General Description - Brother P-touch PTE550WVPYJ1 Quick Setup Manual

GETTING STARTED
1
4
1. Cover latch
2. Tape exit slot
3. LCD display
4. Mini-USB port
5. Keyboard
When shipped from the factory, the LCD display is covered with a protective sheet to prevent
damage. Remove this sheet before using the P-touch labeling system.
1. Tape viewer
2. Rear cover
3. AC adapter connector
20

General Description

General Description
2
5
1
2
3
6
3
8
6. Tape cutter
7. Tape cassette compartment
8. Release lever
9. Print head
4
4. LED lamp
5. Battery compartment
7
9
5
