Bosch Blue Line Gen2 ISC-BPR2 Installation Manual page 2

-
5
-
-
9 - 15 VDC
10 mA (0.12W) @ 12 VDC
9-15 Vcc
de 5 à 7 mA @ 12 Vcc en veille/
en alarme, source limitée en
puissance, ondulation
résiduelle 1 V.
7
44 mm
(1.7 in)
105 mm
(4.2 in)
61 mm
(2.4 in)
© 2014 Bosch Security Systems, Inc. 130 Perinton Parkway Fairport, NY 14450 USA
+
+
+ NC NC T T
≤ 100 mA, 25 VDC, 2.5 W
<20 Ω closed
8
2 min
?→
www.boschsecurity.com
Reading Bosch Security Systems, Inc. Product Date Codes
For Product Date Code information, refer to the
Bosch Security Systems, Inc. Web site at:
http://www.boschsecurity.com/datecodes/.
6
9
F.01U.139.797 | 06 | 2014.11 | 2
