Samsung UA55C9000SR User Manual

Series 9.
Hide thumbs
Most useful pages: More
  • Contents

Advertisement

Table of Contents
Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.
Country
Customer Care Centre
AUSTRALIA
1300 362 603
NEW ZEALAND
0800 SAMSUNG (0800 726 786)
CHINA
400-810-5858
010-6475 1880
HONG KONG
(852) 3698-4698
INDIA
3030 8282
1800 110011
1800 3000 8282
1800 266 8282
INDONESIA
0800-112-8888
021-5699-7777
JAPAN
0120-327-527
MALAYSIA
1800-88-9999
PHILIPPINES
1-800-10-SAMSUNG(726-7864)
1-800-3-SAMSUNG(726-7864)
1-800-8-SAMSUNG(726-7864)
02-5805777
SINGAPORE
1800-SAMSUNG(726-7864)
THAILAND
1800-29-3232
02-689-3232
TAIWAN
0800-329-999
VIETNAM
1 800 588 889
© 2010 Samsung Electronics Co., Ltd. All rights reserved.
BN68-03034A-01Eng-Cover.indd 1
Web Site
www.samsung.com
www.samsung.com
www.samsung.com
www.samsung.com/hk
www.samsung.com/hk_en/
www.samsung.com
www.samsung.com
www.samsung.com
www.samsung.com
www.samsung.com
www.samsung.com
www.samsung.com
www.samsung.com
www.samsung.com
BN68-03034A-03
LED TV

user manual

imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model _____________ Serial No. _____________
2010-06-04 오전 10:25:50
Previous page
Next page
Show quick links

Advertisement

   Related Manuals for Samsung UA55C9000SR

   Summary of Contents for Samsung UA55C9000SR

  • Page 1: User Manual

    Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Customer Care Centre AUSTRALIA 1300 362 603 NEW ZEALAND 0800 SAMSUNG (0800 726 786) CHINA 400-810-5858 010-6475 1880...
  • Page 2 Failing to do so may result in fire or a problem with the product due to an increase in the internal temperature of the product. ✎ When using a stand or wall-mount, use parts provided by Samsung Electronics only. If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the product falling.

  • Page 3: Table Of Contents

    Contents Getting Started Connections Basic Features Advanced Features Other Information This function can be used by pressing the TOOLS TOOLS button on the remote control. [UC9000]BN68-03034A-02Eng.indb 3 Accessories Viewing the Control Panel Mini Remote Control Viewing the Touch Control 10 Connecting to an Antenna 10 Plug &...

  • Page 4: Getting Started

    English [UC9000]BN68-03034A-02Eng.indb 4 Accessories y Cleaning Cloth y Component Adapter y AV Adapter y PC Adapter Samsung Wireless Lan Adapter For stand type y Warranty Card / Quick Setup Guide Cable Power Adapter y Maximum thickness - 0.55 inches (14mm)

  • Page 5: Viewing The Control Panel

    ✎ The product colour and shape may vary depending on the model. 3D Emitter Woofer Speakers ✎ To control the TV using the LED touch pad, tap the LED touch pad centered underneath the stand. The touch pad will slide out by itself. The LED touch pad will slide back in if unused for a specified period of time. 3D Emitter Power Indicator Remote control sensor...

  • Page 6: Mini Remote Control

    Getting Started The Mini Remote Control is a simplified remote control that consists of the power, channel and volume buttons only. ¦ ¦ Description ¦¦¦ Next channel Volume decrease Previous channel ✎ This is a special remote control for the visually impaired and has Braille points on the Channel and Volume buttons. ¦...

  • Page 7: Viewing The Touch Control

    [UC9000]BN68-03034A-02Eng.indb 7 Viewing the Touch Control Rear View Earphone jack 2. Insert the battery with the 3. Slide and close the battery Samsung logo facing up. Battery cover Charge Port cover in the direction of the arrow. English 2010-05-28 오후 2:28:28...
  • Page 8 EXITe: Exits the menu. Use these buttons in Media Play and Anynet+ modes (p. 35, 42). (�: Controls recording for Samsung recorders that have the Anynet+ feature) Buttons used in the Channel Manager, Internet@TV, Media Play menu, etc. Tap Services.

  • Page 9: Setting Up The Network

    The networked, Wi-Fi mode requires the largest number of setup steps. In addition, to use the networked, Wi-Fi mode, you need a working local area network and a wireless router. You also need to attach Samsung’s Wireless LAN Adapter (WIS09ABGN, WIS09ABGN2, or WIS10ABGN) to one of your TV’s USB ports. To use the Multimedia function, you need to install Samsung’s PC Share Manager on your PC.

