- Page 1 User Manual 520mm Rangehood UC52...
-
Page 2: Table Of Contents
Home Appliances CONTENT 2 …………………………………………………. Notice 3 …………………………………………………. Safety Warning 4 …………………………………………………. Function & Feature 5-6 ……………………………………………….. Installation 7-8 ……………………………………………….. Operation and Maintenance 9 ……………………………………………..…… Caution 10 …………………………………………..……. Abnormity and Solution Canopy Installation and Operation Manual Home Appliances – Oct 2013... -
Page 3: Notice
3. The manufacturer disclaims all liability for any damage or injury caused as a result of not following instructions for installation contained in the following text. The cooker hood is used on 220/240v, 50Hz. Canopy Installation and Operation Manual Home Appliances – Oct 2013... -
Page 4: Safety Warning
SAFETY WARNINGS • Installation of this Integrated Canopy Rangehood must be carried by a Qualified and competent installer. • The manufacturer disclaims and liability for any damage or injury caused as a result of not following instruction of installation contained in this instruction manual. -
Page 5: Function & Feature
FUNCTION AND FEATURE 1. The cooker hood is made of high quality materials with streamlined design accordingly to technical and physical engineering theory, high end and luxury with age aesthetic feeling, also there are kinds of styles for your option to perfect your kitchen. 2. -
Page 6: Installation
1. INSTALLATION 1) The cooker hood should be placed at a distance of 65-75cm (26-30inch) from the cooking surface for the best effect. 2) Drill a hole in the cabinet, with hole wide 500*275(mm) for 52CM and 730*275(mm) for model 75CM. Pic 1. Make sure the hole’s edge to the cupboard’s edge is at least 35mm distance. - Page 7 2. LIGHT REPLACEMENT 1) Open the S/S panel. 2) Remove the two screws of the lamp panel. Take out the lamp panel. Take out the LED strip from the lamp panel. Unplug the connector at the end of the lamp wire.
- Page 8 3. OPERATION How to use the control panel. Pic. 5: 1) Push the low button, the indicating light on, and the motor runs at low speed. Push it again and the motor will stop. 2) Push the middle button, the indicating light on, and the motor runs at mid speed.
- Page 9 2) To protect the main body from corrosion over a long period of time, the cooker hood should be cleaned with hot water plus soap or non corrosive detergent once a week. Do not use grinding detergent, or it will damage the body. 3) Keep the motor and other spare parts free from water, as this will cause damage to the appliance.
-
Page 10: Caution
6. CAUTION ² Keep your children from using the cooker hood. ² Your cooker hood is for domestic use only, not suitable for barbecue, roast shop and other commercial use. ² Any installation work must be carried out by a qualified electrician or competent person. -
Page 11: Abnormity And Solution
7. ABNORMITY AND SOLUTION Fault Cause Solution The bulb damaged Change bulb Light does not work, Bulb contact lamp cap bad Fix or change but motor work Light panel switch damage Fix or change Bulb contact lamp cap Restart later Motor bearings damage Change motor Light work, but motor... - Page 12 Distributed by: Home Appliances Pty. Ltd. 20 Carlotta Street, Artarmon NSW 2064 Tel: 02 9958 3111 Fax: 02 9958 3555 Email: info@hapl.com.au Website: www.hapl.com.au...
