Access Interfacing Solutions OCR640 Series User Manual

Model outline
The OCR640 captures the full page image and decode the machine readable zone
(MRZ) from documents complying to ICAO9303. The OCR640 has an integrated RFID
reader enables the device to simultaneously decode the contents of an e-passport or
contactless smart card.
Main features
1
2
3
4
5
1. Fixed cover
2. OCR reading window
3. Power and read indicators
Document orientation
The document should be placed with the Machine Readable Zone (MRZ) facing
downwards on the document guide. Slide the document under the cover until
fully inserted.
Connection
Plug in the USB connection to the host device and connect the DC power
connector to the power supply. The power indicator will illuminate green. The
OCR640 requires an application programme to be running on the host computer:
please refer to your system administrator.
4. Document guide
5. RJ50 connector
OCR640 Series
Optical MRZ Identity Checker with eMRTD
User Guide
How to read a document with OCR data
Orient the document correctly with the MRZ text down under the lid. Follow the
instructions provided by the host application.
If a read is unsuccessful then re-present the document; for persistent errors refer to
the Troubleshooting section.
How to read a document with data stored
on the chip
Orient the document correctly with the MRZ text down under the lid. Follow the
instructions provided by the host application.
If a read is unsuccessful then re-present the document; for persistent errors refer to
the Troubleshooting section.
