) 2. Diagnostic Function Upgrade Download and upgrade software by “Bulk Update” Tap main screen “Bulk update”, start downloading and upgrading...
  • Page 32 If a software needs to be canceled, just tap the corresponding Check Box. You can search for the updated model required in the search box (Fuzzy Search function). As following photo shown: After the upgrade is completed, you can enter the diagnostic programming to view the upgrade version description and the version number, and you can perform related diagnostic operations and functions.
  • Page 33 You can use any APP based on browser website and network. 2.1 Open the browser Enter main menu screen, tap to OBDSTAR the browser. You can choose the desired homepage or input the website address to browse. 1. Tap to input or edit the web link 2.2 Browser webpage...
  • Page 34 2.5 Open multiple pages The browser allows you to open multiple web pages and you can toggle between these pages. 1. While browsing a webpage, tap the Fold Button at the top right and open new window. 2. Another web page will be displayed in the new window. 2.6 Customize Internet settings While browsing a webpage, choose “Settings”...
  • Page 35 2. Tap to add alarms. 3. Set the detailed information of the alarm. 4. Tap to pack up the alarm to store the setting. 7.2 Delete an alarm 1. Enter main menu, and tap “Alarm”. 2. Tap the desired alarm. 3.

  • Page 36: Language And Input Method

    8 ES FILE VIEWER Open ES file viewer, and enter main menu. You can manage SD card, browse by category and browse all music, picture, video, document application, package, favorites, installation package, management recommended through catalogue. 9 BRIGHTNESS 1. Enter main menu screen, tap “Settings” > “Display”. 2.

  • Page 37: Set Date And Time

    OBDSTAR (hereinafter referred to as OBDSTAR). The information contained herein is designed only for the use of the unit. OBDSTAR is not responsible for any consequences arising from its use in guiding the operation of other...
  • Page 38 This manual and all examples contained herein are subject to change without prior notice. Neither OBDSTAR nor its affiliates shall be liable to the purchaser of this unit or third parties for damages, losses, costs, or expenses, incurred by purchaser or third parties as a result of: accident, misuse, or abuse of this unit or unauthorized modifications, repairs, or alternations to this unit, failure to strictly comply with OBDSTAR operating and maintenance instructions.
  • Page 39 stored on the devices. 10. Do not use this device in high temperature and other environment with flammable gas, such as gas station. 11. Store this device out of the reach of children and do not allow children to use it in unsupervised state.
  • Page 40 Traffic safety 1. Do not hold this device while driving and comply with the regulations in your area or country. 2. The wireless device may interfere with the aircraft's flight system, please comply with the relevant provisions of the airline, in the ban on the use of wireless equipment, please turn off this device.
  • Page 41 The warranty is only applicable to users and distributors who purchase OBDSTAR products through normal procedures. Within one year from the date of delivery, OBDSTAR electronic products due to material or process defects caused by warranty, due to abuse, unauthorized changes, for non-product design purposes, not in accordance with the provisions of the manual Operation, etc., resulting in...
  • Page 42 0086-755-86707161. When the device needs repair, please send it to OBDSTAR Technology Co., Ltd., together with the purchase invoice and problem description. If the device is within the scope of the warranty, OBDSTAR will provide free maintenance; if the device is not in the warranty, OBDSTAR will charge maintenance and return freight.
