  • Page 1: User Manual

    BW-54-3RGBW User Manual Please read the instructions carefully before use...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Safety Instuctions......................2 2. Technical Specifications ....................3 3. How To Set The Fixture....................4 3.1 Control Panel ......................4 3.2. Main Functions....................... 4 4. How To Control The Unit ....................10 4.1 Master/Slave Built-In Preprogram Function............10 4.2 DMX Controler ......................

  • Page 3: Safety Instuctions

    1. Safety Instruction Please read the instructions carefully which includes important information about the installation, operation and maintenance. WARNING — Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Caution：...

  • Page 4: Technical Specifications

    — The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged. — Do not open the unit as there are no user serviceable parts inside. Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest authorized technical assistance center.

  • Page 5: How To Set The Fixture

    3. How To Set The Fixture 3.1 Control Panel Power Water proof connectors for power input/output DMX input/output Water proof connectors for DMX 512 operation, 3-pin XLR cable to link the unitstogether Display o show the menu and the selected functions Button: MENU To select the programming functions...
  • Page 6 Once you set , after running in show mode for 5 minutes without any change or restarting the unit, the key board become locked. Press ENTER button to enable the menu, the display will show , press UP and DOWN button until it shows then press ENTER to unlock.
  • Page 7 DMX 512 Address Setting Press the MENU button up to when the is shown on the display. Pressing ENTER button and the display will blink. Use DOWN and UP button to change the DMX 512 address. Once the address has been selected, press ENTER button to setup or automatically exit menu mode without any change after one minute.
  • Page 8 Channel mode Press the MENU button up to when the is shown on the display. Pressing ENTER button and （ the display will blink. Use DOWN and UP button to select the 4channels （ ） （ ） ， 5channels 7channels Once select, press ENTER button to setup or automatically exit menu mode without any change after one minute.
  • Page 9 （fade）is selected, press ENTER button to confirm, then use DOWN and UP button to adjust rotation time(1…..9). Once select ,press ENTER button to store or automatically return to the main functions without any change after one minute. To go back to the previous functions without any change press the MENU button.
  • Page 10 Adjust White Balance Press the MENU button up to when the is showing on the display. Pressing ENTER button （Red） ， （Green） ， and the display will blink. Use DOWN and UP button to select the （Blue）mode. Once the mode has been selected, press the ENTER button to setup or automatically return to the main functions without any change after one minute.

  • Page 11: How To Control The Unit

    Fixture Hours Press the MENU button up to when the is blinking on the display. Pressing ENTER button and the display will show the number of working hours of the unit. To go back to the functions press the MENU button. Software version Press the MENU button up to when the is blinking on the display.

  • Page 12: Dmx 512 Configuration

    Please refer to the following diagram to address your DMX512 channel for the first 4 units： 4 Channels： 5 Channels： Channels ： 4.3 DMX 512 Configuration...

  • Page 13: Dmx512 Conntections

    4.4 DMX512 连接 1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin adapter-cable. 2. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120 ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit.

  • Page 14: Fixture Cleaning

    Not responding to DMX controller 1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly. 2. If the DMX LED is on and no response to the channel, check the address settings and DMX polarity.
  • Page 16 Innovation, Quality, Performance...