  • Page 10: Connecting To An Antenna

    TV and Touch Control using the Samsung Wireless LAN Adapter. y Connect the Samsung Wireless LAN Adapter to the TV. You can connect the Samsung Wireless LAN Adapter using the method shown on page 31. y If the connection fails, reconnect the Samsung Wireless LAN Adapter and then try again.
  • Page 11 Connections Using an HDMI or HDMI/DVI cable: HD connection (up to 1080p) Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver, cable box, STB satellite receiver White ✎ HDMI IN 1(DVI), 2(ARC), 3, 4, PC/DVI AUDIO IN For better picture and audio quality, connect to a digital device using an HDMI cable.
  • Page 12 Connections Using a Component (up to 1080p) or Audio/Video (480i only) Cable Available devices: DVD, Blu-ray player, cable box, STB satellite receiver, VCR White Yellow White Blue Green ✎ To obtain the best picture quality, the Component connection is recommended over the A/V connection. Using an EX-Link Cable Connection Available Devices: External devices that support EX-Link.

  • Page 13: Connecting To An Audio Device

    Using an Optical (Digital) Cable Connection Available devices: digital audio system, amplifier, DVD home theatre ✎ DIGITAL AUDIO OUT (OPTICAL) When a Digital Audio System is connected to the of both the TV and the system. 5.1 CH (channel) audio is available when the TV is connected to an external device supporting 5.1 CH. When the receiver (amplifier or DVD home theatre) is set to on, you can hear sound output from the TV’s optical jack.

  • Page 14: Basic Features

    Basic Features How to Navigate Menu Before using the TV, follow the steps below to learn how to navigate the menu and select and adjust different functions. Keyboard TV Control Services INTERNET CONTENT MENU Navigation MENU button: Displays the main on-screen menu. 2 ENTERE / Direction button: Move the cursor and select an item.

  • Page 15: Other Features

    Using Favourite Channels ¦ My Channels (In Channel Manager) Shows all favourite channels. ■ Edit My Channels channels to desired my channels group. ✎ The “*” symbol will be displayed and the channel will be set as a My Channels. 1.

  • Page 16: Picture Menu

    Basic Features ■ Timer Viewing: You can set a desired channel to be displayed automatically at the reserved time. Set the current time first to use this function. ■ Sort: This operation allows you to change the programme numbers of the stored channels. This operation may be necessary after using the auto store.

  • Page 17: Changing The Picture Options

    Min Backlight: When Eco sensor is On, the minimum screen brightness can be adjusted manually. ✎ If Eco Sensor is On, the display brightness may change (become slightly darker or brighter) depending on the surrounding light intensity. ■ No-Signal Power Off (Off / 15 min / 30 min / 60 min): To avoid unnecessary energy consumption, set how long you want the TV to remain on if it’s not receiving a signal.

  • Page 18: Picture Options

    Basic Features Picture Options ✎ In PC mode, you can only make changes to the Colour Tone, Size and Auto Protection Time. Picture Options Colour Tone Size Digital Noise Filter MPEG Noise Filter HDMI Black Level Film Mode Motion Plus ▼...
  • Page 19 This exciting new feature enables you to view 3D content. In order to fully enjoy this feature, you must purchase a pair of Samsung 3D Active Glasses (SSG-2100AB, SSG-2200AR, SSG- 2200KR) to view 3D video. Samsung 3D Active Glasses are sold separately.
  • Page 20 Basic Features 3D emitter ✎ If there is any obstacle between the emitter and 3D Active Glasses, the proper 3D effect may not be obtained. ■ 3D Mode: Select the 3D input format. ✎ If you want to feel the 3D effect fully, please wear the 3D Active Glasses first, and then select 3D Mode from the list below that provides the best 3D viewing experience.
  • Page 21 How to watch the 3D image To watch in 3D, wear 3D glasses and press the power button on the glasses. Viewing 3D TV motion pictures for long periods may cause eye fatigue and/or dizziness. Cancel L Move E Enter e Exit 3D 3D Using the LEFT / RIGHT keys on the remote control, Using the LEFT / RIGHT keys on the remote control,...

  • Page 22: Sound Menu

    PC may differ in which case the same basic set-up information will almost always be applied. (If not, contact your computer manufacturer or Samsung Dealer.) 1. Click on “Control Panel” on the Windows start menu.

  • Page 23: Setup Menu

    Auto Volume (Off / Normal / Night) To equalize the volume level on each channel, set to Normal. ■ Night: This mode provides an improved sound experience compared to Normal mode, making almost no noise. It is useful at night. Speaker Select (External Speaker / TV Speaker) A sound echo may occur due to a difference in decoding...

  • Page 24: Menu Language

    Other Features ¦ Menu Language Set the menu language. Network (Network Type / Network Setup / Network Test / SWL(Samsung Wireless Link) / Connect SWL) For details on setting up options, refer to the “Network Connection” instructions (p. 28). General ■...

