- Page 1 LED TV/DVD Combo LT-22HD32J LT-22HD3WJ LT-24HD32J INSTRUCTIONS...
-
Page 2: Precautions
Dear Customer, [European Union] This apparatus is in conformance with the valid European directives and standards regarding electromagnetic compatibility and electrical safety. European representative of JVC KENWOOD Corporation is: JVC Technical Services Europe GmbH Postfach 10 05 04 61145 Friedberg Germany... -
Page 3: Table Of Contents
Features • USB-Media player for JPEG and WMA • 16:9 LCD screen • CI-Slot for CA- module • LED-Backlight-Technology • Auto Power Off after 4 hours with no operation • On-Screen Language Display in 18 languages DVD Player • DVB-C-HDTV-Tuner •... -
Page 4: Important Safety Information
Important safety information This unit has been produced according to all current safety regulations. The following safety tips should safeguard users against careless use and the dangers connected with such use. • Although this appliance has been carefully manufactured and rigorously checked prior to leaving the factory, as with all electrical appliances it is possible for problems to develop. -
Page 5: Important Instruction
Important safety information How to attach the stand NOTE: • Unplug the AC cord from the AC INPUT terminal. • Before performing work spread cushioning over the base area to lay the TV on. • Do not support the TV by the screen as sharp objects and too much pressure may cause damage. •... - Page 6 Important safety information To prevent fire, never place any type of candle or open WARNING flame on the top or near the TV set. Headphone Warning Loud music can damage your hearing irreversibly, therefore do not set the volume to a high level when listening through headphones, particularly for extended listening periods.
-
Page 7: Location Of Controls
Location of controls DVD-Player Description of Indicators and Controls 1. Remote sensor 2. Power indicator: The power indicator lights up red in standby mode, and blue in power - ON mode. 3. Loudspeakers (Power)-button: Preparation: Connect power-cable to AC220~240V/50Hz. Press power-button to enter standby mode or turn on the power. 5. -
Page 8: Remote Control
Remote Control Function Page Enter standby mode or turn on the power Display program position number 13, 29 Select between the available broadcast audio Change sound track language of DVD Eject a disc Select channel Select Teletext page Enter password 16, 33 Select title/chapter/track 28, 29... - Page 9 Remote Control Install the batteries Use batteries type UM3 (AA-Size). Do not use old or weak batteries. The remote control may not work properly with a weak voltage from such batteries. Replace exhausted batteries with new ones. Never try to recharge normal batteries - this could cause an explosion.
-
Page 10: Antenna Connection
Antenna connection Note: Before you connect other appliances: • To avoid potentially damaging your set, make sure all items are switched off and disconnected from the mains power when you make the connections. • Arrange the desired connection. • When you have finished making the connections, reconnect the mains power to the unit and switch it back on. -
Page 11: Auto Setup
TV will search for Digital TV-channels at first. Auto setup Connect your DVB-T antenna (or DVB-C The built-in tuner receives DVB-C, DVB-T and Cable- antenna if you selected “Cable” at step 5) now. analogue. At the first time you operate after the Continue with ENTER to start auto tuning. -
Page 12: On-Screen Language Selection
On-screen Language Selection Station search Warning! All previously saved channels are Select Feature (unless you have already deleted in Step 5. A new channel search then selected when the set was first switched on) starts automatically. then press . Then press to select Language, then press . -
Page 13: Manual Station Search
Manual Station search Basic Operation Digital Manual Search Channel selection With the numbered buttons. Channel - Digital Manual Search Example: • No. 2: Press 2. Frequency(kHz) 474000 • No. 29: Press 2 and within 2 seconds, press 9. Picture • No. -
Page 14: Teletext
QuickView Select Page button allows you to go back to the last selected Press P + or – until the page you desire appears. Or TV channel..enter the requested page number by using the 10 • This feature is not available in external input mode and Number Buttons. -
