- Page 1 Installation a nd O peration M anual 600mm Integrated Rangehood Manual MODEL IRI6SE1 Installation and Operation -‐ 1 -‐ ...
-
Page 2: Table Of Contents
We thank you for choosing this quality appliance and hope you enjoy many years of reliable service. Please ensure this manual is read carefully before installation and use. Keep this manual in a safe and accessible location should future reference be required. Regards Home Appliances CONTENTS Contents Safety Warnings Dimensions... -
Page 3: Safety Warnings
Installation a nd O peration M anual SAFETY WARNINGS Installation of this Integrated Canopy Rangehood must be carried by a • qualified and competent installer. The manufacturer disclaims and liability for any damage or injury caused as a •... -
Page 4: Dimensions
Installation a nd O peration M anual DIMENSIONS -‐ 4 -‐ ... -
Page 5: Installation
Installation a nd O peration M anual INSTALLATION The IRI6WE3/ IRI9WE3/ IRI6SE1/ IRI9SE1 are designed to be installed fully integrated into an overhead cupboard as pictured below. The IRI6WE3/ IRI6SE1 is suited for a 600mm cupboard and the IRI9WE3/ IRI9SE1 is suited for a 900mm cupboard. - Page 6 Installation a nd O peration M anual INSTALLATION - Position of Mounting Bracket The Integrated Rangehood is mounted to the rear of the overhead cupboard. Supplied with the rangehood is a mounting bracket (Fig. 2) Fig.
- Page 7 Installation a nd O peration M anual INSTALLATION – Fitting of Integrated Rangehood Fit 150mm duct spigot (pictured below) with the four 8mm screws provided over the rectangular hole located at the top rear of the integrated rangehood. Fit 150mm flexible ducting (pictured below), supplied, to the ducting spigot, Using one of the nylon ties, supplied, secure the ducting to the duct spigot.
- Page 8 Installation a nd O peration M anual INSTALLATION – Ducted or Re-circulating The integrated rangehood can be installed in either ducted or re-circulating method. The integrated rangehood is supplied with a small length of flexible duct, although may not be sufficient in all installations.
- Page 9 Installation a nd O peration M anual INSTALLATION – Ducted or Re-circulating Re-circulation installation 150mm flexible duct is provided with the integrated rangehood for re-circulatiing installation. This type of installation can be executed to the top of a cupboard or through a bulkhead above the cupboard.
-
Page 10: Operation
Installation a nd O peration M anual OPERATION The integrated rangehood is fitted with push button Back-lit electronic controls. There is 1 light push button and 3 speed push buttons, Low, Mid and High to control the air flow speeds. -
Page 11: Maintenance And Cleaning
Installation a nd O peration M anual MAINTENANCE and CLEANING WARNING ALWAYS un-plug the rangehood PRIOR to any maintenance or cleaning being carried out, to avoid possible electric shock. To ensure long lasting performance and efficiency, regular maintenance and cleaning of your integrated rangehood should be performed. -
Page 12: Service
Installation a nd O peration M anual MAINTENANCE and CLEANING WARNING ALWAYS un-plug the rangehood PRIOR to any maintenance or cleaning being carried out, to avoid possible electric shock. Cleaning of Grease Filter We recommend cleaning of the grease filter to be done at least every 4 weeks.