  • Page 25: Support Menu

    – Equalizer is not available. ■ BD Wise (Off / On): Provides the optimal picture quality for Samsung DVD, Blu-ray and Home Theatre products which support BD Wise. When BD Wise is turned On, the picture mode is automatically changed to the optimal resolution.

  • Page 26: Contact Samsung

    Installing the Latest Version ■ By USB: Insert a USB drive containing the firmware upgrade file, downloaded from “www. samsung.com,” into the TV. Please be careful not to disconnect the power or remove the USB drive until upgrades are complete. The TV...

  • Page 27: Advanced Features

    Advanced Features Using an HDMI/DVI Cable / a D-sub Cable Display Modes (D-Sub and HDMI/DVI Input) Optimal resolution is 1920 X 1080 @ 60 Hz. Mode Resolution 640 x 350 720 x 400 640 x 480 832 x 624 1152 x 870 720 x 576 1152 x 864 VESA CVT...

  • Page 28: Network Connection

    Advanced Features You can set up your TV so that it can access the Internet through your local area network (LAN) using a wired or wireless connection. Connecting to a Wired Network ¦ You can attach your TV to your LAN using cable in three ways: y You can attach your TV to your LAN by connecting the LAN port on the back of your TV to an external modem using a Cat 5 cable.
  • Page 29 Network screen appears. Network Network Type Network Setup Network Test SWL(Samsung Wireless Link) Connect SWL U Move E Enter R Return 4. On the Network screen, select Network Type. 5. Set Network Type to Wired. 6. Select Network Setup. The Network Setup screen appears.

  • Page 30: Connecting To A Wireless Network

    Connecting to a Wireless Network ¦ To connect your TV to your network wirelessly, you need a wireless router or modem and a Samsung Wireless LAN Adapter (WIS09ABGN2), which you connect to your TV’s side panel USB jack. See the illustration below.
  • Page 31 Notice The picture may appear corrupted or have static for some channels when the TV is connected to the Samsung Wireless LAN Adapter. In such a case, connect the Samsung Wireless LAN Adapter using a USB cable in a place that is not affected by radio interference.
  • Page 32 How to set up using PBC (WPS) If your router has a PBC (WPS) button, follow these steps: 1. Connect your TV to Samsung Wireless LAN Adapter as described in the previous section. 2. Turn on your TV, press the MENU remote, use the ▲...

  • Page 33: Network Setup (ad-hoc)

    Network Test, and then press the ENTERE button. Network Setup (Ad-Hoc) You can connect to a mobile device without an access point through the “Samsung Wireless LAN Adapter” by using a peer to peer network. ✎ This function is available when SWL(Samsung Wireless Link) is set to Off.
  • Page 34 1. Follow Steps 1 through 5 in the “How to set up using PBC (WPS)” (p. 32). 2. Select Samsung Wireless Link by using the ▼ button and press the ENTERE button to turn it On. 3. Select Connect SWL by using the ▼ button and press the ENTERE button.

  • Page 35: Media Play

    PC IP addresses should be the same and only the last part (the host address) should be changed. (e.g. IP Address: 123.456.789.**) 2. Using a LAN cable, connect between the external modem and the PC onto which the Samsung PC Share Manager programme will be installed.
  • Page 36 The Divx DRM, Multi-audio, embedded caption does not supported. ✎ Samsung PC Share manager should be permitted by the firewall programme on your PC. ✎ When you use Media Play mode through a network connection, According to functions of the provided server: The sorting method may vary.
  • Page 37 Screen Display ¦ Move to the file you desired using the up/down/right/left buttons and then press the ENTERE or � (Play) button. The file is played. ✎ Supports the View Devices and Home in Media Play homepage. Information: You can ascertain the selected file name and the number of files and page.
  • Page 38 – Below 1280 x 720: 60 frame max – Above 1280 x 720: 30 frame max • GMC 2 over is not supported. • H.263 is not supported. • Only Samsung Techwin MJPEG is supported. English [UC9000]BN68-03034A-02Eng.indb 38 Frame rate Video Codec Resolution (fps) Divx 3.11 / 4.x / 5.1 / 6.0...
  • Page 39 Playing movie file continuously (Resume Play) If you exit the playing videos function, it can be played later from the point where it was stopped. ✎ If you press the ENTERE (Chaptering) button during playing the file, you can explore scene divided into 5 chapters you want.
  • Page 40 Advanced Features Playing the Multiple Files ¦ Playing the selected video/music/photo files 1. Press the Yellow button in the file list to select the desired file. 2. Repeat the above operation to select multiple files. ✎ NOTE The c mark appears to the left of the selected files. To cancel a selection, press the Yellow button again.
  • Page 41 Videos/Music/Photos Play Option menu During playing a file, press the TOOLS Category Title You can move the other file directly. Repeat Mode You can play movie and music files repeatedly. Picture Size You can adjust the picture size for preference. Picture Setting You can adjust the picture setting.