Page 15: Remarks On Dvb-T System
Remarks on DVB-T system DVB-T is at present still being developed. You can get information regarding the current stage of development from your specialist retailer. As a digital service DVB-T basically works differently to previous analogue TV reception. Reception Possibilities: In contrast to cable TV, DVB-T is received via room or roof antennas. -
Page 16: Password Setup (Parental Lock)
Password Setup (Parental lock) EPG (Electronic Program Guide) Parental lock is a function of the channel The Guide menu shows the available provider. If it is not supported by the channel, programme listings for the next 8 days only, parental lock is without function. Currently there including today. -
Page 17: Picture Size And Resolution
Picture size and resolution Resolution and picture quality Broadcast wide screen films in different resolutions. The following table shows the resolution options for wide screen film broadcast media. Broadcast media Resolution of the wide Analogue Digital DVB-T Satellite HDTV Blu-ray- screen signal cable TV cable TV... -
Page 18: Picture Format
Picture format Picture Size Other formats The required picture format can be set by pressing Press PICTURE SIZE until the desired size is the PICTURE SIZE button. Press PICTURE SIZE reached. until the required format is displayed. You move through the following formats when you The picture is displayed in 4:3 press the button: Auto, 4:3, 16:9, 14:9, Cinema, format with black bars to the... -
Page 19: Other Convenience Functions
Other convenience functions Selected Items Setup hint Picture Picture Mode Standard Standard picture quality (factory-set) Vivid Enhanced picture contrast and sharpness (factory-set) Soft Intended for bad-quality signals (factory-set) User Your personal preferences Brightness / Contrast / Sharpness / Colour / Tint You can adjust the picture to your preference. - Page 20 Other convenience functions Selected Items Setup hint Feature Child Lock See page 16. Language OSD Language See page 12. Preferred Subtitle Select preferred subtitle language, if the current watching DVB channel has more than one subtitle language. If the preferred subtitle language set here is not transmitted in the channel, the first displayed subtitle language in Subtitle language menu (P.13) is automatically selected.
- Page 21 Other convenience functions Selected Items Setup hint Setup OSD Timer The OSD is cleared automatically as per this setting. But if you select “Never”, the OSD is not cleared 5/10/15/20/25/30 Seconds/Never automatically .(Press RETURN to clear.) SCART Input Auto Factory setting, normally OK. when RGB is input.
-
Page 22: Media Operation
Media Operation Media Browser You can enjoy viewing pictures and playing music Current File/Total Files from your USB-Stick. Thumbnail window Connect the USB-Stick into the Media Input Media Selection File Path File/Folder List terminal. Press MEDIA. Media Browser will appear. Photo /udska1/pic Pic1.JPG... -
Page 23: Playback Files
Playback files Press ◀/▶ to select (Music) or (Photo) at Media Selection and press ▼. Select folder or file with ▲ or ▼, and then start the playback with ENTER. • Press RETURN to return to Media Selection. You can playback the files with the following remote control buttons. -
Page 24: Playable File Types
Playable File Types Photo Type Extension Name Compression Spec / Limitation Baseline Non-support JPEG 2000 compression JPEG .jpg .jpeg Progressive Color type : YCbCr (Non-support CMYK) Support JPEG/JFIF and JPEG/Exif file format Picture size limitation: Baseline: Number of horizontal pixels: up to 165370 Progressive: Number of horizontal pixels: up to 61648 •... -
Page 25: Disc
Disc DVD discs must be Region 2 or Region ALL type to play on this unit. Example: The loaded Disc (DVD and Audio-CD) will be recognized automatically. The suitable disc formats are: DVD-ROM, DVD-Video, DVD-R/-RW/-R DL, Audio CD, Fujicolor CD, KODAK Picture CD, CD-R/CD-RW, CD-ROM. Some CD-R/RW discs may be incompatible. - Page 26 Disc Playing Audio files WMA and MP3 files recoded in DVD-R/-RW/-R DL, PC-created disc compatibility CD-R/-RW can be played. • You may not be able to play discs recorded using a personal computer or recorder for disc Windows Media Audio (WMA) compatibility compatibilities, scratches or marks on the disc, •...
