LAD4700_LGEAF_ENG_MFL41634281
LAD4700/LAD4705/LAD4710
ENGLISH
CAR DVD Receiver
Read the manual carefully before using the unit
FRANÇAIS
Syntoniseur DVD voiture
Prière de lire entièrement et attentivement ce manuel d'instruction
avant de procéder à l'installation, la mise en marche ou le réglage de
cet appareil.
CD - R/RW
P/NO: MFL41634281
Advertisement
Table of Contents
Related Manuals for LG LAD4700
Summary of Contents for LG LAD4700
- Page 1 LAD4700_LGEAF_ENG_MFL41634281 LAD4700/LAD4705/LAD4710 ENGLISH CAR DVD Receiver Read the manual carefully before using the unit FRANÇAIS Syntoniseur DVD voiture Prière de lire entièrement et attentivement ce manuel d’instruction avant de procéder à l’installation, la mise en marche ou le réglage de cet appareil.
-
Page 2: Safety Note
Safety note CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT SPLIT COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with the arrowhead symbol, within an equilateral triangle is intended to alert the user about the presence of uninsulated dangerous voltage with- in the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. - Page 3 • A defective or soiled disc inserted into the unit can cause the sound to drop during playback. • Handle the disc by holding its inner and outer edges. • Do not touch the surface of the unlabeled side of the disc. Do not stick paper or tape, etc.
- Page 4 • You have to set the disc format option to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live File System, you cannot use it on LG players. (Mastered/Live File System : Disc format system for Windows Vista)
-
Page 5: Table Of Contents
Table of contents Safety note ............2-4 Table of contents . -
Page 6: Before Use
Before use Detaching the control panel You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connector on the back of the control panel and on the panel holder. 1 Press the “... -
Page 7: Control Panel
Control Panel INFO DISC MENU [SOURCE] Disc Slot Repeat [RPT] I I /i i • Skip / Search [ Display Window Intro Scan [SCAN] I I /i i • Seek/ Tune [ Release [ • Play/Pause [B X] • Auto Store [AS] •... - Page 8 PLAY (B) ANGLE Starts playback. Selects a DVD camera angle if available. STOP (x) ZOOM JPEG Stops playback. Enlarges video image. SEARCH TITLE Selects a track or file. Displays title menu, if available. DISPLAY BAND Accesses On-Screen display. • Selects three FM and MW (AM) bands. 0-9 number buttons •...
-
Page 9: Installation
Installation Basic Installation Bend the claws according to Before installing, make sure that the ignition-switch is set to the thickness of the OFF and remove the terminal of the car battery to avoid dashboard short-circuiting. 1 Remove the existing receiver unit. 2 Make the necessary connections. - Page 10 Connecting to a car Before connecting, make sure that the ignition switch is set to OFF and remove the battery # terminal to avoid short circuits. To Speaker To Vehicle PHONE MUTE (ORANGE) GROUND(-) (BLACK) DIMMER (PINK) DIMMER SWITCH TO IGNITION (RED) IGNITION SWITCH TO BATTERY(+) (YELLOW) POWER ANTENNA (BLUE)
- Page 11 • YELLOW: This lead is for connection to the battery (back-up) terminal from which power is always supplied. • BLUE: This lead is for the power antenna connection. • BLUE/WHITE: This lead is for the remote amplifier connection. Speaker connections REAR FRONT REAR...
-
Page 12: Basic Operation
Basic operation Turning the unit on Press MUTE/PWR (MUTE/PWR on the remote control) or any other buttons. Note : When you insert the CD in the CD slot, the unit turns on. Turning the unit off Press and hold MUTE/PWR (MUTE/PWR on the remote control). Inserting a disc Insert the disc, and starts playback automatically. - Page 13 Dual Zone mode You can listen to the main source through the speakers, and to the secondary source through the monitor inserted into the cradle or the one connected the REAR OUT jacks. Press RSE on the remote control repeatedly to select a source. RSE ON t RSE OFF t RSE ON...
- Page 14 Changing the general settings 1 Press and hold MENU on the control panel so that one of menu items appears. 2 Press MENU to scroll between menus . AUX ON t AUX 0dB t DEMO OFF t BEEP 2ND t AUX ON... 3 Rotate the volume knob clockwise or unclockwise to select one of the settings.
-
Page 15: Radio Operation
Radio operation Listening to radio stations 1 Press SOURCE (SRC on the remote control) to select the tuner. 2 Press BAND repeatedly to select a band. The indicator lights up in the following order. FM1 t FM2 t FM3 t MW(AM) 3 Auto Search : Press I I i i ( on the remote control). -
Page 16: Cd/Mp3/Wma Operation
CD/MP3/WMA operation Playing an Audio CD and MP3/WMA disc The unit can play MP3/WMA formatted recordings on CD-ROM, CD-R or CD-RW discs. Before playing MP3/WMA recordings, read the notes on MP3/WMA Recordings on page 35. If you change the source, CD play also stops (without ejecting the CD). Next time you select “CD”... - Page 17 Pause 1 Press X (X on the remote control) during playback. 2 To return to playback, press X (PLAY(B B ) or X on the remote control). Skip to next or previous track/file During playback, press I I or i i (. or > on the remote control) to go to the next track/file or to return to the beginning of the current track/file.
