Belkin
Wireless G Notebook Card
User Manual
F5D7010 / F5D7010v7

Table of Contents

1 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . X
Benefits of a Home Network......................................................x
Advantages of a Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . X
2 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . X
Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . X
Applications and Advantages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . X
Product Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . X
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . X
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . X
3 Installing and Setting up the Card . . . . . . . . . . . . . . . . . . . . . . . . . . . X
Step 1: Install. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .X
Step 2: Insert .......................................... X
Step 3: Configure. . . . . . . . . . . . . . . . . X
Accessing the Belkin Wireless Networking Utility from the Windows System Tray
Setting Wireless Network Profiles . . . . . . . . . . . . . . . . . . . . . X
Securing your Wi-Fi Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . X
5 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . X
6 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . X
Introduction
Thank you for purchasing the Belkin Wireless G Notebook Card. Now you can
take advantage of this great new technology and gain the freedom to network
your home and office computers wirelessly. This Card allows you to connect a
notebook computer to your network. Please be sure to read through this User
Manual completely, and pay special attention to the section entitled "Placement
of your Wireless Networking Hardware for Optimal Performance".
