- Page 1 D5032S - D5032D INSTRUCTION MANUAL SIL 3 Switch/Proximity Detector Repeater Relay Output, Termination Board Models D5032S, D5032D D5032 - SIL 3 Switch/Proximity Detector Repeater Relay Output G.M. International ISM0108-11...
-
Page 2: Technical Data
Current consumption @ 24 V: 35 mA for 2 channels D5032D, 18 mA for 1 channel D5032S with short circuit input and relay energized, typical. Power dissipation: 0.85 W for 2 channels D5032D, 0.45 W for 1 channel D5032S with 24 V supply voltage, short circuit input and relay energized, typical. -
Page 3: Ordering Information
- Input Ch 1 for Proximity or Voltage free Contact + Input Ch 2 for Proximity or Voltage free Contact - Input Ch 2 for Proximity or Voltage free Contact G.M. International ISM0108-11 D5032 - SIL 3 Switch/Proximity Detector Repeater Relay Output... - Page 4 Ci device + C cable ≤ 50 % of Co and Li device + L cable ≤ 50 % of Lo). If the cable parameters are unknown, the following value may be used: Capacitance 180pF per meter (60pF per foot), Inductance 0.60µH per meter (0.20µH per foot). D5032 - SIL 3 Switch/Proximity Detector Repeater Relay Output G.M. International ISM0108-11...
- Page 5 Resistors R1 - R2 used with Termination Relay contact shown in voltage free contact required board connector de-energized position for line fault detection. Internal Dip switches programmable MODEL D5032S Supply 24 Vdc voltage free voltage free Proximity Contact Contact Out NO Contact (SIL 3) Termination...
-
Page 6: Operation
On the section “Function Diagram” and enclosure side a block diagram identifies all connections. Identify the number of channels of the specific card (e.g. D5032S is a single channel model and D5032D is a dual channel model), the function and location of each connection terminal using the wiring diagram on the corresponding section, as an example: For Model D5032S, in case of Proximity or Voltage free Contact, connect the wires at terminal “7”... - Page 7 For SIL Application Input Output Input Output IN / OUT NO-NE or Operation NC-ND Input Output Input Output NO-ND or NC-NE For SIL Application G.M. International ISM0108-11 D5032 - SIL 3 Switch/Proximity Detector Repeater Relay Output...
- Page 8 Set SW4 Reverse opposite to Not specified fault condition Mode Fault No Fault Fault condition Output Mode For SIL Application No Fault Fault condition Mode For SIL Application D5032 - SIL 3 Switch/Proximity Detector Repeater Relay Output G.M. International ISM0108-11...
- Page 9 For SIL Application Input Input Output Output IN / OUT NO-NE or Operation NC-ND Output Input Input Output NO-ND or NC-NE For SIL Application G.M. International ISM0108-11 D5032 - SIL 3 Switch/Proximity Detector Repeater Relay Output...
- Page 10 Configuration DIP Switch factory settings (valid for D5032S and D5032D) SW1 SW2 SW7 SW8 D5032D (used as double channel) Configuration Summary Table WARNING: dip-switch 6-7-8 must be set to “OFF” position. Channel Channel Line fault detection IN/OUT Operation Disabled NO-NE or NC-ND...