- Page 18 Shuffle All of the tracks/files (SHF) or the current selected folder ( SHF) on the disc is played randomly. 1 Press SHF during playback. – (or SHF ) appears on the display window. Press and hold SHF for about 2 seconds during playback. –...
-
Page 19: Display Menu
DISPLAY menu Movie Displaying Disc information on-screen You can display various information about the disc loaded on-screen. 1. Press DISPLAY during playback. The displayed items differ depending on the disc type or playing status. 2. You can select an item by pressing U U / u u ( on the remote control) and change or select the setting by pressing I I i i (... -
Page 20: Set Up Menu
SET UP menu Initial Settings By using the Setup menu, you can make various adjustments to items such as picture and sound. You can also set a language for the subtitles and the Setup menu, among other things. For details on each Setup menu item, see the pages 20 to 24. 1 Press DVD SETUP or press and hold DISC MENU/SETUP on the remote control. - Page 21 DISPLAY TV Aspect 16:9 : Select when a 16:9 wide TV is connected. 4:3 Letter Box : Select when a standard 4:3 TV is connected. Displays a wide picture with bands on the upper and lower portions of the screen. 4:3 Panscan : Select when a standard 4:3 TV is connected.
- Page 22 AUDIO Each DVD disc has a variety of audio output options. Set the player’s AUDIO options according to the type of audio system you use. Dolby Digital / DTS / MPEG Bitstream: Select “Bitstream” if you connect the Car DVD Receiver’s DIGITAL OUT jack to an amplifier or other equipment with a Dolby Digital, DTS or MPEG decoder.
- Page 23 1 Select “Rating” on the Lock menu then press i i ( on the remote control). 2 To access the Rating, Password and Area Code features, you must input the 4-digit security code you created. If you have not yet entered a security code you are prompted to do so.
-
Page 24: Dvd/Vcd Operation
Others Set Playback Control (PBC) to On or Off. On: Video CDs with PBC are played according to the PBC. Off: Video CDs with PBC are played in the same way as Audio CDs. DivX VOD ® We provide you the DivX VOD (Video On Demand) registration code that allows you to rent ®... - Page 25 Use the numeric buttons to select the track you want to view. Press DISC MENU/SET UP or RETURN on the remote control to return to the menu screen. Menu settings and operating procedures may differ. Follow the instructions on the each menu screen.
- Page 26 Moving to another CHAPTER/TRACK When a title on a disc has more than one chapter or a disc has more than one track, you can move to another chapter/track as follows: Press I I /i i ( on the remote control) briefly during playback to select the next ?m/M? chapter/track or to return to the beginning of the current chapter/track.
- Page 27 Time search The Time Search function allows you to start playing at any chosen time on the disc. 1. Press DISPLAY during playback. The on-screen display appears on the screen. The Time Search box shows the elapsed playing time of the current disc. 2.
-
Page 28: Photo Operation
ZOOM The Zoom function allows you to enlarge the video image. Press ZOOM on the remote control repeatedly during playback or in the pause mode. - DVD : 100% → 400% → 1600% → 100%..., Video CD : 100% → 400% → 100%... You can move through the zoomed picture using buttons. -
Page 29: Movie Operation
Moving to another folder Press U U /u u ( on the remote control) to select the previous or next folder in the disc. Moving to another file Press I I i i ( on the remote control) to select the previous or next file in the selected folder. - Page 30 • Playable Subtitle format : SubRip(*.srt), SAMI(*.smi), SubStation Alpha(*.ssa), MicroDVD(*.sub), SubViewer, 2.0(*.sub), TMPlayer(*.txt), DVD Subtitle System(*.txt), Advanced Substation Alpah(*.ass) • Playable Codec format : DivX3.x, DivX4.x, DivX5.x (*.avi, *.divx, *.div), MP4S (*.asf), Xvid (*.avi, *.xvid) • Playable Audio format : "Dolby Digital", "MP3" •...
- Page 31 Still picture and frame-by-frame playback 1. Press X (X on the remote control) during playback. The unit will now go into the PAUSE mode. 2. You can advance the picture frame-by-frame by pressing X repeatedly on the remote control. 3. To return normal playback, press X (PLAY( ) on the remote control).
-
Page 32: Aux Operation
Time search The Time Search function allows you to start playing at any chosen time on the file. 1. Press DISPLAY during playback. The on-screen display appears on the screen. The Time Search box shows the elapsed playing time of the current disc. 2. -
Page 33: Troubleshooting
Troubleshooting : Symptom , : Cause, : Correction Power doesn’t turn on. / The unit There’s no picture. doesn’t operate. The parking brake cord is not Leads and connector are not connected. properly connected. Connect a parking brake cord, Confirm once more that all and apply the parking brake. -
Page 34: Language Code List / Area Code List
Language Code List Enter the appropriate code number for the initial settings “Disc Audio”, “Disc Subtitle” and/or “Disc Menu” (See page 20). Language Code Language Code Language Code Language Code Abkhazian 6566 Fiji 7074 Lingala 7678 Singhalese 8373 Afar 6565 Finnish 7073 Lithuanian... -
Page 35: Reference
Reference ® Playing DivX VOD content ® Some DivX VOD (video on demand) content may only be playable a fixed number of times. ® When you load a disc containing this type of DivX VOD content, the remaining number of plays is shown on-screen and you then have the option of playing the disc (thereby using up ®... -
Page 36: Specifications
Specifications GENERAL Output Power ..........50W x 4CH (Max.) Power Source .
