- Page 1 USER GUIDE RF&KEYPAD INTEGRATED LOCKER LOCK (model :PT400B) Version 1.1 - 1 -...
-
Page 2: Table Of Contents
Table of Contents 1 Understanding PT400B Locker Lock ......... 3 1.1 What is PT400B Locker Lock? .............. 3 1.2 Operation cards ..................3 2. Types of Lock Operating Scenario ......... 3 2.1 Free Selection (Shared Use) ..............4 2.2 Assigned Mode (Permanent Use) ............4 3. -
Page 3: Understanding Pt400B Locker Lock
1 Understanding PT400B Locker Lock 1.1 What is PT400B Locker Lock? PT400B locker lock is operated by either keypads or BLE enabled mobile device (i.e. smartphone). PT400B is the battery power operating standalone RFID lock ( Offline ) 1.2 Operation cards... -
Page 4: Free Selection (Shared Use)
(max. 5 lockers ). - Programmable for multiple user mode per a locker (max. 8 users in a locker). 3. Lock Operation PT400B can be accessed with both Pin and BLE enabled smartphone. Version 1.1 - 4 -... -
Page 5: Assigned Mode
3.1 Assigned Mode 3.1.1 Open & Close by Pin Code ① Default Pin Code :1234 + “4 digit Pin Code”+ ② Open： ③ Close： Automatic close after several seconds ( Full cycle latch ) ④ Change Pin Code： + old Pin Code + + new Pin Code + + new Pin Code + Pin Code can be changed only when the lock is under... -
Page 6: Open In Emergency
① Download Passtech Mobile App from Google play store and install it into his smartphone ② After running the App, choose ‘Free mode’ on the setting tab. ③ Then, you can freely choose any available lock to operate. (2) Access Log To check the history of the mobile access key, visit the “Access Log”... -
Page 7: Low Battery Warning And Battery Change
lock by Master Card I or Master code. ② If Master code is set, + Master code + to open any locks. Master card can be set by Set up Card. ③ Once Master card I is used to open the lock, the lock reverts to default position (i.e. -
Page 8: Card Operation
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS 4. Card Operation 4.1 Owner Card The role of the Owner card is to delete the Master card registration. Therefore, Owner Version 1.1 - 8 -... -
Page 9: Master Card
card will be used to delete current master card registration in the lock, and make the lock to be ready to register new Master Card. It is simple to delete the Master card registration and to register new master card in the lock : ①... -
Page 10: User Card
③ Put the Maintenance card to the locks, then, new Master cards will be registered to the lock, and lost master card will be blocked. (2) Using Owner Card ① Delete the old master card registrations in the lock (refer to the 4.1) with Owner Card. -
Page 11: Assigned Mode (Permanent Use)
☞ In free selection mode, lock and card needs to read and write the each other’s information. So please do not sway the card until the latch is moved. 4.3.2 Assigned Mode (Permanent Use) The initial status of the lock in Assigned Mode is closed status (bolt out) ①... -
Page 12: Maintenance Card
4.4 Maintenance card ① Program Maintenance card as you want from LOS ② Put Maintenance card to each lock, lock will be set as you programmed in step ① ③ Time of the lock, Master cards change, Master code, Wireless online channel, Auto status update time can be updated with Maintenance card. -
Page 13: Annex A Beep & Led Table
Open/Close：GREEN LED on for 0.2 second, one beep sound for 0.2 second. Successful programming：Melody. Indicate for mistake：RED LED flashes 3 times, 3 beep sounds voltage：RED LED blinks 5 times, and beep sounds 5 times. Incorrect Pin Code or input is beyond 6 digits: see #5, power off，need to press to wake up the keypad again. - Page 14 buttons 3 X short beep 1 X Green & Red User card expired 4 X short beep Exceed the capacity of Lock info card 5 x short beep 5 x Red & Green Low battery Do-Re for 1.5 sec 4 X Red & Green Forced entry.
-
Page 15: Annex B Trouble Shooting
ANNEX B Trouble Shooting 1) Master card registration should be followed after deleting old Master card in the lock by Master card registration in the lock Owner card. was failed. 2) Put Master card on the lock before waiting time is out after Owner card. Cannot open the lock with Master Master card is not registered in the lock. - Page 16 Thank you for choosing PT400B RFID/Keypad locks. IF you have any questions, please contact your local distributor or our technical support. FCC Statement 15.19: This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
