- Page 1 EC200XL Electrophoresis Power Supply LTM1595X2 8/28/07 © 2007 All rights reserved Printed in U.S.A.
-
Page 2: Table Of Contents
Thermo Scientific EC200 Electrophoresis Power Supply Table of Contents Safety Considerations Introduction Unpacking the Power Supply Specifications Getting Started Using the Power Supply Constant Voltage Operations Constant Current Operations Timed Operations Automatic Power-fail Restart Cleaning Troubleshooting and Error Indications EC200 Warranty Statement... -
Page 3: Safety Considerations
This equipment has been designed and tested to conform to CSA1010 safety standards, as applicable to laboratory instrumentation. This applies only to the EC200 when used as specified in the documentation, in its intended applications, with Thermo Scientific approved electrophoresis apparatus only. Usage in any other manor may not provide similar performance or safety protection. -
Page 4: Introduction
Introduction Thank you for selecting a Thermo Scientific EC200 Electrophoresis power supply. This manual describes the operation of the EC200. The power supply that you have purchased is the most productive and easy-to-use unit available anywhere. This manual should answer any questions that might arise in operating your power supply;... -
Page 5: Specifications
Specifications AC input Power 95-265VAC, 50-60Hz, 250VA Max Environmental Operating temperature: 0-40°C, 0-95% R.H. non-condensing Altitude: 2000m Overvoltage category II, IEC664 Pollution degree 2, IEC664 DC output Power 5-200VDC, 200W Max 0.01-2.00A, 200W Max Ripple: ± 1% Drift: ± 1%, after 30-minute warm-up Page 4... -
Page 6: Getting Started
Getting Started Select a location that allows for 3" clearance behind the power supply, and comfortable reach of the front panel controls and cell connections. Do not block the vented area of the case - on the front bottom of the unit, or the fan area at the rear. Connect the power supply to a 3-prong grounded AC outlet, using the AC cord provided with the unit only. -
Page 7: Constant Voltage Operations
setpoint. The run mode display shows the controlled parameter highlighted, and will automatically change if a crossover has occurred. To stop a run in progress, press the Run key, the Stop key, or the blue ON/OFF key. The display will change to "STOP" signifying that the output is no longer energized. To pause a run in progress, press the Pause key. -
Page 8: Automatic Power-Fail Restart
Enter a time parameter as described above for setting a voltage or current setpoint. Enter a time duration of 0-99 hours, 59 minutes. A time duration of zero effectively disables timed run mode. When running a timed run, the time parameter displays the time remaining in the run. When running a non-timed run, the time parameter displays the elapsed time during the run Automatic Power-fail Restart Automatic power-fail restart capability allows a timed run which is interrupted by loss of AC... -
Page 9: Troubleshooting And Error Indications
Troubleshooting and Error Indications The EC200 detects and reports several events and conditions that are considered errors. The EC200 will stop any run in process and display "ERROR XX" where XX is one of the below listed errors. When the EC200 is displaying an error indication, press the blue ON/OFF key to clear the error and return to setup mode, or press the Run key to resume the run (after correcting the cause of the error). -
Page 10: Ec200 Warranty Statement
EC200 Warranty Statement The Thermo Scientific Company ("Thermo") warrants to the direct purchaser that the EC200 will be free from defects in material or workmanship for a specified warranty period. During that period, Thermo will repair or replace the product or provide credit, at its sole option, upon prompt notification and compliance with its instructions.
