Summary of Contents for VISIO VG-4-3TC-P

  • Page 1 VG-4-3TC-P User Manual Please read the instructions carefully before use...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instuctions ......................2 2. Technical Specifications ....................3 3. How To Control The Unit ....................3 3.1 DMX Controler ......................4 3.2 DMX 512 Configuration....................5 3.3 DMX512 Conntections .....................6 4. Troubleshooting .......................7 5. Fixture Cleaning.......................7...
  • Page 3: Safety Instuctions

    1. Safety Instruction Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Caution:...
  • Page 4: Technical Specifications

    By DMX controller By VD-T VD-T is a specially designed handy setup tool for all Visio integral fixtures and Controllers. By connecting VD-T to any fixture via XLR, you can easily setup DMX Address, Channel Modes, White Balance, Manual Colors, and Fade Speed functions.
  • Page 5: Dmx Controler

    3.1 DMX Controller Use universal DMX controller to control the units, you have to set DMX address from 1 to 512 channel so that the units can receive DMX signal. Please refer to the following diagram to address your DMX512 channel for the first 4 units: 3 Channels:...
  • Page 6: Dmx 512 Configuration

    3.2 DMX 512 Configuration...
  • Page 7: Dmx512 Conntections

    3.3 DMX512connections 1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable. 2. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120 ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit.
  • Page 8: Troubleshooting

    4. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
  • Page 10 Innovation, Quality, Performance...
