BlueStorm/Express Diagrams
Figure 1: BlueStorm/Express RS-232/422/485 two and four port model hardware components
(BEG001, BEG002, BEG003, BEG004, BEG012, BEG013)
Note: The above example is a four port BlueStorm/Express model. JC and JD
headers will not be installed on two port models.
