Summary of Contents for ATC ATC-PremBlade15
- Page 1 INTELLIGENT FACILITY SOLUTIONS Electric Works, 3 Concourse Way Sheffield, S1 2BJ, United Kingdom Phone UK: +44 (0) 114 354 0047 Phone Eire: +353 190 36387 sales@ihdryers.co.uk https://www.intelligenthanddryers.com/...
- Page 2 Hand Dryer Model: ATC-Premblade15 Installation & User Manual Issue number 1...
-
Page 3: Table Of Contents
Contents Contents Specification, Packing List, Mounting Height Precautions before installation & Installation Location Installation Operation Routine Cleaning Troubleshooting & Electrical Diagram Part Names and Dimensions Warranty ►This hand dryer should be installed by a qualified electrician or a trained service technician. ►Read this manual thoroughly before using the hand dryer to ensure safe and correct operation. -
Page 4: Specification, Packing List, Mounting Height
Specification Product Code ATC-PremBlade15 Finish Silver Warranty 3 years Activation Automatic Voltage 220-240V AC 1~ Frequency (Hz) 50/60 Power output (W) 975 + 1000 (heater) @ 230V Motor power (W) Current (A) 8.5 @ 230V Air Speed 95 m/s Sensor (Adjustable or Fixed) -
Page 5: Installation Location
Precautions before installing Do not install the unit in the following locations; installation in these areas will cause the unit to malfunction: • Locations where the unit is under direct sunlight or where direct sunlight can pass over the unit. •... -
Page 6: Installation
Installation 1. Install a wall box. Install a flush mounting wall box as per diagram 1 NB. If a wall box is not used the power cable will not sit flush with the wall and prevent the unit from being firmly installed against the wall. 2. -
Page 7: Operation
If this happens turn off the hand dryer and wait one minute until all the indicators and the display turn off. After this time switch the power back on. If the indicator is still flashing and/or the error code is on the display please contact the ATC Technical Department for advice. -
Page 8: Routine Cleaning
Routine Cleaning arrow on top of the cover. and then Cleaning the Unit body remove the cover completely. • Before cleaning switch off the power to 3. Wash out the interior of the drain the hand dryer. Do not spray water on the tray 4. -
Page 9: Troubleshooting & Electrical Diagram
Check the air speed switch. If the switch is on low then change it to high. If the above solutions do not solve the problem, turn off the power to the hand dryer and call your installer or the ATC Technical Department for advice. -
Page 10: Part Names And Dimensions
Part Names and Dimensions... -
Page 11: Warranty
ATC Electrical &Mechanical provides a limited 3-year parts warranty for the ATC-PremBlade15 blade hand dryer as long as the following conditions are followed: 1. Installation and use of the ATC-PremBlade15 blade hand dryer is in accordance with the instruction manual, which is packed with each ATC-PremBlade15 blade hand dryer.