  • Page 42: Anynet

    Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it.

  • Page 43: Setting Up Anynet

    Anynet+ Menu The Anynet+ menu changes depending on the type and status of the Anynet+ devices connected to the TV. Anynet+ Menu Description View TV Changes Anynet+ mode to TV broadcast mode. Shows the Anynet+ device list. Device List (device_name) MENU Shows the connected device menus.

  • Page 44: Listening Through A Receiver

    Advanced Features Recording ¦ You can make a recording of a TV Programme using a Samsung recorder. 1. Select Recording. ✎ When there are more than two recording devices When multiple recording devices are connected, the recording devices are listed. Select one recording device in the Device List.

  • Page 45: Troubleshooting For Anynet

    Troubleshooting for Anynet+ ¦ Problem Possible Solution Anynet+ does not work. • • • • • • • • • • I want to start Anynet+. • • I want to exit Anynet+. • • • The message “Connecting to •...

  • Page 46: Internet@tv

    Login Mark as Favourite Sort by R Return Recommended Applications: Displays the recommended service by Samsung. You are not able to add or delete a service in this list. Downloaded Applications: Displays the downloaded applications through the Samsung Apps. 2010-05-28 오후 2:29:22...
  • Page 47 Account Login For a application with multiple account, use ◄ and ► to access the different account. Login admin User account : Password : ✎ For a more enjoyable application experience, register and log in to your account. ✎ For instructions on creating an account, refer to Settings →...

  • Page 48: Samsung Apps

    [Legal Statement] Due to the various capabilities of products featuring the Samsung Internet@TV - Content Service, as well as limitations in the available content, certain features, applications, and services may not be available on all devices or in all territories. Some features on Internet@TV may also require additional peripheral devices or membership fees that are sold separately.

  • Page 49: Allshare

    TV as a monitor for your mobile when browsing a web page. ✎ For more information, visit “www.samsung.com” or contact the Samsung call centre. Mobile devices may need additional software installation. For details, refer to each device’s user’s guide. ¦...
  • Page 50 Advanced Features Using the Message Function Using this function, you view call arrivals, SMS messages and schedules set on the mobile phone through the alarm window while watching TV. ✎ NOTE To disable the alarm window, set Message to Off in Setup of AllShare.
  • Page 51 The screen display may differ depending on the connected device. Contacts Using your Samsung phone to control your TV Simply Before you can use this feature, you must connect to a Samsung mobile phone that supports ScreenShare functions. When operating the TV with your mobile phone, only the POWER, Y, P</>...

  • Page 52: Other Information

    Other Information Wall-Mount Type (UA55C9000ZR) ✎ Do not pull the cables too hard when arranging them. This may cause damage to the product’s connection terminals. Caution: Pulling, pushing, or climbing onto the TV may cause the TV to fall. In particular, ensure that your children do not hang over or destabilize the TV;...

  • Page 53: Troubleshooting

    If you have any questions about the TV, first refer to this list. If none of these troubleshooting tips apply, please visit “www. samsung.com,” then click on Support, or contact the call centre listed on the back-cover of this manual.
  • Page 54 • If you are using a HDMI connection, check the audio output setting on your PC. • Samsung Wireless USB dongle is required to use a wireless network. • Make sure the Network Connection is set to Wireless (p. 30).
  • Page 55 These pixels will have no impact on the performance of the product. ¦ Licence Without producing harmful VOC (Volatile Organic Compounds), Samsung’s Eco-friendly “Crystal Design” expresses colour gradation thanks to our dual injection technology. TheaterSound, SRS and the TheaterSound technology is incorporated under licence from SRS Labs, Inc.

  • Page 56: Enclosed Wireless Lan Adapter

    Other Information Features • Compatible with IEEE 802.11a/b/g and 802.11n draft 2.0 • Supports USB 2.0 • Compact and Lightweight Pocket-Sized Design • Supported Model: The Enclosed wireless LAN Adapter will only be work with the TV is was shipped with. Safety Precautions •...

  • Page 57: Specifications

    5% to 95%, non-condensing -20˚ ~ 20˚ UA55C9000ZR 55 inches 15W x 2 1295.6 x 33.9 x 784.4 mm 1295.6 x 306.1 x 873.3 mm 1295.6 x 306.1 x 873.3 mm 20.4 kg 26.5 kg UA55C9000SR 25.5 kg English 2010-05-28 오후 2:29:34...

  • Page 58: Index

    Other Information AllShare Amplify Anynet+ Auto Adjustment Auto Volume Background Music Balance L/R Basic View Batteries 6, 7 Black Tone Brightness Change PIN Channel Menu Clock Colour Tone Component Connecting to a PC Connecting to an Audio Device DIGITAL AUDIO OUT 13, 42 DivX®...
