- Page 1 MADE IN MADE IN BELGIUM The only limitation is your imagination ... Hugyfot User Manual HFN-D810 Hugyfot User Manual HFN-D810...
-
Page 3: Table Of Contents
Fixing a sync cord ................Fixing an optical adapter ............Fixing the strobe arms ..............Fitting a viewfinder .................. Using the HugyCheck system 11-12 ..........On/off & battery status switch ..........Vacuum system ................Leakage alarm ................... Hugyfot User Manual HFN-D810... - Page 4 Philosophy The HugyCheck system is awarded ‘Innovation of the year 2009’ at Duikvaker in Utrecht. From the early start in 1953, the Hugyfot philoso- phy consisted of developing housings that were not The HugyCheck system allows the diver to check...
-
Page 5: Introduction
Your Hugyfot housing has been designed and developed by using the latest CAD/CAM techniques. It has been milled out of a solid block of seawater re- sistant aluminum and has been treated with a Teflon coating after it has been anodised. -
Page 6: Safety Precautions
These can cause fire and are harmful to your health. sync cords whenever they are connected to the housing bulk heads. Greasing the threaded part will allow swift fitting and removal of the connectors and will avoid corrosion on the bulkheads. Hugyfot User Manual HFN-D810... -
Page 7: Housing Overview
36. Qual button 9. Lens release 23. Exposure compensation 37. ISO button 10. AF/MF swich 24. AF-On button 38. White balance button 11. HugyCheck one way valve 25. Shutter speed control 39. Bracketing button 12. Playback button 26. AF-Lock lever 40. Flash compensation 13. Delete button 27. Neoprene handstrap 41. AF-mode button 14. Menu button 28. Multi selector Hugyfot User Manual HFN-D810... -
Page 8: Installing The Camera
(velcro) and is will activate the battery test mode. Green close placed outside of the housing. open LED: battery is OK. Red LED: replace battery. Pushing the switch to the left: activate Hu gyCheck system (LED blinks red/green/red). Hugyfot User Manual HFN-D810... - Page 9 (5). The top side of the back shell should be about 3 cm over the top side of the front shell. Gently lower the top part of the back shell while bringing it backwards (6). While bringing the back shell backwards, Hugyfot User Manual HFN-D810...
-
Page 10: Fitting The Lens
When using fixed focal lenses, fit the focus gear (if applicable) before fitting the lens to the camera body. Hugyfot provides several zoom and focus gears depending on the brand, model or type of lens. Please check the lens charts on our website to look up the appropriate zoom or focus gear for your lens. -
Page 11: Fitting The Port
7. Fitting the port Depending on the lens being used, different Hugyfot ports and extension rings are available. Please check our port charts in order to determine which port and extension ring you need for a specific lens. Before fitting any port or extension ring, make sure that it is fitted with the proper O-ring (black 105x3) and see to it that this O-ring is clean, slightly greased and that it doesn’t show any damage... -
Page 12: Connecting The Strobes
Your Hugyfot housing comes with three 25mm (1”) arm balls (one on top of each handle and one on top of the housing). The Hugyfot strobe arms are also Each sync cord (whether it is a 5-pin or a 6-pin) will have a plug on the hou- equipped with 25mm (1”) arm balls on both ends and are fixed to the housing... -
Page 13: Fitting A Viewfinder
10. Using the HugyCheck system 9. Installing a viewfinder (standard, straight or 45°) Your Hugyfot underwater housing is equipped with the ‘genuine’ HugyCheck pre- Your Hugyfot housing comes with a stan- dive check system. Introduced in 2008, this system has constantly proven its... -
Page 14: Vacuum System
LED will be reactivated while the green LED will stop blinking. When opening the housing after a dive, the vacuum has to be released by unscrewing the one way valve from the bulkhead. Hugyfot User Manual HFN-D810... - Page 16 Fits your camera like a glove Hugyfot NV Industrielaan 30 - Zuid III - 9320 Erembodegem - Belgium www.hugyfot.com - info@hugyfot.com...
