- Page 1 COUNTERTOP DISPLAY FREEZER Model SCFU386 Instruction Manual BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Write Serial No. (on rating label) here: Felix Storch, Inc. 770 Garrison Avenue ____________________________ Bronx, NY 10474 www.summitappliance.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Appliance Safety ................. Important Safeguards ..............Location of Parts, Control Panel ..........Technical Information ..............Installation Instructions ............. Moving and Installing Your Appliance ........Electrical Connection .............. Operating Your Appliance ............Turning On the Freezer ............Storing Items in the Unit ............Defrosting the Unit .............. -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 • Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result in electrical shock or death. • Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in this manual.
-
Page 5: Location Of Parts, Control Panel
LOCATION OF PARTS Temperature control, light switch and anti-sweat switch (on back of cabinet) Interior light Gasket Adjustable feet (4) (self-closing) Control Panel For switching the interior light on and off and for adjusting the storage temperature, use the control panel located on the back of the cabinet. Temperature control dial Temperature Control Dial... -
Page 6: Technical Information
TECHNICAL INFORMATION Model SCFU386 Climate Class Installation Free-standing Capacity 2.0 ft Electrical Input 115V AC 60Hz Power Input 155W Rated Current 4.0A Refrigerant R134a, 3.18 oz Lamp Wattage Unit Weight 83 lbs Unit Dimensions 24.7" W X21.7"D X 23.4"H NOTE: Specifications are subject to change without notice. INSTALLATION INSTRUCTIONS ... -
Page 7: Electrical Connection
Electrical Connection Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is damaged, have it replaced by a qualified electrician or an authorized service center. Never ground the unit through a gas, heating, or tap water pipe or the grounded wire of a single-phase power supply. -
Page 8: Storing Items In The Unit
• The temperature should be adjusted according to ambient temperature and the food items being stored. As you can see from the illustration on page 5, the temperature control can be adjusted on a scale of 1 through 5, with 5 being the coldest setting. (The control is set at 3 at the factory.) •... -
Page 9: Door Lock
Door Lock Your unit is provided with a lock and set of keys. The keys are located inside the plastic bag that contains the Instruction Manual. Insert the key into the lock and turn it clockwise to unlock the door. To lock the door, do the reverse operation, making sure the metal pin is engaged completely. -
Page 10: Power Failure
Power Failure Most power failures are corrected within a few hours and should not affect the temperature of your freezer if you minimize the number of times the doors are opened. If the power is going to be off for a longer period of time, you need to take the proper steps to protect the contents. -
Page 11: Troubleshooting
If the freezer develops problems that cannot be solved by referring to the chart above, do not try to dismantle the unit yourself. This could void your warranty. Instead, refer to an authorized service center or call SUMMIT Customer Service at 1-800-932-4267. -
Page 12: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship.
