Reversing the direction the doors open

The doors normally open to the left (hinges on the right); if you wish to open the door to the right,
you can modify the direction in which it opens by following the instructions below. To ensure cor-
rect installation, please scrupulously follow the directions and the sequence of operations below.
1. Gently tilt the appliance backwards (with the doors
facing upwards).
2. Remove the plinth by pulling the lugs A on the lower
part towards you and swivelling the plinth upwards
to disengage it (R1). Remove cover B from its hous-
ing on the left and insert it in the housing on the right
(R2).
3. Remove the bottom hinge pin and release it from its
housing C ; retrieve the plastic distance piece placed
between the door and the hinge on the pin; unscrew
the bottom hinge D and screw the pin into the left-
hand hole in the hinge (R3).
4. Remove the refrigerator's door (R3).
5. Unscrew the middle hinge E, taking care not to lose
the plastic distance pieces inserted on the pin (R3).
6. Remove the covers G on top of the freezer's door
(R4).
7. Free the freezer's door from the top hinge (R4).
8. Remove the screw and the covers F on the left-hand
side of the appliance and insert them in the holes on
the right-hand side (R3) .
9. Remove the covers H from the control panel (R5 ).
10. Unscrew and remove the top right-hand hinge I
(R5).
G
H
32
drawing R1
A
A
drawing R2
B
drawing R3
E
F
C
drawing R4
drawing R5
I
H
EN
D
