PCB Piezotronics IMI SENSORS 647A01 Installation And Operating Manual page 18

Model Number
LOOP POWERED, CURRENT OUTPUT, INDUSTRIAL VIBRATION SENSOR
647A01
Performance
Measurement Range
Output
Frequency Range(± 10 %)
Broadband Resolution
Non-Linearity
Environmental
Temperature Range
Enclosure Rating
Electrical
Excitation Voltage
Settling Time(within 2% of value)
Electrical Isolation(Case)
Physical
Size - Hex
Size - Height
Weight
Mounting Thread
Mounting Torque(Stud)
Mounting Torque(hex nut)
Sensing Element
Sensing Geometry
Housing Material
Sealing
Electrical Connector 2-Pin MIL-C-5015
Electrical Connection Position
Electrical Connections(Pin A)
Electrical Connections(Pin B)
[7]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
EN GLISH SI
0.0 to 5 g rms 0.0 to 49 m/s² rms
4-20 mA 4-20 mA
180 to 300 kcpm 3 to 5 kHz
0.025 g rms 0.24 m/s² rms
± 1 % ± 1 %
-40 to 185 °F -40 to 85 °C
IP68 IP68
12 to 30 VDC 12 to 30 VDC
< 15 sec < 15 sec
8 8
> 10 Ohm > 10 Ohm
7/8 in 22.2 mm
1.41 in 35.8 mm
3.8 oz 108 gm
1/4-28 UNF 1/4-28 UNF
3 to 4 ft-lb 4.1 to 5.4 Nm
2 to 3 ft-lb 2.7 to 4.1 Nm
Ceramic Ceramic
Shear Shear
Stainless Steel Stainless Steel
Welded Hermetic Welded Hermetic
2-Pin MIL-C-5015
Side Side
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg (-) 4-20 mA Neg (-)
Optional versions have identical specifications and accessories as listed for the standard model
[1]
except where noted below. More than one option may be used.
[2][3]
- Hazardous Area Approval- contact factory for
EX
[4] specific approvals
Hazardous Area Approval
Hazardous Area Approval
Hazardous Area Approval
Hazardous Area Approval
M - Metric Mount
Supplied Accessory: Model M080A163A (1)
RV - Buffered Analog Signal Output - 100 mV/g
(±20%)
Electrical Connector
Electrical Connections
Electrical Connections
Electrical Connections
[5][6]
N OTES:
[1]Conversion Factor 1 in/sec = 0.0254 m/sec.
[2]1Hz = 60 cpm (cycles per minute).
[3]Current will fluctuate at frequencies below 5 Hz.
[4]Typical value.
[5]1/8" hex Allen key required for English version, 3mm hex Allen key required for metric version.
[6]Stud torque must exceed sensor hex nut torque to ensure proper dismantling.
[7]See PCB Declaration of Conformance PS039 or PS053 for details.
SUPPLIED ACCESSORIES:
Model M080A163A (1)
Model 080A162 Mounting Stud (1)
Model ICS-4 NIST-traceable single-axis amplitude response calibration from 0 cpm (0 Hz) to
upper 10% frequency for 4 - 20 mA output vibration sensor (1)
Entered: LK Engineer: NJF
Date: 07/24/2019 Date: 07/24/2019 Date: 07/24/2019 Date: 07/24/2019 41751
3425 Walden Avenue, Depew, NY 14043
Revision: B
ECN #: 49753
OPTION AL VERSION S
DIV II, CL I, GRPS A-D, ExnL, DIV II, CL I, GRPS A-D, ExnL,
AExnA, IIC T4 AExnA, IIC T4
EEx ia IIC T4, -40°C≤Ta≤80°C, EEx ia IIC T4, -40°C≤Ta≤80°C,
II 1 G II 1 G
EEx nL IIC T4, - EEx nL IIC T4, -
40°C≤Ta≤80°C, II 3 G 40°C≤Ta≤80°C, II 3 G
DIV I, CL I, II, III, GRPS A-G, DIV I, CL I, II, III, GRPS A-G,
Exia, AExia, IIC T4 Exia, AExia, IIC T4
3-Pin MIL-C-5015 3-Pin MIL-C-5015
4-20 mA Pos (+) 4-20 mA Pos (+)
4-20 mA Neg/Signal Output 4-20 mA Neg/Signal Output
Neg Neg
Signal Output Pos Signal Output Pos
Sales: MC Approved: NJF Spec Number:
Phone: 800-959-4464
Fax: 716-684-3823
E-M ail: imi@ pcb.com
