- Page 1 MODEL : LK-P11B MOBILE PRINTER All specifications are subject to change without notice...
- Page 2 RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTURECITONS...
-
Page 3: Table Of Contents
1. Product overview Table of Contents 1. Product overview 2. Unpacking 3. Installation & Usage 3-1. Battery Installation Power switch 3-2. Battery Charging 3-3. Battery Charger Usage Paper feed Cover open button button 3-4. Belt Strap Usage 3-5. Separation of Battery from the printer 3-6. -
Page 4: Unpacking
2. Unpacking 3. Setting Up the Product 3-1. Installing battery Standard Printer Battery Belt Buckle Push the Open to the direction as pointed Open the battery cover and push up the hook to by arrow in the image. the direction as above. Recharger Serial Cable USB Shelded Cable... -
Page 5: Battery Charging
3-3. Battery charger Usage 3-2. Battery Charging 1. The battery can be charged only when the temperature is 0~40 1. Please press the battery into the holder until you can hear a snapping sound . ℃ 2. Be sure that the printer is turn off and the battery to be charged is installed. 2. - Page 6 3-4. Belt Hook Usage 3-5. Removing battery Insert the belt hook screw into the hole of the belt hook. Push the Open into the direction Push up the hook after opening the battery cover. indicated with the arrow in the image. As shown above, fasten the screw with a screw driver.
-
Page 7: Shoulder Strap Usage
3-7. Leather Case Usage 3-6. Shoulder Strap Usage Place the end of strap into the hook of Insert the strap into the hook on Put the printer into the leather case the printer. shoulder strap. Open the Velcro following the direction shown in the Close the Velcro After pulling out the end of strap Fasten the strap in the opposite side... -
Page 8: Control Panel Usage
3-9. Control Panel 3-8. Loading the media. Button Name function This button is used to turn the printer on and off. Power When the printer is off, press this button for approximately 2 seconds and button it will turn on the power. When you press this button in a state that the printer is on, the printer will turn off. -
Page 9: Self Test
3-10. Self Test < Sample Printout of Self Test > You can check the printer setting state by doing self test when you set the printer first time or encounter some problems. - Control Circuit, Mechanisms, Print Quality, Rom version. When you can not find the exact cause of problem through self test, investigate on other hardware parts or software. -
Page 10: Peripherals Connection
4. Peripherals Connection 4-2. Interface Cable Connection This product can communicate with other devises via Bluetooth communication and cable. 4-1.Bluetooth Connection Serial 1. The printer can be connected to devices equipped with Bluetooth communication capacity (PDA, PC, etc.) 2. Use the Bluetooth connection function supported by the device to connect to the printer. -
Page 11: Printer Cleaning
6. Pritner Specification 5. Printer cleaning 6-1. Specification If the interior of the printer is dusty, printing quality can lowered. In such a case, follow the instructions below to clean up the printer. Printing Method Direct Thermal NOTE Printing Speed 80mm/sec 1. - Page 13 SEWOO TECH CO.,LTD. ADDRESS Doosung Bd, 689-20, Kumjung-dong, Kunpo-si, Kyunggi-do, Korea TEL 82-31-459-8200 FAX 82-31-459-8880 URL http://www.miniprinter.com Rev. 1.0...
