- Page 1 USER GUIDE RF&KEYPAD INTEGRATED LOCKER LOCK (model :PT200) Version 1.0 - 1 -...
-
Page 2: Table Of Contents
Table of Contents 1. Understanding PT200 Locker Lock ......... 3 1.1 What is PT200 Locker Locks? ............3 1.2 Card Types and Functions ..............3 2. Types of Lock Operating Scenario ......... 4 2.1 Free Selection (Day Use) ..............4 2.2 Assigned Mode (Pre-Assigned Mode) .......... -
Page 3: Understanding Pt200 Locker Lock
1. Understanding PT200 Locker Lock 1.1 What is PT200 Locker Locks? PT200 locker locks are the locker lock operated by either13,56 MHz RF keys or Digital touch keypads. PT200 can work as both offline (stand alone) or online mode. To set PT200 as online system, additional peripherals such as Access point, Server and client software are necessary. -
Page 4: Types Of Lock Operating Scenario
2. Types of Lock Operating Scenario PT200 locker locks are designed to work for the various operation requirements by simple set up process. Following operation modes can be programmed before or after lock installation. 2.1 Free Selection (Day Use) - User can select any empty locker. -
Page 5: Lock Operation
3. Lock Operation 3.1 Pass code & RF tag uses ① PT200 can be set three different credential acceptance modes. ② Pass code & RF tag mode accepts both pass code and RF tag ③ RF tag only mode accepts only RF tag ( no pass code available ) ④... -
Page 6: Assigned Mode
3.2 Assigned Mode - Open & Close by Pass Code ① Default Pass Code :1234 ② Open： “Start” button + “4 digit pass code”+ “Start” button ③ Close： Automatic close after several seconds ④ Change Pass Code： “Start” button + old pass code + “Start” button + new pass code + “Start”... -
Page 7: Free Selection Mode
3.3 Free Selection Mode - Open & Close by Pass Code ① Close： “Start” button + self-selected 4 digit code + “Start” button ② Open： “Start” button + User’s 4 digit code + “Start” button. Bolt stays open - Open & Close by RF card key “Start”... -
Page 8: Card Operation
4. Card Operation 4.1 Owner Card The role of the Owner card is to delete the Master card registration. Therefore, Owner card will be used to delete current master card registration in the lock, and make the lock to be ready to register new Master Card. It is simple to delete the Master card registration and to register new master card in the lock : ①... -
Page 9: Replacing Old Master Cards With New Master Cards
4.2.2 Replacing old Master cards with New Master cards There are two ways to delete the lost Master card and register new Master card in the lock. - Using Time/Master Change Card ① Read the master cards (all Master cards to be used in a lock) to register in each lock at Time/master change menu in LOS program (or LIS program). -
Page 10: How Do I Add New Master Card
How do I add new Master card? 4.2.4 The procedure to add new Master card is same as 3.2.1. All master cards that will be used in locks must be registered to the locks because all Master card registration is deleted from the locks when Owner card is used. -
Page 11: Assigned Mode (Pre-Assigned Mode)
4.3.2 Assigned Mode (Pre-Assigned Mode) The initial status of the lock in Assigned Mode is closed status (bolt out) - Open and close the lock - ① Press “Touch” button on the front body of the lock. ② Put the User Card to the front body of the assigned lock. ③... -
Page 12: Low Battery Warning And Battery Change
4.4 Low Battery warning and battery change The RFID lock uses 4 pieces of 1.5V AA alkaline batteries (6V). - When battery reaches to low voltage ; ① Beep sounds five times. ② Red LED lights ③ Low battery is recorded in the memory of the User Card (Operator can know the low battery of the lock when the card is read at operator’s Program). -
Page 13: Audit Trail
4.5 Audit Trail ① Put Audit Trail Card to the lock. ② The latest event data (up to 18 events) will be downloaded from lock to the Card. Wait until melody is on. ③ Read the Card at LOS program, and 18 event data will be saved to the PC. 4.6 Lock Info ①... -
Page 14: Indication Instruction
5. Indication Instruction All the pass code is 4 digit（0-9）. “Start” button : wake up button，the keypad or RFID does not respond before you press “Start” button. Open/Close：GREEN LED on for 0.2 second, one beep sound for 0.2 second. Successful programming：Melody. Indicate for mistake：RED LED flashes 3 times, 3 beep sounds... -
Page 15: Annex A Beep & Led Table
ANNEX A Beep & LED Table Beep Description 1 x short beep 1 x Green(2sec) 2 x short beep 1 x Red(2sec) Operation Error 3 x short beep 1 x Red & Green in Time over turn(2sec) Do-Re-Mi Melody 1 x Red & Green in Successful Set up / mode turn(2sec) change / Time setting... -
Page 16: Annex B Trouble Shooting
ANNEX B Trouble Shooting 1) Master card registration should be followed after deleting old Master card in the lock by Master card registration in the lock Owner card. was failed. 2) Put Master card on the lock before waiting time is out after Owner card. Cannot open the lock with Master Master card is not registered in the lock. - Page 17 Thank you for selecting PT200 RFID/Keypad locks. Should you have any questions, please contact your local distributor or our technical support. Version 1.0 - 17 -...
- Page 18 USA-Federal Communications Commission (FCC) This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules.