-
Page 27: Playing A Disc
Playing a disc To pause playback (still mode) Press during playback. This section shows you the basics on how to To resume normal playback, press PLAY ( play a disc. • The sound is muted during still mode. Basic playback (DVD/Audio CD) To stop playback Preparation Make sure that the... -
Page 28: Zooming (Dvd)
Playing in slow-motion (DVD) Press ENTER. Playback starts. Press during playback. • When you change the title, playback starts Each time you press , the slow-motion from Chapter 1 of the selected title. speed changes. • Some discs may not work in the above operation. -
Page 29: Changing Angles (Dvd)
Changing angles (DVD) Using HOME MENU When playing back a disc recorded with multi-angle Playing a disc facility, you can change the angle that you are Press SETUP during stop mode. viewing the scene from. HOME MENU will appear. Press ANGLE during Current/Total Press / / playback. -
Page 30: Play Mode
Play mode Program playback A-B repeat playback Press PLAY MODE during playback. A-B repeat playback allows you to repeat selection Play Mode screen will appear. between two selected points. Press / to select “Program”, then press Press PLAY ENTER. Play Mode MODE during Press / to A-B Repeat... -
Page 31: Audio Settings Menu
Sharpness Audio Settings menu Adjust sharpness of images. The Audio Settings menu offers features for Brightness adjusting the way discs sound. Adjust brightness of images. Press SETUP during stop mode. Contrast HOME MENU will appear. Adjust a ratio of brightness between the brightest part and the darkest part. - Page 32 Customizing The Function Settings Setting Option Setup hint Digital Audio Out settings Digital Out Digital audio is output when playing a disc. Digital audio is not output when playing a disc. Dolby Digital Out Dolby Digital Dolby Digital encoded digital audio is output when playing a Dolby Digital DVD disc.
-
Page 33: Parental Control
Parental Control Level Change Some discs are specified as not suitable for Press Initial Settings children. Such discs can be limited not to playback select “Level Digital Audio Out Parental Lock Password Change with the unit. Change”, then Video Output Level Change Language Country Code... -
Page 34: Language Code List
Language Code List Language (Language code letter), Language code Japanese (ja), 1001 Bhutani (dz), 0426 Kirghiz (ky), 1125 Sinhalese (si), 1909 English (en), 0514 Esperanto (eo), 0515 Latin (la), 1201 Slovak (sk), 1911 French (fr), 0618 Estonian (et), 0520 Lingala (ln), 1214 Slovenian (sl), 1912 German (de), 0405 Basque (eu), 0521... -
Page 35: Pc Connection
PC connection Follow these steps: On your PC monitor choose a resolution of 1920 × 1080 at 60Hz and save this configuration. Shut down your PC and connect the shut off LCD TV. Use a screensaver to avoid burning-in of static picture content. Select PC input Use a PC-VGA cable (not supplied) to connect the LCD-Monitor to your PC. - Page 36 Connection to other equipment 2. Connecting to other equipment Please connect your satellite-receiver or DVD player via SCART. Make sure your SCART cable’s cross- section is at least 1 cm or more. SCART cables with less thickness may cause visible noise. Please make the following settings inside your receiver’s / DVD-player’s setup-menu: Video signal: RGB TV-Format: 16:9...
-
Page 37: Troubleshooting Table
Troubleshooting table Please check the following list before requesting service. Symptom Possible solution Page No picture, no sound Switch on the set. Check that the mains power outlet is properly connected. Select appropriate input mode. Unplug unit for 1 minute, then plug it back in. No reception Have you tuned in the TV stations? Press 1 on the remote control. -
Page 38: License Information
License information * The “HD ready” Logo and “1080p” qualifier Logo are trademarks of DIGITALEUROPE. * This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited. * Manufactured under license from Dolby Laboratories. -
Page 39: Specifications
Specifications LT-22HD32J/LT-22HD3WJ LT-24HD32J System: Analogue: PAL (B/G, D/K, I), SECAM (B/G, D/K) Digital: DVB-T, DVB-T HD (H.264), DVB-C, DVB-C HD (H.264) Video Colour System: PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60 Preset channels: Digital 1200 Service, Analog 100 Carrier Frequency Range: Analogue: 45.75~858MHz... - Page 40 JVC has assigned the service and in warranty responsibility to Kesa Electricals plc. FOR CUSTOMER SERVICE, ADDITIONAL SET-UP AND OPERATING ASSISTANCE, OR TO ORDER ACCESSORIES PLEASE CALL: Country Sales URL Main Service Contact Company COMET 0844 8009595 http://www.comet.co.uk France DARTY 0978970970 http://www.darty.com/...
